BIO-7504 & BIO-7505 BIO PROTECTOR
All specications and information shown were current as of publication and are subject to change without notice.
750405BIOIS APR2022
CLEANING INSTRUCTIONS
1. Rinse cover with water to remove abrasive dust and dirt.
2. Wash with soap or mild detergent using a soft cloth. (DO NOT SCRUB.)
3. Rinse once more, then dry with a soft cloth or chamois.
4. To remove grease or wet paint, rub gently with a cloth wetted thoroughly
with naphtha, then wash and rinse. (DO NOT USE RAZOR BLADES.)
INSTALLATION INSTRUCTIONS
1. Place the cover over the reader. Be sure the keypad and print reader are
accessible through the front opening in cover.
2. Mark and drill 7 holes 3/16 in. (4.7mm).
3. Complete assembly as shown.
WARNING: This product can expose you to chemicals including Dichloromethane, which is known
to the State of California to cause cancer, and Bisphenol A (BPA),
which is known to the State of California to cause birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
Three year warranty or a one year limited warranty (from date of purchase) on most products.
See website for details. Electronic warranty form at .www.sti-usa.com/wc14
75009A NEOPRENE GASKET
FRONT OPENING
19018 ANCHOR
(7) PROVIDED
19025 #8 x 2 in. SCREW
(7) PROVIDED 750097C COVER - CLEAR
750097S COVER - SMOKE
5.0 in.
(127mm)
GASKET
TOP VIEW
5.5 in.
(139mm)
FRONT VIEW
4.75 in.
(120mm)
8.75 in.
(222mm)
6.75 in.
(171mm)
USA EMEA
