TFA 35.1078.10.IT Bruksanvisning
TFA
Väderstation
35.1078.10.IT
Läs nedan 📖 manual på svenska för TFA 35.1078.10.IT (18 sidor) i kategorin Väderstation. Denna guide var användbar för 15 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/18
21
Stand
LCD
Display
Function
keys
WEATHER STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this state-of-the-art weather station as an
example of innovative design and quality piece of engineering. Providing radio
controlled time, date, calendar, Moon phase, indoor and outdoor temperature,
indoor and outdoor relative humidity, and air pressure history information. This
unit will never keep you guessing on current and future weather conditions.
Operation of this product is simple and straightforward. By reading this operating
manual, the user will receive a better understanding of the Weather Station
together with the optimum benefit of all its features.
FEATURES:
The Weather Station
• DCF Radio controlled time with manual setting option
• Time reception ON/OFF (user selectable)
• 12/24 hour time display
• Time zone option ±12 hours
• Weekday and day calendar display (year and month only in setting mode)
• Weather forecasting with weather tendency indicator
Battery
compartment
Hanging hole
22
• Temperature display in ºC/ºF
• Indoor and outdoor temperature display with MIN/MAX records and time of
reception
• Humidity data display as RH%
• Indoor and outdoor humidity display with MIN/MAX records
• Relative air pressure hPa/ inHg with adjustable reference value
• Weather icon sensitivity setting
• Relative air pressure history for the past 24 hours (electronic barometer
with barometric pressure trend)
• LCD contrast selectable
• Wireless transmission at 868 MHz
• Signal reception intervals at 4 seconds
• Can receive up to 3 outdoor transmitters
• Low battery indicator
• Table standing or wall mounting
Thermo-Hygro Transmitter
• Remote transmission of outdoor temperature and humidity
to Weather Station by 868MHz
• Shower proof casing
• Wall mounting case
• Mounting at a sheltered place. Avoid direct rain and
sunshine
TO INSTALL AND REPLACE BATTERIES IN THE WEATHER
STATION
The Weather Station uses 3 x AA, IEC LR6, 1.5V
batteries. To install and replace the batteries,
please follow the steps below:
1. Insert finger or other solid object in the space
at the bottom center of the battery
compartment and lift up to remove the cover.
2. Insert batteries observing the correct polarity
(see marking).
3. Replace compartment cover.
23
TO INSTALL AND REPLACE BATTERIES IN THE THERMO-HYGRO
TRANSMITTER
The outdoor Thermo-hygro transmitter uses 2 x AA IEC LR6,
1.5V batteries. To install and replace the batteries, please follow
the steps below:
1. Remove the battery cover at the front side with a small
screwdriver.
2. Insert the batteries, observing the correct polarity (see
battery compartment marking).
3. Replace the battery cover on the unit.
Note:
In the event of changing batteries in any of the units, all units need to be reset by
following the setting up procedures. This is due to a random security code
assigned by the transmitter at start-up. This code must be received and stored by
the Weather Station in the first 3 minutes of power being supplied to the
transmitter.
BATTERY CHANGE:
It is recommended to replace the batteries in all units on an annual basis to
ensure optimum accuracy of these units.
Please participate in the preservation of the environment. Return
used batteries to an authorized depot.
SETTING UP
WHEN ONE TRANSMITTER IS USED
1. First, insert the batteries in the transmitter (see “How to install and
replace batteries in the Termo-hygro outdoor transmitter ” above).
2. Within 2 minutes of powering up the transmitter, insert the batteries in the
Temperature Station (see “How to install and replace batteries in the
Weather Station ” above). Once the batteries are in place, all segments of
the LCD will light up briefly. Following the indoor temperature/humidity and
the time as 0:00 will be displayed. If these information are not displayed on
the LCD after 60 seconds, remove the batteries and wait for at least 60
seconds before reinserting them. Once the indoor data is displayed user
may proceed to the next step.
3. After the batteries are inserted, the Weather station will start receiving data
signal from the transmitter. The outdoor temperature and humidity data
should then be displayed on the Weather station. If this does not happen
after 2 minutes, the batteries will need to be removed from both units and
reset from step 1.
4. In order to ensure sufficient 868 MHz transmission however, the distance
Produktspecifikationer
| Varumärke: | TFA |
| Kategori: | Väderstation |
| Modell: | 35.1078.10.IT |
