Supermicro X11SWN-E-WOHS Bruksanvisning

Läs nedan 📖 manual på svenska för Supermicro X11SWN-E-WOHS (1 sidor) i kategorin Inte kategoriserad. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Sida 1/1
ContaCt nformatIon I
Manuals: http://www.supermicro.com/support/manuals
Drivers & Utilities: https://www.supermicro.com/wftp/driver/
Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2019 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P C (raCkage ontents etaIl aCkage P )
X11sWn-H/-e/-l/-C, X11sWn-H/-e/-l/-C-WOHS
Quick Reference Guide 1.00
One (1) Supermicro Motherboard with
Passive Heatsink
One (1) Quick Reference Guide
One (1) DC IN Power Cable
One (1) SATA Power Cable
Website: www.supermicro.com
General Information: marketing@supermicro.com
Technical Support: support@supermicro.com
Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
f or your system to Work ProPerly Please doWnload aPProPrIate,
drIvers Images user s manual from tHe lInks beloW/ / ' :
MNL-2217-QRG-100
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
SUPERMICR R
One (1) SATA Cable
One (1) COM Cable
One (1) USB Cable One (1) Audio Cable
DESIGNED IN USA
X11SWN
REV:1.01
1
FAN1
JF1
JGP1
JPH1
JPWR1
JBT1
JPF1
JPME2
JPT1
I-SATA0
JCOM1
JCOM2
JLPC80
JLCDPWR1
LVDS1
MH1
JCOM3
LED
LED
ON
PWR
HDD
JF1
RST
PWR
AUDIO
COM6COM5COM4COM3
COM2COM1
USB6/7
USB4/5
(3.1)USB2/3 (3.1)
HDMI
CPU
ON:PWR FORCE ON
USB0/1
LAN2 LAN1
DP
2-3:DISABLE
JPT1:
1-2:ENABLE
FP
J2
Connectors
Jumpers and ConnectorsMotherboard Layout and Features
Jumpers
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in
this guide.
Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers and connectors. The battery is
temporarily placed on the heatsink during shipping. Please use the foam tape on the back side of the battery to
secure it to a proper location in the system. DO NOT place the battery on the heatsink during operation.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
= mounting hole
CPU and Memory Support
X11SWN-H/X11SWN-H-WOHS: Intel® Core i7-8665UE processor
X11SWN-E/X11SWN-E-WOHS: Intel Core i5-8365UE processor
X11SWN-L/X11SWN-L-WOHS: Intel Core i3-8145UE processor
X11SWN-C/X11SWN-C-WOHS: Intel Celeron® 4305UE processor
The X11SWN Series motherboard supports up to 64GB of Non-ECC SO-DIMM
(32GB per SO-DIMM) DDR4 memory with speeds of up to 2400MHz (2133MHz
for -C/-C-WOHS) in two slots.
Back Panel I/O Connectors
876
5
4
3
2
Jumper Description Default Setting
JBT1 CMOS Clear Pin 1-2* Normal Operation (Default)
Pin 2-3 Clear CMOS
JLCDPWR1 LVDS Panel
Power Source Selection
Pin 1-3* (3.3V) (Default)
Pin 3-5 (5V)
Pin 3-4 (12V)
JPF1 Power Force On Pin 1-2* (Force Power ON) (Default)
Pin 2-3 (Power Button ON)
JPME2 Manufacturing Mode Select Pins 1-2* (Normal)
JPT1 TPM Enable/Disable Pins 1-2* (Enabled) (Default)
Pins 2-3 (Disabled)
J2 SIM Detection Pins 2-4* (High Active) (Default)
Pins 4-6 (Low Active)
Connector Description
AUDIO FP Front Panel Audio Header (Mic-In/Mic-Out)
BT1 Onboard Battery Header
JCOM1 COM1/COM2 Headers (RS232/422/485)
JCOM2 COM3/COM4 Headers (RS232)
JCOM3 COM5/COM6 Headers (RS232)
DP Dual-Mode Display Port (DP++)
FAN1 System Fan Header
HDMI High Denition Multimedia Interface
I-SATA0 SATA 3.0 Port
JEIO1 Extended I/O (bottom side)
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JMD1 M.2 B-Key 2242/3042/2280
(SATA 3.0/USB 3.0/USB 2.0 with Nano SIM) Slot (bottom side)
JMD2 M.2 E-Key 2230 (PCI-E x1/USB2.0/CNVi) Slot (bottom side)
JMD3 M.2 M-Key 2242/2280 (PCI-E x4/SATA) Slot (bottom side)
JPH1 4-pin HDD Power Output Connector
JPWR1 8-pin +12-24V DC Power Input Connector
JSIM1 Nano SIM Card Slot (bottom side)
JSMBUS1 System Management Bus Header (bottom side)
LAN1/LAN2 Gigabit Ethernet Ports
LVDS1 Low-Voltage Di󰀨erential Signaling (LVDS) Connector
SRW1 - SRW5 M.2 Mounting Holes
USB0/1, USB2/3 Back Panel USB 3.1 Gen2 Ports
USB4/5, USB6/7 Front Accessible USB 2.0 Headers
Front Control Panel
Power Button
1
Reset Button
2
3.3V
3.3V Stby
HDD LED
Power LED
Ground
Ground
7 8
1
JSMBUS1
BT1
JEIO1
JMD3
JMD1
JMD2
JSIM1
SRW3
DIMMA1
DIMMB1
SRW1
SRW2
SRW4
SRW5
Align
1. Position the SO-DIMM module's bottom key so it aligns with the receptive
point on the slot.
2. Insert the SO-DIMM module vertically at about a 45-degree angle. Press
down until the module locks into place. The side clips will automatically
secure the SO-DIMM module, locking it into place.
Insert this end rst
Locking Clip
SO-DIMM Installation
Bottom Side Layout
Top Side Layout
# #Description Description
1. LAN1 5. USB2 (USB3.1)
2. LAN2 6. USB3 (USB3.1)
3. 7. DP++USB1 (USB3.1)
4. 8. HDMIUSB0 (USB3.1)
