Sida 1/40

Technaxx® * User Manual

Security Premium Camera Set 10.1 - TX 29

Security Premium Camera Set 18.5 TX- 30

Important Hint regarding the user manuals:

All languages of the user manual are on the CD enclosed.

Warranty 2 years

Contents

1 Features ............................................................................................................................ 2

2. Package content .............................................................................................................. 3

3. Product Overview 3.............................................................................................................

4. Installation ........................................................................................................................ 6

4.1 How to install TX-29 & TX- 30......................................................................................... 7

4.2 Antenna installation ........................................................................................................ 7

4.3 Hard disk installation ...................................................................................................... 8

4.4 Add camera to -29/TX- TX 30 .......................................................................................... 9

5. Software Functions ........................................................................................................ 10

5.1 Split screen .................................................................................................................. 10

5.2 Video Manage .............................................................................................................. 10

5.4 Video playback ............................................................................................................. 15

5.5 Video backup ............................................................................................................... 20

5.6 Color adjust .................................................................................................................. 21

5.7 PTZ control (not for included cameras) ........................................................................ 21

5.8 Manual record .............................................................................................................. 22

5.9 Volume ......................................................................................................................... 22

5.10 Setup Wizard ............................................................................................................. 22

5.11 Fast network ............................................................................................................... 22

5.12 Add Camera ............................................................................................................... 22

5.13 Exit System ................................................................................................................ 22

6. Device Access ...............................................................................................................23

6.1 Access via LAN (local WEB Interface) ......................................................................... 23

6.2 Access via WAN ( global WEB Interface) ..................................................................... 24

6.3 Mobile application (Security Premium) ......................................................................... 25

7. Security Premium PC Client ..........................................................................................29

8. Advanced camera settings ............................................................................................. 32

9. Troubleshooting ............................................................................................................. 32

10. Specications ............................................................................................................... 33

11. Attachment ................................................................................................................... 34

The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device,

to which this user manual belongs, complies with the essential requirements of the

standards referred to the Directive . The Declaration of Conformity you R&TTE 2014/53/EU

nd here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”). Before using

the device the rst time, read the user manual carefully.

Service phone No. for technical support: 01805 012643 (14 cent/minute from German

xed-line and 42 cent/minute from mobile networks). Free Email: support@technaxx.de

If you drill a hole in the wall, please make sure that power cables, electrical cords and/or

pipelines are not damaged. When using the supplied mounting material, we do not take the

liability for a professional installation. You are entirely responsible to ensure that the

mounting material is suitable for the particular masonry, and that the installation is done

properly. When working at higher altitudes, there is danger of falling! Therefore, use

suitable safeguards.

Security Premium Camera Set 10.1" TX- 29

Security Premium Camera Set 18.5" TX-30

1. Features

  Recorder & Receiver & Monitor in one device Wireless transmission with 2.4GHz via

Plug & Play HD LCD monitor screen HD camera video resolution 1280x720 (720P)  

 Built- camera microphone for audio recording in PIR sensor with ~8m distance at day &

night  Push message via APP when motion is detected  Wireless camera connection with

up to 4 cameras (TX-29) & up to 8 cameras (TX-30) Windows split-screen function with 

real-time/routine/event surveillance Hard disk storage function & USB backup function 

Network operation via LAN cable connection  Mobile viewing via free iOS & Android APP

(Technaxx Security Premium) Easy monitoring via PC (PC Client software) Worldwide  

PC access (DDNS) [www.technaxxp2p.de]  IP66 camera protection class against waterjet

& dust

Hints for Environment Protection: Packages materials are

raw materials and can be recycled. Do not disposal old devices

or batteries into the domestic waste. Protect the Cleaning:

device from contamination and pollution (use a clean drapery).

Avoid using rough, coarse-grained materials or

solvents/aggressive cleaner. Wipe the cleaned device

accurately. Technaxx Deutschland GmbH & Distributor:

Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany

2. Package contents

TX-29: Monitor with Stand, AC/DC Adapter 12V/2A, Wall bracket & screws & dowels, HDD

bracket & screws, Antenna with AC/DC Adapter 12V/1A, Wall bracket & , Outdoor Camera

screws & dowels, Antenna, Waterproof end cap USB Mouse, Network Cable , General:

(2m), CD, User Manual, [*HDD not included]

TX-30: Monitor with Stand, AC/DC Adapter 12V/3A, Wall bracket & screws & dowels,

Antenna with AC/DC Adapter 12V/1A, Wall bracket & screws & dowels, , Outdoor Camera

Antenna, Waterproof end cap USB Mouse, Network Cable (2m), CD, User , General:

Manual, [*HDD not included]

3. Product Overview

The main use of the device is local on the display. The TX- & 29 TX-30 are recorder,

receiver and display in one device. They can be used for example as surveillance device.

TX TX-29 supports up to 4 cameras, -30 supports up to 8 cameras. Both need a HDD (not

included) for recording and push notications. The devices are supported by a local and a

global WEB interface as well as a APP which is available for Android and iOS (Security

Premium).
