Technaxx® * User Manual

Mini Bluetooth LED Beamer TX-132

The Declaration of Conformity for this device is under the Internet link:

www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before

using the device the rst time, please read the user manual carefully.

Service phone No. for technical support: 01805 012643 (14 cent/minute

from German xed-line and 42 cent/minute from mobile networks). Free

Email: support@technaxx.de

Keep this user manual for future reference or product sharing carefully.

Do the same with the original accessories for this product. In case of

warranty, please contact the dealer or the store where you bought this

product. Warranty 2 years

Enjoy your product * Share your experience and opinion on one of

the well-known internet portals.

Features

 Mini projector with a powerful 1800 lumen LED lamp, multimedia

player, 2x 2W stereo speakers & headphone output

 Connect your speakers via Bluetooth version 4.2

 Compensation of low light conditions

 Projection size 32”–176"

 Manual focus adjustment

 Low fan noise max. 54dB

 Long LED lifetime ~40000 hours

 Connectable with PC/notebook, tablet, smartphone, gaming

consoles Playback of video/photo/ audio les from 

USB/MicroSD/external harddisk

 Controllable via the remote control

Hints for Environment Protection: Packages

materials are raw materials and can be recycled. Do

not disposal old devices or batteries into the

domestic waste. Cleaning: Protect the device from

contamination and pollution. Avoid using rough,

coarse-grained materials or solvents/aggressive

cleaner. Wipe the cleaned device accurately.

Distributor: Technaxx Deutschland GmbH & Co.KG,

Kruppstr. 105, 60388 Frankfurt a.M., Germany

Product view & Functions

Menu Move up / Last le

Signal source Esc (exit)

V– (VOL) / Move left Indicator light

Lens Power button

Focus adjustment V + (VOL) / Move right

Keystone correction Move down / Next le

Power button: Press this button to shut on or o the device.

Volume plus and minus button: Press the two buttons to

increase or decrease volume. They can also be used in the menu

as selection and parameter adjustment.

Menu: Bring up the main menu or exit system.

Arrow keys: Move up, down, left or right in the menu options.

Signal source: Select the signal or an external video signal. It is

also usable as “play” button.

Lens: Rotate the lens to adjust the image.

Air outlet: Do not cover the air cooling openings during operation

to avoid burns.

Remote control & Functions

Power Switch OK

Menu Play / Pause

Select Signal Source Exit

Move Up / Last File Volume – (down)

Move Left / Backwards Volume + (up)

Move Right / Forward Mute

Move Down / Next File

 Between the remote control and remote control receiving host

window, do not put any items, In order to avoid blocking the signal.

 Point the remote control to the left side of the device or the

projection screen, to receive the Infrared Radiation.
