Sida 1/45
Rev AO Date: 8.12.2019
READ AND SAVE THESE INSTRUCTIONS
I:\Oper Manuals\Oasis\B22_B32_B36_B42_B42C_B47_B59_B62_B71_B82_B88_B92_54110.pub
INSTALLATION &
OPERATING MANUAL
SCC P/N 54110
M O B I L E S E R I E S
888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
Model B42C
Model B32
OASIS REFRIGERATED “BOX CASES” / SELF-CONTAINED & REMOTE /
OPTIONAL SECURITY COVERS / TOP-MOUNTED CONDENSER PACKAGES
ON CERTAIN MODELS
Important!
If You Are
Adjoining Cases,
See Synchronous
Defrost Connection
Instructions On Page
8 AND Adjoinment
Instructions on
Page 9 Of This
Model B22.6817
Model
B6632SC.6241
Model B5932TM.6785
(Similar To B4732TM.6785)
(Top-Mounted Condenser
Pkg. / Underside Pump) /
Optional Rear Doors
Model B8832 (With Optional
Roll-Down Security Cover)
Model B4732
(With Optional Roll-Down
Security Cover)
Model B32.7413
2
TABLE OF CONTENTS / MODELS TO WHICH THIS MANUAL IS APPLICABLE
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS ………………………..
INSTALLATION: CASE REMOVAL (VIA L ………………..…….. EVELERS & CASTERS) …….……………………
INSTALLATION, CONTINUED: POSITIONING & ALIGNING CASE / ADJUSTING LEVELERS .…………..……..
INSTALLATION, CONTINUED: OPTIONAL SECURITY COVER INSTRUCTIONS ……………………….…….….
INSTALLATION, CONTINUED: SYNCHRONOUS DEFROST CONNECTION (OPTIONAL) …………….…….….
INSTALLATION, CONTINUED: ADJOINMENT INSTRUCTIONS ……………………………………..…..………….
FRONT GRILLE REMOVAL / CONDENSER PACKAGE / OVERFLOW PAN / MAIN POWER SWITCH /
CAREL® THERMOSTAT …………………………………………………………………………………………
EVAPORATOR COIL FAN DISCHARGE / TXV (THERMOSTATIC EXPANSION VALVE) …………...………..….
HONEYCOMB AIR DIFFUSER ACCESS ……………………………………...…...…………….………….…………..
FLUORESCENT LIGHT FIXTURES …………......………………………………………………………………….…....
LED LIGHT FIXTURES ………………………………………………………………………………………………..…....
OPTIONAL ROLL-DOWN SECURITY COVER - MODEL B4732 ILLUSTRATED (YOUR MODEL MAY VARY) ..
OPTIONAL DUAL REAR DOORS (WITH PERFORATED PLENUM DOORS) / B5932TM SHOWN …………..…...
OPTIONAL SINGLE REAR DOOR (WITH PERF. PLENUM AS PART OF DOORS) / B3632TM SHOWN ...………
WALL SPACING / REAR VENTING (MAY NOT BE APPLICABLE TO YOUR MODEL) ..…………...……………..
CONDENSATE PAN ACCESS: STANDARD UNITS ………..……………………………………………..….............
CONDENSATE PAN ACCESS: REMOTE UNITS WITH CONDENSATE PANS ONLY …………………..............
SELF-CONTAINED HOT GAS LOOP CONDENSATE PACKAGE LAYOUTS ……………………………………....
SELF-CONTAINED HOT GAS LOOP CONDENSATE PACKAGE LAYOUTS - TOP MOUNTED ………………...
UNDERSIDE PUMP/DRAIN UNIT (FOR UNITS WITH TOP-MOUNTED SELF-CONTAINED COND. PKGS.) ….
LOAD LEVEL GUIDE / TEMPERATURE GUIDE (MODEL B42 SHOWN / APPLICABLE TO ALL OTHER
MODELS IN MANUAL) …..………………………………………………………………………………………..
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) …..……………...…....……………….
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) …………………….
TROUBLESHOOTING (BY TRAINED SERVICE PROVIDERS ONLY) - CONDENSING SYSTEM ………….......
