Sida 1/5
Technaxx * User Manual
FMT1100BT Transmitter with Hands-free & Charging function
Receive phone calls directly from your mobile phone via Bluetooth and speak
through the hands free system
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device,
to which this user manual belongs, complies with the essential requirements of the
standards referred to the Directive R&TTE 2014/53/EU. The Declaration of Conformity you
find here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”). Before using
the device the rst time, read the user manual carefully.
Turn OFF nearby Bluetooth devices to avoid signal interference!
Service phone No. for technical support: 01805 012643 (14 cent/minute from German
fixed-line and 42 cent/minute from mobile networks). Free Email: support@technaxx.de
Features
Safe driving when making phone calls via the Bluetooth Hands-free system Easy
handling with 2 buttons Bluetooth V2.1 + EDR with ~10m transmission range Supports
MicroSD cards up to 32GB Supports AUX–IN DSP noise reduction & echo cancellation
for crystal clear voice quality Adjustable volume of the speaker LED status indicator
shows working mode, frequency, volume, etc. Simple fastening of the FM unit with a 3M
adhesive surface
Technical specifications
Bluetooth Bluetooth V2.1 + EDR with ~10m transmission range
Bluetooth protocol AVRCP V1.5, HFP V1.5, A2DP V1.3
Power supply DC 12–24V (cigarette lighter socket of a vehicle)
LED display size (L) 2.0 x (W) 0.8cm
Frequency range FM 87.5–108.0MHz, max. 5m
Frequency response 20Hz–15KHz
Music format MP3, WMA, WAV, FLAC
Storage MicroSD cards up to 32GB
USB port Charging 5V/2.1A max.
Material ABS
Weight / Dimensions 61g (FM unit with cable and charger) / Ø 5.7 x (Thickness)
2.8cm / Cable length FM unit to charger ~84cm
Package Contents FMT1100BT Transmitter, AUX–IN cable, User Manual
Compatibility: This device can be paired as a hands-free kit with any compatible
Bluetooth 2.1 or higher enabled devices.
Recommendation: Disconnect the FMT1100BT from the cigarette lighter socket
before starting the engine of the vehicle.
Product Overview
1 Display Shows working mode, frequency, volume, etc.
2 Rotary
Switch
Under music playback mode: short press of the button to play/
pause music; Rotation reverse/clockwise to go to the last/next track;
Rotation reverse/clockwise and hold to decrease/increase the
volume. Under Bluetooth mode: short press of the button to receive
or reject incoming calls.
3 MicroSD* card slot (*not included in delivery)
4 Microphone 5 AUX–IN entrance
6 Channel
Short press to enter frequency debug mode; frequency display
starts flashing slowly. Frequency range 87.5~108.0MHz. Rotation
reverse/clockwise of the Rotary Switch to decrease/increase
frequency point by 0.1MHz frequency point. Rotation
reverse/clockwise and hold the Rotary Switch to decrease/increase
the frequency quickly. When nished the testing frequency, short
press to enter the normal display mode.
Long press (under normal display mode) to switch to different
modes: Bluetooth (blu), MP3 mode (MicroSD card) or AUX–IN mode
(AUX).
7 Car charger indicator
8 Car charger USB connector
Insert the car charger into the car cigarette lighter charging port, after the display lights on,
user can adjust the FMT1100BT transmit frequency to match frequency of car FM or adjust
the car FM frequency to match the frequency of FMT1100BT.
MP3 MODE
When FMT1100BT is on, plug in MicroSD Card, the FMT1100BT will enter the music play
mode and you hear voice say “MP3 Mode”. Under this mode rotate the Rotary Switch (2)
reverse / clockwise to go to the last / next track. Rotate and hold the Rotary Switch (2)
reverse / clockwise to decrease / increase the volume.
Long press the Rotary Switch (2) to switch among different modes: “all cycle” (all songs
will be repeated), “single cycle” (selected song will be repeated); “random-cycle” (songs will
be played randomly).
Click the Rotary Switch (2) twice to switch among 6 different EQ modes: EQ0-Normal,
EQ1-Rock, EQ2-Pop, EQ3-Classic, EQ4-Jazz, EQ5-Country.
You can press CH (6) to switch the frequency; long press "CH (6)" to switch to the next
mode.
Press the Rotary Switch (2) to pause the track. Press again the Rrotary Switch (2) to
continue the playback of the track.
When you remove the MicroSD card you hear “Bluetooth waiting for pairing”.
Bluetooth mode (Connect the hands free system with a Smartphone)
For a successful Bluetooth connection between a mobile phone and the FMT1100BT,
first make sure that your Smartphone is Bluetooth capable.
Search with your mobile phone for Bluetooth enabled devices. Then choose the device
with the name “FMT1100BT” from the list. (When a password is required then use the
original password „ “). Now the Bluetooth connection will start. 0000
After a successful connection, you hear “Bluetooth connection successful”.
In case the Bluetooth connection fails, switch OFF the FMT1100BT and try again. After
switching to Bluetooth mode, Bluetooth works spontaneously, searching previous pairing
Bluetooth set. If the FMT1100BT fails to link, it starts pairing other Bluetooth devices. In this
case, turn on your Bluetooth device to search for the FMT1100BT. Car speaker music
streams by FMT1100BT after pairing successfully. When a call is incoming, you can
short/long press the Rotary Switch (2) to receive or reject it. After answering the call, short
press the Rotary Switch (2) to hang up, long press the Rotary Switch (2) to switch talking
between cell phone and device. Under this mode, you can press the CH (6) to switch the
frequency, long press CH (6) to switch to the next mode.
