Technical description and instruction manual

Ultra-compact 5.1 AV Receiver with Wireless Technology

CoreStation

3 • CoreStation

Notice

The information in this document may change without

prior notice and in no way constitutes any liability on

the part of Lautsprecher Teufel GmbH.

No part of these instructions may be reproduced in

any form or be broadcasted in any way electronically,

mechanically, by photocopy or recording without the

written permission of Lautsprecher Teufel GmbH.

Version 2.0

February 2016

Trademarks

® All trademarks are the property of their respective

owners.

Manufactured under license from

Dolby Laboratories. “Dolby”, “Pro

Logic” and the double D symbol are

trademarks of Dolby Laboratories.

Manufactured under license un-

der U.S. Patent Nos: 5,956,674;

5,974,380; 6,487,535 & other U.S. and worldwide

patents issued & pending. DTS, the Symbol, & DTS

and the Symbol together are registered trademarks

& DTS Digital Surround and the DTS logos are trade-

marks of DTS, Inc. Product includes software. © DTS,

The HDMI and High-Definition

Multimedia Interface symbols

as well as the HDMI logo are trademarks or registered

trademarks of HDMI Licensing LLC in the USA and

other countries.

The Bluetooth® word mark and

logos are registered trademarks

owned by Bluetooth SIG, Inc. and any use of such

marks by Lautsprecher Teufel GmbH is under license.

Other trademarks and trade names are those of their

respective owners.

panies.

The aptX® mark and the aptX logo

are trademarks of CSR plc or one of

its group companies and may be registered in one or

more jurisdictions.

General Notes and Information

Original packaging

If you wish to exercise your eight-week right of re-

turn, we ask that you be absolutely sure to hold onto

the packaging. We can only accept the return of the

speakers WITH THE ORIGINAL PACKAGING.

Empty boxes are not available!

Complaints

In case of complaint we will need the following infor-

mation to process your enquiry:

1. Invoice number

Can be found on the sales slip (enclosed with the

product) or on the order confirmation received as a

PDF document, e.g. 4322543

2. Serial number or batch number

Located on the back of the device,

e.g. serial no.: KB20240129A-123.

Thank-you for your support!

Contact

Please contact our customer service with any ques-

tions, suggestions or criticism:

Lautsprecher Teufel GmbH

Bikini Berlin

Budapester Str. 44

10787 Berlin

Phone 00800 - 200 300 40 (toll-free)

Fax: +49 (0)30 / 300 930 930

E-Mail: service@teufelaudio.com

www.teufelaudio.com

Proper use

Only use the CoreStation as described in these oper-

ating instructions. Any other use will be deemed as

not in accordance with the instructions and may lead

to damage of property or even persons.

The manufacturer accepts no liability for damage

caused by use not in accordance with the instruc-

tions.

The CoreStation is intended for domestic use.

6 • CoreStation

Explanation of Symbols

Protection class II

Dual insulation

Risk of electrical shock – do not open the

housing.

Disconnect the mains cable before chang-

ing a fuse.

Old devices must not be disposed of

with household waste!

If the device is no longer operational, every

consumer is required by law to dispose

of old devices separately from household

waste, e.g. at a collection point run by

the communal authority/boroughs. This

ensures that old devices are recycled in

a professional manner and also rules out

negative consequences for the environ-

ment.

For this reason, electrical equipment is

marked with this symbol.

Batteries and storage batteries do not

belong in the household garbage!

Every consumer is required by law to bring

all batteries and storage batteries, regard-

less whether they contain harmful sub-

stances*) or not, to a collection point run

by the communal authority or borough or to

a retailer, so that they can be disposed of

in an environmentally friendly manner.

Please only turn in batteries and storage

batteries which are empty!

*) labelled with: Cd = cadmium, Hg = mer-

cury, Pb = lead
