Rechargeable Li-ion Battery Pack
Ver:A
Tel:+86-25-85805753
Fax:+86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
USER MANUAL
S W I T E l e c t r o n i c s Co. , LT D.
Features
Storage
Caution
Charging and Discharging
1. High performance Li-ion battery pack, rechargeable.
2. 4-step LED power indicator.
3. Build-in multiple protective circuit design.
4. D-tap DC output, to power the camera and other equipment
simultaneously.
5. S-8180A/S support 6A fast charging, by SWIT S-3812A/S fast
charger.
1. Keep the battery pack terminals clean.
2. The battery pack may become warm in use or while being
charged. This is normal.
3. Never expose the battery pack to rain, re or moisture.
4. Never expose the battery pack to temperature above 60°C.
5. Please pay attention to the polarity of the D-tap DC output
6. Please check the max current of the battery plate of the
equipment to avoid damage to battery plate or battery.
IMPORTANT SAFETY INSTRUCTIONS
Never short-circuit the battery pack terminals.
Never attempt to open the battery pack.
Keep the battery pack away from re or hot place.
Avoid strong mechanical shock.
Charging:
1. It is suggested that fully charge the battery before use.
2. Please use SWIT charger to charge.
3. The battery pack should be charged within a temperature
range of 0-40°C.
Discharging:
1. Fully charged battery pack will discharge naturally and please
use it as soon as it gets charged.
2. At low temperature, the running time of battery pack usually
decreases.
3. The internal impedance of battery pack will be greater at low
temperature, which may cause the automatically circuit cutting.
4. The battery will automatically cut o power to protect itself
when voltage, current or temperature is abnormal. Please take
o the battery, and follow the down blow steps to reactivate
the battery:
(1) Under indoor temperature, lay the battery pack aside for 3-5
minutes and mount the battery pack to any SWIT charger, it
will be re- activated and get charging normally.
(2) If the environment temperature is high, please lay the battery
pack aside for 20-30 minutes and then charge the battery by
SWIT chargers to active.
Store the battery pack in cool, dry and clean place.
Specification
Capacity
95Wh
95Wh
146Wh
146Wh
220Wh
220Wh
73Wh
6.6Ah
6.6Ah
10.2Ah
10.2Ah
15.3Ah
15.3Ah
5.1Ah
70W
70W
100W
100W
140W
140W
66W
6A
6A
8A
8A
12A
12A
5.5A
Dimension
134×88×54mm
134×88×52mm
165×90×53mm
165×90×51mm
165×90×68mm
165×90×66mm
185×72×25mm
Model
S-8082A
S-8082S
S-8110A
S-8110S
S-8180A
S-8180S
S-8073N
Mount Type
Gold Mount
V-Mount
Gold Mount
V-Mount
Gold Mount
V-Mount
NP-1
Nominal Voltage
14.4V
14.4V
14.4V
14.4V
14.4V
14.4V
14.4V
Mass
710g
710g
940g
940g
1280g
1280g
450g
Max output
