®, LLC

CORDLESS STRING TRIMMER – CORE TOOL

100-VOLT MAX* | 16-INCH

A Division of Snow Joe

®, LLC

OPERATOR’S MANUAL

Model iON100V-16ST-CT Form No. SJ-iON100V-16ST-CT-880E-MR1

IMPORTANT!

Safety Instructions

All Operators Must Read These

Instructions Before Use

Read all the instructions contained in this manual. Keep this

manual in a safe place, so that the information is available at

all times. If you give the equipment to another person, make

sure to provide these operating instructions. Basic safety

precautions should always be followed to reduce the risk of

re, electric shock, and personal injury.

mDANGER! This indicates a hazardous situation, which,

if not followed, will result in serious injury or death.

mWARNING! This indicates a hazardous situation, which,

if not followed, could result in serious injury or death.

mCAUTION! This indicates a hazardous situation, which,

if not followed, could result in minor or moderate injury.

Improper use of the machine will invalidate the warranty,

relieve the manufacturer from all liabilities. The user will

consequently be liable for all and any damage or injury to

himself/herself or others.

mDANGER! The cordless string trimmer should only be

used for cutting lawns and for trimming along the borders

of ower beds. Other uses of the string trimmer that are not

indicated in these instructions could damage the unit or

seriously injure the operator.

General Safety

1. Avoid dangerous environments – Do not use appliances

in damp or wet locations. Do not use in rain.

2. Keep children and bystanders away – Children and

other spectators, including pets, should be kept at least

50 feet (15 meters) away from the work area. When the

grass is cut, stones and debris contained in the grass can

be picked up by the string trimmer and dispersed into the

air. These ying projectiles can cause blindness or other

bodily injury.

3. Dress properly – Always wear suitable clothing when

using the string trimmer to prevent head, hand, or feet

injuries. Do not wear loose clothing or jewelry. They can

get caught in moving parts.

4. Use safety glasses – Also use safety footwear, snug-

tting clothing, protective gloves, hearing and head

protection.

5. Use the right tools – Do not use tools for any job except

that for which they are intended.

6. Avoid unintentional starting – Do not carry the tool with

nger on the trigger. Make sure the switch is o before

inserting the battery.

7. Do not force the tool – It will do the job better and with

less likelihood of injury if it is used at the rate for which it

was designed.

8. Do not overreach – Keep proper footing and balance at

all times.

9. Stay alert – Watch what you are doing. Use common

sense. Do not operate the string trimmer when you are

tired, or under the inuence of alcohol or drugs.

10. Disconnect the tool – Turn the string trimmer o and

remove the battery when: the unit is not in use; it is left

unattended; it is being examined because it is not working

correctly; the cutting line is being removed or changed;

or when the trimmer is being moved from one place to

another.

11. Store idle tools indoors – When not in use, tools should

be stored indoors in a dry and high or locked-up place out

of the reach of children.

12. Maintain tools with care – Keep cutting lines sharp

and clean for best performance and to reduce the

risk of injury. Follow instructions for maintenance and

changing accessories. Repair the string trimmer only at an

authorized service facility. Keep handles dry, clean, and

free from oil and grease.

13. Checked for damaged parts – Before continuing to

use the string trimmer, a guard or other part that is

damaged should be carefully checked to determine that

it will operate properly and perform its intended function.

Check for the alignment of moving parts, binding of

moving parts, breakage of parts, mounting, and any other

condition that may aect the tool’s operation. A guard or

other part that is damaged should be properly repaired or

replaced by an authorized service center unless indicated

elsewhere in this manual.

mCAUTION! The safety guard is critical to the safety of

the operator and the safety of people standing within a safe

distance of the string trimmer. The safety guard keeps the unit

in good working order and must always be in place during

operation. Failure to have the guard in place during operation

is dangerous and will void the warranty.

14. Keep away from the cutting line – It can seriously injure

the skin.

15. Do not try to stop the cutting device with your hands –

Always let it come to a stop by itself.

16. Stay alert – Watch what you are doing. Use common

sense. Do not operate the string trimmer when you are

tired or under the inuence of drugs, alcohol, or other

medication.

mCAUTION! The trimmer line spool will continue to rotate

after turning the trimmer OFF. Wait until the trimmer line spool

has completely stopped before making contact.

• Only use the same type of line originally provided with the

tool.

• Do not use the unit to cut grass that is not in contact with

the ground.

• ONDo not switch the string trimmer in enclosed or poorly

ventilated spaces or in the presence of ammable and/or

explosive substances such as liquids, gases, and powders.

• The user of the string trimmer is responsible for any

damage sustained by third parties that has been caused by

the string trimmer within the working area.

• Only cut during broad daylight or with adequate articial

light.

• Do not cross roads or gravel paths while the unit is still

running.

