Smart Door/Window Sensor

User Manual

TLL331091

1. PRODUCT REVIEW

This Door/Window Sensor is a Wi-Fi, battery powered reed

sensor, including device part and magnet part. Working with

APP together in your mobile phone, once the state changing

(close or open) detected, the device will wake up the Wi-Fi

connection to Wi-Fi router, send an alarm signal to your mobile

phone via Wi-Fi network, in the case that the APP internet is

available locally or remotely. The alarm is selectable as a

notiﬁcation on your mobile phone with bar display, banner with

tone, vibration based on the APP Notiﬁcation setting on your

Mobile Phone. There is an around 5-second delay from the

state changes to notiﬁcation on your mobile phone depending

on the internet connection quality.

Besides working with APP, this device is compatible with

Amazon Alexa and Google Home.

This device can be installed on Door, Window and Drawer,

which one part is the frame and the other part can be moved.

2. PRODUCT FEATURES

• Working in 802.11 b/g/n 2.4GHz wireless network

(no hub required);

• Wi-Fi network conﬁguration with EZ (Smart Conﬁg)

and AP(Access Point) mode;

• Powered by 2xAAA battery for lasting 6 months depending

on alarm frequency;

• Real state (open/close) monitor in APP;

• Notiﬁcation with Open/Close, Tampered and Low battery

(less than 10%);

• Enable/disable notiﬁcations on Open/Close, tampered,

low battery event in APP;

• Indicate the battery level in APP;

• Open/Close history record;

• Share device in family;

• Dual color LED status indicator;

• Mounting with adhesive tape or screw;

• Works with Amazon Alexa, Google Home;

How to Get the device working:

• Make sure your Wi-Fi network work in 802.11 b/g/n

2.4GHz and internet available;

• Download the APP from Apple store or Google Play;

• Register an account in APP and login with your

email address or Mobile phone number;

• Setup the device Wi-Fi connection;

• Mount device on speciﬁed location;

• Test and check the Device and APP working state;

• Check working with Alexa and Google Home if necessary;

3. PRODUCT DESCRIPTION

This main device components are showing as following:

1) Latch button: press the Latch button to take apart the

battery cover from the device part in order to change the

batteries or setup the Wi-Fi network.

2) Button: Long press for 5 seconds this button to enter the

Wi-Fi network mode. Switch between EZ mode and AP mode

by long press the button more than 5 seconds.

3) Tamer button: Loose this button will trigger a

tempered Alarm to Mobile Phone;

4) LED indicator: indicate the device working state:

• Fast blinking in Red: EZ mode (Smart conﬁg) for

Wi-Fi conﬁguration;

• Slow blinking in Red: AP Mode for Wi-Fi conﬁguration;

Lock button LED Button Tamper button

Device Part

Magnet Part
