Step Fader mkII

Step Fader mkII it’s a ‘hands on’ eurorack dual sequencer, featuring two 8 step lines or one with 16 steps plus

quantizer, slew limiter, internal clock generator, CV inputs to control several parameters and more…

Each sequencer has independent settings for the play mode, start point, length, clock divider, transposition

and duty cycle.

The 2 channels of the quantizer can be used for processing external signals, and the same applies for the slew

limiter.

There are also 16 presets to store & recall all the sequencer settings.

The range of the sequencers is 5V approx, and the sum output (CV 1+2) is about 10V.

INPUTS

● clock input for sequencer 1 (normalized to CLK 2)CLK 1

● reset input for sequencer 1RESET 1

● input for quantizer 1, range 0 to +10 voltsQIN 1

●SLW IN input for the slew limiter 1

● CV input for modulationCV IN 1

● CV input for modulationCV IN 2

● input for slew limiter 2SLEW IN

● input for quantizer 2, range 0 to +10 voltsQIN 2

● reset input for sequencer 2RESET 2

● clock input for sequencer 2CLK 2

OUTPUTS

● clock output for sequencer 1CLK 1

● gate & trigger 1 outputG/T 1

● quantizer 1 output (V/OCT)VOCT 1

●SLW 1 slew limiter 1 output

● sum of both CVs (taken from both slew outs)CV 1 + 2

● sum of both G/T outputs (aka OR)GT 1+2

● slew limiter 2 outputSLEW 2

● quantizer 2 output (V/OCT)VOCT 2

● gate & trigger 2 outputG/T 2

● clock output for sequencer 2CLK 2

FUNCTION BUTTON AND KEYPAD MODES

The 16 illuminated buttons can be used to set several parameters, even to play the sequencer as a keyboard.

Clicking on the button will make the keypad blink, clicking again on one of the 16 illuminated buttonsFUNCT

will select the overall behavior (aka ).key modes

The selected will remain active, with the exception of ‘LOAD’ and ‘SAVE’. For those ones, thekey mode

previous key mode will be recalled after loading or saving the actual state of the sequencer.

G/T

Gate / Trigger mode (long press will set gate, short set trigger)

MAIN

sets the ‘Main Setup’ of the module (dual, parallel, single)

LOAD

load preset

SAVE

save preset

SCALE

set the scale for the quantizer of both sequencers

REC

record mode

CV IN 1

set the destination for the CV input 1

CV IN 2

set the destination for the CV input 2

SLIDE

quantizer will do a slide when a step is active

MODE

set the play mode of each sequencer

START

set the starting step of each sequencer

SIZE

set the length of sequencer

DIV

set the clock divider of each sequencer

KEY

use the keypad to play like a sort of keyboard

TRNSP

set the transposition of each quantizer (from -19 to +19 semitones)

DUTY

set the duration of the triggers (from 5 milliseconds to ⅞ of the step length)