• When the string trimmer is not in use, store it in a dry place

and out of the reach of children.

• The string trimmer must be operated in a vertical position,

perpendicular to the ground.

• Check regularly that all screws are properly secured.

Battery + Charger

Safety Instructions

NOTE: The battery and the charger are not included and must

be purchased separately. The iON100V-16ST-CT is compatible

with the following batteries (models iON100V-2.5AMP and

iON100V-5AMP) and charger (model iON100V-RCH). See page

19 for more information.

We pay a great deal of attention to the design of every battery

pack to ensure that we supply you with batteries that are safe,

durable and have a high energy density. The battery cells have

a wide range of safety devices. Each individual cell is initially

formatted and its electrical characteristic curves are recorded.

This data is then used exclusively to be able to assemble the

best possible battery packs.

Despite all the safety precautions, caution must always be

exercised when handling batteries. The following points must

be obeyed at all times to ensure safe use. Safe use can only

be guaranteed if undamaged cells are used. Incorrect handling

of the battery pack can cause cell damage.

IMPORTANT! Analyses conrm that incorrect use and poor

care of high-performance batteries are the main factors

responsible for personal and/or product damage.

mWARNING! Use only approved replacement batteries;

other batteries may damage the string trimmer and cause it to

malfunction, which can lead to serious personal injury.

mCAUTION! To reduce the risk of injury, charge the

iON100V-2.5AMP battery pack or the iON100V-5AMP battery

pack only in their compatible charger (model iON100V-RCH).

Other types of chargers present risk of re, personal injury, and

damage. Do not wire a battery pack to a power supply plug or

car cigarette lighter. Such misuse will permanently disable or

damage the battery pack.

• Avoid dangerous environments – Do not charge the

battery pack in rain, snow or in damp or wet locations.

Do not use the battery pack or charger in the presence of

explosive atmospheres (gaseous fumes, dust or ammable

materials) because sparks may be generated when inserting

or removing the battery pack, which could lead to a re.

• Charge in a well-ventilated area – Do not block the

charger vents. Keep them clear to allow for proper

ventilation. Do not allow smoking or open ames near a

charging battery pack. Vented gases may explode.

The safe temperature range for the battery is NOTE:

-4°F (-20°C) to 113°F (45°C). Do not charge the battery

outside in freezing weather; charge it at room temperature.

• Maintain charger cord – When unplugging the charger, pull

the plug, not the cord, from the receptacle to reduce the

risk of damage to the electrical plug and cord. Never carry

the charger by its cord or yank it by the cord to disconnect

it from the receptacle. Keep the cord away from heat, oil

and sharp edges. Make sure the cord will not be stepped

on, tripped over or subjected to damage or stress when the

charger is in use. Do not use the charger with a damaged

cord or plug. Replace a damaged charger immediately.

• Do not use an extension cord unless it is absolutely

necessary – Using the wrong, damaged or improperly

wired extension cord poses a risk of re and electric shock.

If an extension cord must be used, plug the charger into a

properly wired 18 gauge or larger extension cord with the

female plug matching the male plug on the charger. Make

sure that the extension cord is in good electrical condition.

• Charger iON100V-RCH is rated for 100 – 120 volt AC

only – The charger must be plugged into an appropriate

receptacle.

• Use only recommended attachments – Use of an

attachment not recommended or sold by the battery

charger or battery pack manufacturer may result in risk of

re, electric shock or personal injury.

• Unplug charger when not in use – Make sure to remove

battery pack from unplugged chargers.

mWARNING! To reduce the risk of electric shock,

always unplug the charger before performing any cleaning

or maintenance. Do not allow water to ow into the charger.

Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock

hazards.

• Do not burn or incinerate battery packs – Battery packs

may explode, causing personal injury or damage. Toxic

fumes and materials are created when battery packs are

burned.

• Do not crush, drop or damage battery packs – Do not

use the battery pack or charger if they have sustained a

sharp blow, been dropped, run over or have been damaged

in any way (i.e. pierced with a nail, hit with a hammer,

stepped on, etc.).

• Do not disassemble – Incorrect reassembly may pose

a serious risk of electric shock, re or exposure to toxic

battery chemicals. If the battery or charger are damaged,

please contact an authorized Snow Joe® + Sun Joe® dealer

or call the Snow Joe® + Sun Joe® customer service center

at 1-866-SNOWJOE (1-866-766-9563).

• Never let a Battery chemicals cause serious burns –

damaged battery pack contact the skin, eyes or mouth. If a

damaged battery pack leaks battery chemicals, use rubber

or neoprene gloves to safely dispose of it. If skin is exposed

to battery uids, wash the aected area with soap and

water and rinse with vinegar. If eyes are exposed to battery

chemicals, immediately ush with water for

20 minutes and seek medical attention. Remove and

dispose of contaminated clothing.