TROUBLESHOOTING (BY TRAINED SERVICE PROVIDERS ONLY) - EVAPORATOR SYSTEM ………….…..
SERIAL LABEL LOCATION & INFORMATION LISTED / TECH INFO & SERVICE ……….…..………...…………
CAREL® CONTROLLER OPERATING INSTRUCTIONS ………………………………………..………...…….…....
DIXELL® XM67(X)K CONTROLLER OPERATING INSTRUCTIONS ………………………………………………...
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION …...……………..…………..
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21-22
23
24
25
26
27-31
32-34
35
36
37
38-40
41-44
45
B22.6817
B32 CORE
B32.5955A
B3632
B3632TM
B42
Partial List of Models To Which This Manual Is Applicable
B42.5955
B42.6662
B42C
B43C
B4732
B4732SC.6162
B4732SC.7773
B4732TM
B4732TM.6785
B4732SC.7382
B4736SC.7455
B5932
B5932TM
B5932TM.6785
6032SC.6162
B6032SC.6241
B62
B6632SC.6241
B7132 B7132TM
B7132TMDR
B7132SC.6162
CDR7317
B82
B8832
B8832TM
B9232
CDR7317 (B42/B62
ADJOINMENT)
3
OVERVIEW
• These Structural Concepts merchandisers are designed
to merchandise packaged products at 41 °F (5 °C) or
less product temperatures.
• Product must be pre-chilled to 41 °F (5 °C) or less
product temperatures prior to placing in merchandiser.
• Cases should be installed and operated according to
this operating manual’s instructions to ensure proper
performance.
• Improper use will void warranty.
TYPE I vs. TYPE II ENVIRONMENTAL CONDITIONS
This unit is designed for the display of products in ambient
store conditions where temperature and humidity are
maintained within a specific range.
• Type I display refrigerators are intended for use in an
area where environmental conditions are controlled and
maintained so that the ambient temperature does not
exceed 75 °F (24 °C) and 55% maximum humidity.
• Type II display refrigerators are intended for use in an
area where environmental conditions are controlled and
maintained so that the ambient temperature does not
exceed 80 °F (27 °C) and 55% maximum humidity.
• If unsure if your unit is Type I or II, see tag next to serial
label. See SERIAL LABEL LOCATION &
INFORMATION LISTED / TECH INFO & SERVICE
section in this manual for sample serial labels.
COMPLIANCE
• Performance issues when in violation of applicable NEC,
federal, state and local electrical and plumbing codes
are not covered by warranty. See below.
WARNINGS
• This sheet contains important warnings to prevent injury
or death. Please read carefully!
REFRIGERANT DISCLOSURE STATEMENT
• This equipment is prohibited from use in California with
any refrigerants on the “List of Prohibited Substances”
for that specific end-use, in accordance with California
Code of Regulations, title 17, section 95374.
• This disclosure statement has been reviewed and
approved by Structural Concepts and Structural
Concepts attests, under penalty of perjury, that these
statements are true and accurate.
WARNING
Hazardous moving parts. Do not operate unit with covers removed.
Fan blades may be exposed when deck panel is removed.
Disconnect power before removing deck panel.
WARNING
Risk of electric shock. Disconnect power before servicing unit.
CAUTION! More than one source of electrical supply is
employed with units that have separate circuits.
Disconnect ALL ELECTRICAL SOURCES before servicing.
WARNING
Condensate Pan is Hot!
Disconnect and allow to cool before cleaning or removing from case.
WARNING
ELECTRICAL
HAZARD
WARNING
KEEP
HANDS
CLEAR
WARNING
HOT
SURFACE
COMPLIANCE
This equipment MUST be installed in compliance with
all applicable NEC, federal, state and local
electrical and plumbing codes.
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS - PAGE 1 of 2
ATTENTION
CONTRACTORS
WARNING: This product can expose you to chemicals, including
Urethane (Ethyl Carbamate), which are known to the state of
California to cause cancer and birth defects or other reproductive
harm. For more information go to P65Warnings.ca.gov.
