Operating Instructions

Model No.

SH-MZ1200

RQT7230-3Y

DJ Mixer

Before connecting, operating or adjusting this product, please read the

instructions completely.

Please keep this manual for future reference.

This manual was printed with soy based ink.

The photograph shows the silver model.

RQT7230

Dear customer

Thank you for purchasing this product.

For optimum performance and safety, please read these instructions

carefully.

Table of contents

Supplied accessories ................................................................... 2

IMPORTANT SAFETY INSTRUCTIONS ....................................... 3

Product service ............................................................................. 4

Main features ................................................................................ 4

Component part names ............................................................... 5

Connections .................................................................................. 7

Output side connections ............................................................ 7

Input side connections ............................................................... 8

Mixing (Basic operations) ........................................................... 9

Using the microphone .............................................................. 10

Recording and playing on external equipment ........................ 10

Additional mixing operations .................................................... 11

Adjusting the effect ................................................................... 11

Adjusting the monitor ................................................................ 11

Using play mode functions ....................................................... 12

Individually adjusting the left (L) and right (R) input ............... 12

Output separation (dual output separation) ............................ 12

Fader start function .................................................................... 13

Start using the channel fader ................................................... 13

Start using the cross fader ....................................................... 13

Block diagram ............................................................................. 14

Specifications ............................................................................. 15

Maintenance ................................................................................ 15

Troubleshooting guide............................................................... 15

Warranty (U.S.A.) ......................................................... Back cover

Supplied accessories

Please check and identify the supplied

accessories.

Use numbers indicated in parentheses when

asking for replacements parts.

In U.S.A. to order accessories, refer to

“Accessory Purchases” on back cover.

The model number and serial number of this product can be found

on either the back or the bottom of the unit.

Please note them in the space provided below and keep for future

reference.

MODEL NUMBER SH-MZ1200

SERIAL NUMBER

CAUTION!

DO NOT INSTALL OR PLACE THIS UNIT IN A

BOOKCASE, BUILT-IN CABINET OR IN

ANOTHER CONFINED SPACE. ENSURE THE

UNIT IS WELL VENTILATED. TO PREVENT

RISK OF ELECTRIC SHOCK OR FIRE HAZARD

DUE TO OVERHEATING, ENSURE THAT

CURTAINS AND ANY OTHER MATERIALS DO

NOT OBSTRUCT THE VENTILATION VENTS.

User memo:

DATE OF PURCHASE

DEALER NAME

DEALER ADDRESS

TELEPHONE NUMBER

AC power supply cord (K2CB2CB00006) ..................... 1

Note

The included AC power supply cord is for use with this unit only.

Do not use it with other equipment.

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR PRODUCT DAMAGE, DO NOT

EXPOSE THIS APPARATUS TO RAIN,

MOISTURE, DRIPPING OR SPLASHING AND

THAT NO OBJECTS FILLED WITH LIQUIDS,

SUCH AS VASES, SHALL BE PLACED ON THE

APPARATUS.

The lightning flash with arrowhead symbol, within

an equilateral triangle, is intended to alert the user

to the presence of uninsulated “dangerous voltage”

within the product’s enclosure that may be of suffi-

cient magnitude to constitute a risk of electric shock

to persons.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE SCREWS.

NO USER-SERVICEABLE PARTS

INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

The exclamation point within an equilateral triangle

is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in the literature accompanying the

appliance.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Although the AC power switch is in the “OFF” position, the

unit is not completely disconnected from the mains. Remove

the plug from the main electrical outlet if you will not be

using the unit for an extended period of time. Place the unit

so the plug can be easily removed.

RQT7230

Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions

listed below. Keep these operating instructions handy for future reference.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with

the manufacturer s instructions.’

8) Do not install near any heat sources such as radiators, heat reg-

isters, stoves, or other apparatus (including amplifiers) that pro-

duce heat.

9) Do not defeat the safety purpose of the polarized or grounding-

type plug. A polarized plug has two blades with one wider than

the other. A grounding-type plug has two blades and a third

grounding prong. The wide blade or the third prong are provided

for your safety. If the provided plug does not fit into your outlet,

consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particu-

larly at plugs, convenience receptacles, and the point where

they exit from the apparatus.

11) Only use attachments/accessories specified by the manufac-

turer.

12) Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused

for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way,

such as power-supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate normal-

ly, or has been dropped.

IMPORTANT SAFETY INSTRUCTIONS

CAUTION:

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules.

These limits are designed to provide reasonable protection

against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more

of the following measures:

ﾁReorient or relocate the receiving antenna.

ﾁIncrease the separation between the equipment and re-

ceiver.

ﾁConnect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

ﾁConsult the dealer or an experienced radio/TV technician

for help.

Any unauthorized changes or modifications to this

equipment would void the user s authority to operate this’

device.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation.

THE FOLLOWING APPLIES ONLY IN THE U.S.A.