• Do not short circuit – A battery pack will short circuit if

a metal object makes a connection between the positive

and negative contacts on the battery pack. Do not place a

battery pack near anything that may cause a short circuit,

such as paper clips, coins, keys, screws, nails and other

metallic objects. A short-circuited battery pack poses a risk

of re and severe personal injury.

• Store your battery pack and charger in a cool, dry

place – Do not store the battery pack or charger where

temperatures may exceed 104ºF (40ºC), such as in direct

sunlight or inside a vehicle or metal building during the

summer.

Protection from environmental inuences

1. Wear suitable work clothes. Wear safety goggles.

2. Protect your cordless tool and the battery charger from

moisture and rain. Moisture and rain can cause dangerous

cell damage.

3. Do not use the cordless tool or the battery charger near

vapors and ammable liquids.

4. Use the battery charger and cordless tools only in dry

conditions and at an ambient temperature of 50˚F – 104°F

(10°C – 40°C).

5. Do not keep the battery charger in places where the

temperature is liable to reach over 104°F (40°C).

In particular, do not leave the battery charger in a car that

is parked in the sunshine.

6. Protect batteries from overheating. Overloads,

overcharging and exposure to direct sunlight will result

in overheating and cell damage. Never charge or work

with batteries that have been overheated – replace them

immediately, if possible.

7. Store the charger and your cordless tool only in dry

locations with an ambient temperature of 50˚F – 104°F

(10˚C – 40°C). Store your lithium-ion battery pack in a

cool, dry place at a temperature of 50˚F – 68°F

(10˚C – 20°C). Protect the battery pack, charger and

cordless tool from humidity and direct sunlight. Only place

fully charged batteries in storage (charged to at least

40%).

8. Prevent the lithium-ion battery pack from freezing. Battery

packs that were stored below 32°F (0°C) for more than

60 minutes must be discarded.

9. When handling batteries, be wary of electrostatic charge.

Electrostatic discharges can damage the electronic

protection system and the battery cells. Avoid electrostatic

charging and never touch the battery poles.

Information about the battery

1. The battery packs (model iON100V-2.5AMP or iON100V-

5AMP) must be purchased separately for use with this

cordless string trimmer are only partially charged. The

battery packs have to be charged completely before you

use the tool for the rst time.

2. For optimum battery performance, avoid low discharge

cycles by charging the battery packs frequently.

3. Store the battery packs in a cool place, ideally at

59°F (15°C) and charged to at least 40%.

4. Lithium-ion batteries are subject to a natural aging

process. The battery packs must be replaced at the latest

when its capacity falls to just 80% of its capacity when

new. Weakened cells in an aged battery pack are no

longer capable of meeting the high power requirements

needed for the proper operation of your cordless string

trimmer, and therefore pose a safety risk.

5. Do not throw battery packs into an open re as this poses

a risk of explosion.

6. Do not ignite the battery packs or expose them to re.

7. Do not exhaustively discharge batteries. Exhaustive

discharge will damage the battery cells. The most

common cause of exhaustive discharge is lengthy

storage or non-use of partially discharged batteries. Stop

working as soon as the performance of the batteries falls

noticeably or the electronic protection system triggers.

Place the battery packs in long-term storage only after

they have been fully charged.

8. Protect batteries and the tool from overloads. Overloads

will quickly result in overheating and cell damage inside

the battery housing even if this overheating is not apparent

externally.

