Sida 1/17

LCD

Display

WIRELESS 868 MHz WEATHER STATION

Instruction Manual

INTRODUCTION:

Congratulations on purchasing this Weather Station with wireless 868

MHz transmission of outdoor temperature and display of indoor

temperature, weather forecast icons and weather tendency indicators. It

is further featuring a DCF-77 radio controlled clock and alarm function.

With four easy to use function keys, this innovative product is ideal for

use in the home or office.

FEATURES:

The Weather station

•

DCF-77 Radio controlled time function with manual time setting

options

•

DCF time reception ON/OFF

Function keys

Foldout stand

Battery

compartment

cover

Hanging hole

•

24 hour display

•

Alarm function with snooze

•

Time zone +/- 12 hours

•

Temperature display in degree Celsius (°C)

•

Indoor and outdor temperature with MIN/MAX records

•

Manual reset of MIN/MAX records

•

3 weather forecast with weather tendency indicator

•

Wireless transmission at 868 MHz

•

Signal reception intervals at 4 seconds

•

Low battery indicator

•

Wall mounting or table standing (foldout stand)

The Outdoor Temperature Transmitter

•

Remote transmission of outdoor

temperature to Weather station by 868

MHz signals

•

Shower proof casing

•

Wall mounting and table-standing

SETTING UP:

Note: This weather station receives only one outdoor transmitter.

1. First, insert the batteries into the Temperature transmitter. (see

“ “). Install and replace batteries in the Temperature transmitter

2. Immediately after and within 30 seconds, insert the batteries into

Weather station (see “Install and replace batteries in the

Weather station”). Once the batteries are in place, all segments of

the LCD will light up briefly. Following the time as 0:00 and the

weather icon will be displayed. If these are not displayed after 60

seconds, remove the batteries and wait for at least 30 seconds

before reinserting them.

3. After inserting the batteries, the Weather station will start receiving

data from the transmitter. The outdoor temperature and the signal

reception icon should then be displayed on the Weather station. If

this does not happen after 3 minutes, the batteries will need to be

removed from both units and reset from step 1.

4. In order to ensure sufficient 868 MHz transmission however, this

should under good conditions be a distance no more than 100

meters between the final position of the Weather Station and the

transmitter (see notes on “ ” and “ ”). Mounting 868 MHz Reception

5. Once the remote temperature has been received and displayed on

the Weather station, the DCF time (radio controlled time) code

reception is automatically started. This takes typically between 3-5

minutes in good conditions.

Note:

Daily DCF reception is done at 02:00 and 03:00 every day. If the

reception at 03:00 is not successful, then at 04:00 and 05:00 and 06:00

there are other tries, until one is successful. If the reception at 06:00 is

still not successful, then the next try takes place at 02:00 next day.

If reception is successful, the received time will override the manually set

time. (Please refer also to notes on “ ” DCF-77 Radio Controlled Time

and “ ”). Manual Time Setting

HOW TO INSTALL AND REPLACE BATTERIES IN THE WEATHER

STATION

The Weather Station uses 3 x AA, IEC LR6, 1.5V batteries. When

batteries will need to be replaced, the low battery icon will appear on the

LCD. To install and replace the batteries, please follow the steps below:
