®, LLC

CORDLESS STRING TRIMMER – CORE TOOL

100-VOLT MAX* | 16-INCH

A Division of Snow Joe

®, LLC

OPERATOR’S MANUAL

Model iON100V-16ST-CT-RM Form No. SJ-iON100V-16ST-CT-RM-880E-MR1-V2

®, LLC

CORDLESS STRING TRIMMER – CORE TOOL

100-VOLT MAX* | 16-INCH

A Division of Snow Joe

®, LLC

OPERATOR’S MANUAL

Model iON100V-16ST-CT-RM Form No. SJ-iON100V-16ST-CT-RM-880E-MR1-V2

IMPORTANT!

Safety Instructions

All Operators Must Read These

Instructions Before Use

Read all the instructions contained in this manual. Keep this

manual in a safe place, so that the information is available at

all times. If you give the equipment to another person, make

sure to provide these operating instructions. Basic safety

precautions should always be followed to reduce the risk of

re, electric shock, and personal injury.

mDANGER! This indicates a hazardous situation, which,

if not followed, will result in serious injury or death.

mWARNING! This indicates a hazardous situation, which,

if not followed, could result in serious injury or death.

mCAUTION! This indicates a hazardous situation, which,

if not followed, could result in minor or moderate injury.

Improper use of the machine will invalidate the warranty,

relieve the manufacturer from all liabilities. The user will

consequently be liable for all and any damage or injury to

himself/herself or others.

mDANGER! The cordless string trimmer should only be

used for cutting lawns and for trimming along the borders

of ower beds. Other uses of the string trimmer that are not

indicated in these instructions could damage the unit or

seriously injure the operator.

General Safety

1. Avoid dangerous environments – Do not use appliances

in damp or wet locations. Do not use in rain.

2. Keep children and bystanders away – Children and

other spectators, including pets, should be kept at least

50 feet (15 meters) away from the work area. When the

grass is cut, stones and debris contained in the grass can

be picked up by the string trimmer and dispersed into the

air. These ying projectiles can cause blindness or other

bodily injury.

3. Dress properly – Always wear suitable clothing when

using the string trimmer to prevent head, hand, or feet

injuries. Do not wear loose clothing or jewelry. They can

get caught in moving parts.

4. Use safety glasses – Also use safety footwear, snug-

tting clothing, protective gloves, hearing and head

protection.

5. Use the right tools – Do not use tools for any job except

that for which they are intended.

6. Avoid unintentional starting – Do not carry the tool with

nger on the trigger. Make sure the switch is o before

inserting the battery.

7. Do not force the tool – It will do the job better and with

less likelihood of injury if it is used at the rate for which it

was designed.

8. Do not overreach – Keep proper footing and balance at

all times.

9. Stay alert – Watch what you are doing. Use common

sense. Do not operate the string trimmer when you are

tired, or under the inuence of alcohol or drugs.

10. Disconnect the tool – Turn the string trimmer o and

remove the battery when: the unit is not in use; it is left

unattended; it is being examined because it is not working

correctly; the cutting line is being removed or changed;

or when the trimmer is being moved from one place to

another.

11. Store idle tools indoors – When not in use, tools should

be stored indoors in a dry and high or locked-up place out

of the reach of children.

12. Maintain tools with care – Keep cutting lines sharp

and clean for best performance and to reduce the

risk of injury. Follow instructions for maintenance and

changing accessories. Repair the string trimmer only at an

authorized service facility. Keep handles dry, clean, and

free from oil and grease.

13. Checked for damaged parts – Before continuing to

use the string trimmer, a guard or other part that is

damaged should be carefully checked to determine that

it will operate properly and perform its intended function.

Check for the alignment of moving parts, binding of

moving parts, breakage of parts, mounting, and any other

condition that may aect the tool’s operation. A guard or

other part that is damaged should be properly repaired or

replaced by an authorized service center unless indicated

elsewhere in this manual.

mCAUTION! The safety guard is critical to the safety of

the operator and the safety of people standing within a safe

distance of the string trimmer. The safety guard keeps the unit

in good working order and must always be in place during

operation. Failure to have the guard in place during operation

is dangerous and will void the warranty.

14. Keep away from the cutting line – It can seriously injure

the skin.

15. Do not try to stop the cutting device with your hands –

Always let it come to a stop by itself.

16. Stay alert – Watch what you are doing. Use common

sense. Do not operate the string trimmer when you are

tired or under the inuence of drugs, alcohol, or other

medication.

mCAUTION! The trimmer line spool will continue to rotate

after turning the trimmer OFF. Wait until the trimmer line spool

has completely stopped before making contact.

• Only use the same type of line originally provided with the

tool.

• Do not use the unit to cut grass that is not in contact with

the ground.

• ONDo not switch the string trimmer in enclosed or poorly

ventilated spaces or in the presence of ammable and/or

explosive substances such as liquids, gases, and powders.

• The user of the string trimmer is responsible for any

damage sustained by third parties that has been caused by

the string trimmer within the working area.

• Only cut during broad daylight or with adequate articial

light.

• Do not cross roads or gravel paths while the unit is still

running.

• When the string trimmer is not in use, store it in a dry place

and out of the reach of children.

• The string trimmer must be operated in a vertical position,

perpendicular to the ground.

• Check regularly that all screws are properly secured.

Battery + Charger

Safety Instructions

NOTE: The battery and the charger are not included and

must be purchased separately. The iON100V-16ST-CT-RM is

compatible with the following batteries (models

iON100V-2.5AMP and iON100V-5AMP) and charger (model

iON100V-RCH). See page 19 for more information.

We pay a great deal of attention to the design of every battery

pack to ensure that we supply you with batteries that are safe,

durable and have a high energy density. The battery cells have

a wide range of safety devices. Each individual cell is initially

formatted and its electrical characteristic curves are recorded.

This data is then used exclusively to be able to assemble the

best possible battery packs.

Despite all the safety precautions, caution must always be

exercised when handling batteries. The following points must

be obeyed at all times to ensure safe use. Safe use can only

be guaranteed if undamaged cells are used. Incorrect handling

of the battery pack can cause cell damage.

IMPORTANT! Analyses conrm that incorrect use and poor

care of high-performance batteries are the main factors

responsible for personal and/or product damage.

mWARNING! Use only approved replacement batteries;

other batteries may damage the string trimmer and cause it to

malfunction, which can lead to serious personal injury.

mCAUTION! To reduce the risk of injury, charge the

iON100V-2.5AMP battery pack or the iON100V-5AMP battery

pack only in their compatible charger (model iON100V-RCH).

Other types of chargers present risk of re, personal injury, and

damage. Do not wire a battery pack to a power supply plug or

car cigarette lighter. Such misuse will permanently disable or

damage the battery pack.

• Avoid dangerous environments – Do not charge the

battery pack in rain, snow or in damp or wet locations.

Do not use the battery pack or charger in the presence of

explosive atmospheres (gaseous fumes, dust or ammable

materials) because sparks may be generated when inserting

or removing the battery pack, which could lead to a re.

• Charge in a well-ventilated area – Do not block the

charger vents. Keep them clear to allow for proper

ventilation. Do not allow smoking or open ames near a

charging battery pack. Vented gases may explode.

The safe temperature range for the battery is NOTE:

-4°F (-20°C) to 113°F (45°C). Do not charge the battery

outside in freezing weather; charge it at room temperature.

• Maintain charger cord – When unplugging the charger, pull

the plug, not the cord, from the receptacle to reduce the

risk of damage to the electrical plug and cord. Never carry

the charger by its cord or yank it by the cord to disconnect

it from the receptacle. Keep the cord away from heat, oil

and sharp edges. Make sure the cord will not be stepped

on, tripped over or subjected to damage or stress when the

charger is in use. Do not use the charger with a damaged

cord or plug. Replace a damaged charger immediately.

• Do not use an extension cord unless it is absolutely

necessary – Using the wrong, damaged or improperly

wired extension cord poses a risk of re and electric shock.

If an extension cord must be used, plug the charger into a

properly wired 18 gauge or larger extension cord with the

female plug matching the male plug on the charger. Make

sure that the extension cord is in good electrical condition.

• Charger iON100V-RCH is rated for 100 – 120 volt AC

only – The charger must be plugged into an appropriate

receptacle.

• Use only recommended attachments – Use of an

attachment not recommended or sold by the battery

charger or battery pack manufacturer may result in risk of

re, electric shock or personal injury.

• Unplug charger when not in use – Make sure to remove

battery pack from unplugged chargers.

Produktspecifikationer

Varumärke:	Sun Joe
Kategori:	Grastrimmer
Modell:	ION100V-16ST-CT-RM
Färg på produkten:	Rood
Vikt:	1460 g
Bredd:	296 mm
Djup:	208 mm
Blåtand:	Ja
Skärm diagonal:	12.1 "
Upplösning:	1366 x 768 Pixels
Original bildförhållande:	16:9
Processorfrekvens:	1.6 GHz
Processorfamilj:	Intel Atom®
Bluetooth-version:	2.1+EDR
Grafikadapter:	Ion
Främre kameraupplösning (numerisk):	0.3 MP
Inkluderar operativsystem:	Windows 7 Home Premium
Ethernet LAN:	Ja
Integrerad minneskortläsare:	Ja
Kompatibla minneskort:	MMC, SD, SDHC
Ljudsystem:	HDA
LED-bakgrundsbelysning:	Ja
Antal USB 2.0-portar:	3
VGA (D-Sub) port(ar):	1
Antal HDMI-portar:	1
Mikrofon, linjeingång:	Ja
Antal Ethernet LAN (RJ-45)-portar:	1
Antal inbyggda högtalare:	2
Hörlursutgångar:	1
Inbyggd mikrofon:	Ja
Internminne:	2 GB
Batteritid/batteritid:	5 uur
Internminnestyp:	DDR2-SDRAM
Processorns cache:	1 MB
Typ av processorcache:	L2
Processorfabrikant:	Intel
Typ av optisk enhet:	Nee
Nätverksfunktioner:	Fast Ethernet
Pekdon:	Touchpad
Minnesplatser:	2x SO-DIMM
Vikt (imperialistisk):	3.22 lbs
HDD kapacitet:	250 GB
Bussprocessor på framsidan:	533 MHz
Typ av laddningsport:	DC-in ingang
Trådlös teknik:	IEEE 802.11 b/g/n
Höjd (fram):	27.3 mm
Höjd (bak):	33.3 mm
Wifi:	Ja
Typ produkt:	Netbook
Batteriteknik:	Lithium-Ion (Li-Ion)
Antal battericeller:	6
