Sida 1/14
19
WIRELESS 868 MHz WEATHER STATION
Instruction manual
Cat. No. 35.1121.IT
Thank you for choosing this instrument from TFA.
BEFORE YOU USE IT
Please be sure to read the instruction manual carefully.
This information will help you to familiarise yourself with your new device, learn all of its functions and parts,
find out important details about its first use and how to operate it and get advice in the event of faults.
Following the instruction manual for use will prevent damage to the device and loss of your statutory rights
arising from defects due to incorrect use.
We shall not be liable for any damage occurring as a result of not following these instructions.
Likewise, we take no responsibility for any incorrect readings and for any consequences which may
result from them.
Please take particular note of the safety advice!
Please look after this manual for future reference.
SCOPE OF SUPPLY:
•
Weather station (basic unit)
•
Outdoor transmitter
•
Instruction manual
FIELD OF OPERATION AND ALL OF THE BENEFITS OF YOUR NEW WEATHER STATION AT
A GLANCE:
•
24 hour time display (seconds displayed by pressing the button) SUN
•
Calendar Display: weekday, day and month (year only in setting mode)
•
Daylight saving time (DST) function selectable
•
Daily alarm function
•
Weather forecast with weather tendency indicator
•
Temperature display in degree Celsius (°C)
•
Indoor temperature display with MIN/MAX recordings
•
Outdoor temperature display with MIN/MAX recordings, time and date
•
All MIN/MAX temperature recordings can be reset
•
Indoor and outdoor relative humidity display in RH%
•
Display of relative or absolute air pressure in hPa
•
Relative air pressure with adjustable reference value
•
Relative air pressure history bar graph for the past 12 hours
•
Display of sunrise time, sunset time and sun duration in 150 European cities
•
Display of 8 symbols to represent the current moon phase
•
LCD contrast setting
•
Low battery indicators
•
Table standing or wall mounting
20
LCD
display
Function
buttons
FOR YOUR SAFETY:
•
The product is exclusively intended for the field of application described above. The product should
only be used as described within these instructions.
•
Unauthorised repairs, modifications or changes to the product are prohibited.
•
The product is not to be used for medical purpose or for public information, but is intended solely for
home use.
Caution!
Risk of injury:
•
Keep this instrument and the batteries out of reach of children.
•
Batteries must not be thrown into the fire, short-circuited, taken apart or recharged. Risk of explosion!
•
Batteries contain harmful acids. Low batteries should be changed as soon as possible to prevent
damage caused by a leaking battery. Never use a combination of old and new batteries together or
batteries of different types. Wear chemical-resistant protective gloves and glasses when handling
leaked batteries.
! Important information on product safety!
•
Do not expose the instrument to extreme temperatures, vibration or shock.
•
The outdoor transmitter is protected against splash water, but is not watertight. Choose a shady and
dry position for the transmitter.
ELEMENTS
The weather station
Thermo-hygro Transmitter
•
Remote transmission of outdoor temperature and humidity to weather station by
868MHz
•
Alternately display the outdoor temperature and humidity readings on LCD
•
Wall mounting case
•
Mounting at a sheltered place. Avoid direct rain and sunshine.
Battery
compartment
cover
Foldout
stand
Hanging hole
21
TO INSTALL AND REPLACE BATTERIES IN THE THERMO-HYGRO TRANSMITTER
The outdoor thermo-hygro transmitter uses 2 x AAA, IEC LR3, 1.5V batteries. When the
batteries need to be replaced, the low battery symbol will appear on the LCD of the outdoor
transmitter. To install and replace the batteries, please follow the steps below:
1. Remove the cover.
2. Insert batteries, observing the correct polarity (see marking).
3. Replace the battery cover on the unit.
TO INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION
The weather station uses 2 x C, IEC LR14, 1.5V batteries.
To install and replace the batteries, please follow the steps
below:
1. Remove the cover at the back of the weather
station.
2. Insert batteries, observing the correct polarity (see
marking).
3. Replace the compartment cover.
Battery replacement
•
Replace the batteries when the battery symbol of the weather station appears near the air pressure
display.
•
When the batteries of the transmitter are used up, the low battery icon appears above the outdoor
humidity display of the weather station.
Note:
In the event of changing batteries in any of the units, all units need to be reset by following the setting up
procedures. This is because a security code is assigned by the transmitter at start-up and this code must be
received and stored by the weather station in the first 3 minutes of power being supplied to it.
SETTING UP
Note: This weather station receives only one outdoor transmitter.
1. First, insert the batteries in the transmitter (see “To install and replace batteries in the thermo-
hygro transmitter ” above).
2. Within 30 seconds of powering up the transmitter, insert batteries in the weather station (see “To
install and replace batteries in the weather station ” above). Once the batteries are in place, all
segments of the LCD will light up briefly and a short signal tone will sound. Then the indoor
temperature, humidity and the time as 0:00 will be displayed. If this information is not displayed on the
LCD after 1 minute, remove the batteries and wait for at least 1 minute before reinserting them. Once
the indoor data is displayed user may proceed to the next step.
