Sida 1/4
GO GUITAR
Portable Guitar Interface for Mobile Devices
Plug the attached cable into your device’s
headphone input or lightning adapter.
Plug a pair of headphones into the
headphone input.
Connect a guitar or bass via an instrument
cable with a ¼" TS plug.
Connect an amplier to the amp output via an
instrument cable with a ¼” TS connector.
Move the THRU/FX switch to the FX position to
hear the processed guitar or bass sound from
the app in your mobile device.
While playing your guitar or bass, turn up the
GAIN wheel until you get the optimum input level
for the app in your mobile device.
Download your favorite TC Helicon app to
begin experimenting with guitar and bass eects.
Left
Right
Ground
Mic
Quick Start Guide
Getting started
Specications
Analog Connections
Guitar 1 x ¼" TS mono, unbalanced
Impedance 400 k
Headphones 1 x ⁄" TRS stereo
Amplier out 1 x ¼" TS mono, unbalanced
Controls
Gain
0 to +16 dB, adjustable
Routing Thru / FX, switchable
System
Frequency response 20 Hz to 20 kHz, +0/-2 dB
Dynamic range > 100 dB
S/N ratio > 88 dB
Dimensions / Weight
Dimensions
(H x W x D)
92 x 45 x 27 mm
(3.6 x 1.8 x 1.1")
Weight 0.07 kg (0.15 lbs)
FEDERAL COMMUNICATIONS
COMMISSION COMPLIANCE
INFORMATION
Responsible Party Name: Music Tribe Brands UK Ltd.
Address: Klark Industrial Park,
Walter Nash Road,
Kidderminster.
Worcestershire, DY11 7HJ England
Phone Number: +44 1562 741515
GO GUITAR
This equipment has been tested and found to comply with the limits for a ClassB digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
TC Helicon
GO GUITAR
Music Tribe accepts no liability for any loss which may be suered by any person who relies
either wholly or in part upon any description, photograph, or statement contained herein.
Technical specications, appearances and other information are subject to change without
notice. All trademarks are the property of their respective owners. Midas, Klark Teknik,
Lab Gruppen, Lake, Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera
and Coolaudio are trademarks or registered trademarks of Music Tribe Global Brands Ltd.
© Music Tribe Global Brands Ltd. 2018 All rights reserved.
For the applicable warranty terms and conditions and additional information regarding
Music Tribe’s Limited Warranty, please see complete details online at musictribe.com.
LEGAL DISCLAIMER
LIMITED WARRANTY