9. Avoid damage and shocks. Immediately replace batteries

that have been dropped from a height of more than one

meter or those that have been exposed to violent shocks,

even if the housing of the battery pack appears to be

Produktspecifikationer

Varumärke:	Sun Joe
Kategori:	Grastrimmer
Modell:	ION100V-16ST-CT
Typ av operation:	Touch
Färg på produkten:	Black, White
Vikt:	112037 g
Bredd:	610.87 mm
Djup:	657.86 mm
Höjd:	1203.96 mm
Förpackningens vikt:	144242 g
Förpackningens bredd:	830 mm
Djuppackning:	762 mm
Förpackningshöjd:	1438.91 mm
Skärm diagonal:	10.2 "
Pekskärm:	Ja
Processorfrekvens:	1200 MHz
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
USB uttag:	Ja
Ethernet LAN:	Ja
Marknadspositionering:	Bedrijf
Antal USB 2.0-portar:	3
Internminne:	1024 MB
Hållbarhetscertifikat:	ENERGY STAR
Ethernet LAN, dataöverföringshastigheter:	10,100,1000 Mbit/s
Kabelteknik:	10/100/1000Base-T(X)
Säkerhetsalgoritmer som stöds:	802.1x RADIUS, SSL/TLS
Stöder Windows:	Ja
Stöder Mac-operativsystem:	Ja
Stöder Linux:	Ja
Maximal-upplösning:	1200 x 1200 DPI
Medietyper för papperslåda:	Banner, Card stock, Envelopes, Labels, Plain paper, Transparencies
Höjd, drift:	0 - 3048 m
Andra stödsystem:	Ja
Utskriftsteknik:	Laser
Standardgränssnitt:	Ethernet, USB 2.0
Duplexutskriftsläge:	Automatisch/handmatig
Utskriftshastighet (svart, standardkvalitet, A4/US Letter):	37 ppm
Utskriftshastighet (färg, standard, A4/US Letter):	37 ppm
Att skriva ut:	Afdrukken in kleur
Duplexutskrift:	Ja
Sidbeskrivningsspråk:	Microsoft XPS, PCL 5c, PCL 6, PDF 1.6, PostScript 3, PPDS, XHTML
Indikation på användning (max):	150000 pagina's per maand
Förstora/förminska kopior:	25 - 400 procent
Första kopieringstiden (svart, normal):	11.5 s
Tid till första kopia (färg, normal) upp till max.:	13.5 s
Maximal kopieringsupplösning:	- DPI
Att kopiera:	Kopiëren in kleur
Skanna:	Scannen in kleur
Typ av skanner:	Flatbed-/ADF-scanner
Optisk scanningsupplösning:	600 x 600 DPI
Max. scangebied:	216 x 356 mm
Skanningshastighet (färg):	49 ppm
Skanningshastighet (mono):	49 ppm
Modemhastighet:	33.6 Kbit/s
Fax:	Faxen in kleur
Total ingångskapacitet:	1750 vel
Maximal ingångskapacitet:	3200 vel
Total uteffekt:	500 vel
Maximal uteffekt:	1000 vel
Maximal pappersstorlek i ISO A-serien:	A4
ISO A-seriens mått (A0...A9):	A4, A5
Genomsnittlig strömförbrukning (driftsresultat):	- W
Mobil utskriftsteknik:	Apple AirPrint
Skriv ut direkt:	Ja
Dags till första sidan (svart, normal):	9 s
Dags till första sidan (färg, normal):	10 s
Nätverksprotokoll som stöds (IPv4):	TCP/IP, IPV4, AppleTalk
Nätverksprotokoll som stöds (IPv6):	TCP/IP IPv6, TCP, UDP
Valfri anslutning:	Parallel, Serial (RS-232), Wireless LAN
Ljudtrycksnivå (tryck):	51 dB
Maximalt-internminne:	2048 MB
Typ av pappersinmatning:	Papierlade
Totalt antal inmatningsfack:	4
Maximalt antal inmatningsfack:	5
JIS B-seriens storlekar (B0...B9):	B5
Maximala tryckmått:	216 x 297 mm
Kuvertmått:	7 3/4, 9,10, B5, C5, DL
Icke-ISO tryckpappersmått:	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
Duplex skanning:	Ja
Dubbelsidig kopiering:	Ja
Rekommenderad användningsindikation:	2500 - 14000 pagina's per maand
Multifunktionell lådkapacitet:	100 vel
Multifunktionell låda:	Ja
Serveroperativsystem som stöds:	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Skanna till:	Afbeelding
Utskriftshastighet duplex (svart, normal kvalitet, A4/US Letter):	37 ppm
Utmatningskapacitet för automatisk dokumentmatare (ADF).:	75 vel
Automatisk dokumentmatare (ADF):	Ja
Beveiligingseigenschappen:	MD5, MSCHAPv2, LEAP, PEAP, TLS, TTLS, SNMPv3, IPSec
Automatisk dokumentmatarkapacitet:	75 vel
Förvaltningsprotokoll:	HTTP HTTPs (SSL/TLS) SNMPv3 WINS IGMP BOOTP, RARP APIPA (AutoIP) DHCP ICMP DNS SNMPv2c Bonjour DDNS mDNS ARP NTP Telnet Finger
Ljudeffektnivåer (standby):	26 dB
Drifttemperatur (TT):	16 - 32 °C
Relativ luftfuktighet i drift (VV):	8 - 80 procent
Ljudtrycksnivå (kopiering):	52 dB
Ljudtrycksnivå (skanning):	54 dB
Autentiseringsmetod:	802.1x
Duplex skanningshastighet (färg):	54 ppm
Duplex skanningshastighet (svart):	58 ppm
Nätverksutskriftsmetoder:	LPR/LPD, Direct IP (Port 9100), HTTP, NDPS/NEPS, Enhanced IP, FTP, TFTP IPP 1.1, ThinPrint .print
Efterbehandlingsalternativ:	Ja
Ljudtrycksnivå (duplexutskrift):	51 dB
Pappersfackets mediavikt (enhet i Storbritannien):	16 - 47 lbs
Kopieringshastighet (svart, amerikansk bokstav):	37 cpm
Kopieringshastighet (färg, normal, amerikansk bokstav):	37 cpm
