Digalox® DPM72-MPP/MPPA/MPPV-DIN
Instruction manual (Rev-2023-03)

Package contents:  !
1. Safety instructions
•"#      $  %    &  #'(  )    
*
•#%#%$%$+##
$*
•When working on the device hazardous voltages must not be connected to
the device! The terminals J1-J12 are not isolated from the measuring
circuit.
•The device must not be used as the only protective device or protective
shutdown.
•,&#'##&*-
#' % #   $ $ ./&
*!*
•0&/&&12.13$/&%#
/&'/&
'*4/&56789/&%#
:678*
•&&(
•&#'&'%%(
•%$&;#'%#/&*
2. Meaning of symbols
</
%'&#(!
0&;#
..... ..... 1 / 8
3. Intended use
•Measurement of current, voltage, power and frequency in the specified measuring
ranges.
•Indoor use non condensing, non corrosive.
•Mounting on DIN rail or screwing on.
•Failure to comply with these instructions will void all guarantee and warranty.
4. Description
Depending on type the measurement modes analogue signal (2×) 0/2 to 10 V and/or
(2×) 0/4 to 20 mA AC/DC are supported. As individually adjustable threshold values
are reached, two galvanically isolated alarm outputs enable the device to perform
switch-on or switch-off operations.
Using the configuration software “Digalox
® Manager” the device can be configured,
e.g. thresholds for alarm output, hysteresis, and more.
Depending on the model, measured values can be transmitted via XBEE radio
technology or RS485 Modbus interface. In addition, the device features a counting
function with data retention. This enables operating-hours-counters or time-counters
for exceeding and falling below threshold values, as well as single pulse counting
(MPP) or double pulse counting (MPPV). The device can be mounted on DIN rails
as well as on other backgrounds through corresponding holes in the housing.
In the “Downloads” area of www.digalox.com you can find the latest version of the
instruction manual and the software “Digalox
® Manager”.
----- ----- 2 / 8
5. Product overview
3
2
5
4
1
1 2 optocoupler switch outputs
2 Jumper pins J1–J12
3 Supply voltage input
4 Interface (XBEE / RS485)
5 Measurement inputs
6. Mounting
Hook the device into the top-hat rail from above and then press it at the bottom until
the latch engages.
Alternatively, attach the device with 4 screws.
----- ----- 3 / 8
