Jurassic World: Dominion Flying Pterosaur - Quetzalcoatlus
Läs nedan 📖 manual på svenska för Thames & Kosmos Jurassic World: Dominion Flying Pterosaur - Quetzalcoatlus (2 sidor) i kategorin Modellbygge. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/2

1. Attach the le wing to the
back body piece by sliding the
holes in the wing over the pegs
on the back body piece.
2. Attach the right wing to the back body
piece by sliding the holes in the wing
over the pegs on the back body piece.
Insert the lower beak into the head
by pushing the ball into the socket.
4. Insert the base of the
neck into the slot on the
back body piece.
6. Place the front body piece
(with the motor facing
downward) onto the back
body piece, pushing all of
the pegs all the way into all
of the holes. Make sure the
wires t neatly into the
back body compartment.
5. Attach the propeller to
the end of the motor
sha and screw it in place
with the small, thin screw
(part 13).
Note: This is
the smallest
screw in the kit.
7. Screw in the four
small screws (part
14), securing the
body pieces
together.
8. Insert two AAA batteries (1.5-volt, type LR03) into the battery compartment.
Attach the battery compartment cover by rst inserting the tab into the slot in the
body, then pressing the cover gently into place, and nally screwing in the screw.
(The screw is already installed in the battery compartment cover.)
Please provide your child with assistance and support when assembling the ying
pterosaur model. The model must be installed by an adult and operated under adult
supervision. Before starting the assembly and installation, read through the manual
together and be sure to follow it. Please be careful not to let any parts of the kit get
into the hands of small children, especially the small parts and long cable.
ARNING! Not suitable for children under 3
ars. Choking hazard — small parts may be
allowed or inhaled. Strangulation hazard —
g cable may become wrapped around the
. This kit contains functional sharp edges or
s. Do not injure yourself!
ing: This toy is only intended for use by
en over the age of 6 years, due to accessible
nic components. Instructions for parents
or caregivers are included and shall be followed.
Keep packaging and instructions as they contain
important information.
Store the experiment material, particularly the
battery-powered motor and assembled model out
of the reach of small children.
Make sure the model is securely attached to the
ceiling before use.
Do not allow your hair, ngers, or other body
parts to come near the motor-driven propeller.
Safety for Experiments with Batteries
• To operate the models, you will need two AAA
batteries (1.5-volt, type LR03), which could
not be included in the kit due to their limited
shelf life.
• An adult should insert and change the batteries.
For instructions on how to insert and change
the batteries, see step 8.
• The batteries are to be inserted with the correct
polarity (+ and -). Press them gently into the
battery compartment.
• The supply terminals are not to be short-
circuited. A short circuit can cause the wires to
overheat and the batteries to explode.
• Dierent types of batteries or new and used
batteries are not to be mixed.
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Always close battery compartments with the
lid.
• Non-rechargeable batteries are not to be
recharged. They could explode!
• Rechargeable batteries are only to be charged
under adult supervision.
• Rechargeable batteries are to be removed from
the toy before being charged.
• Exhausted batteries are to be removed from the
toy.
• Dispose of used batteries in accordance with
environmental provisions, not in the household
trash.
• Be sure not to bring batteries into contact with
coins, keys, or other metal objects.
• Avoid deforming the batteries.
• Have an adult check the model before use to
make sure it is assembled properly. Always
operate the motorized model under adult
supervision. Aer you are done experimenting,
remove the battery from the battery
compartments.
Notes on Disposal of Electrical and Electronic
Components
The electronic components of this product are
recyclable. For the sake of the environment, do
not throw them into the household trash at the
end of their lifespan. They must be delivered to a
collection location for electronic waste,
as indicated by the following symbol:
Please contact your local authorities for
the appropriate disposal location.
With this kit, you will build and y a model of a pterosaur, an order of
prehistoric ying reptiles related to the dinosaurs. This specic
pterosaur is called the Quetzalcoatlus (pronounced “ket-suhl-kow-at-
luhs”). It was the largest ying animal of all time; a huge, bird-like
creature with a 36-foot wingspan, a massive beak, and erce talons. A
battery-powered motor propels your Quetzalcoatlus through the air
while a thin cable keeps it soaring along a circular ight path. Learn how
the propeller makes the model y, about the similarities between
pterosaurs and modern-day birds, and all about this awe-inspiring giant
of the prehistoric skies.
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS CONTINUED
DEAR PARENTS AND ADULT SUPERVISORS
SAFETY INFORMATION
YOUR OWN FLYING PTEROSAUR
FLYING PTEROSAUR
QUETZALCOATLUS
1
2
4
5
6
7
8
3
Tab
++
–
–
13
USA: support@thamesandkosmos.com
or 1-800-587-2872
UK: support@thamesandkosmos.co.uk
or 01580 713000
WWW.JURASSICWORLD.COM
© Universal City Studios LLC and Amblin
Entertainment, Inc. All Rights Reserved.
1st Edition 2022 Thames & Kosmos, LLC, Providence, RI, USA
Thames & Kosmos® is a registered trademark of Thames &
Kosmos, LLC. This work, including all its parts, is copyright
protected.
Distributed in North America by Thames & Kosmos, LLC.
Providence, RI 02903 Phone: 800-587-2872;
Web: www.thamesandkosmos.com
Distributed in United Kingdom by Thames & Kosmos UK
LP. Cranbrook, Kent TN17 3HE Phone: 01580
713000; Web: www.thamesandkosmos.co.uk
We reserve the right to make technical changes.
Printed in China
KIT CONTENTS
1. Le wing
2. Right wing
3. Back body piece
4. Front body piece
(with motor, switch,
and battery
compartment)
5. Propeller
6. Head
7. Lower beak
8. Battery
compartment
cover (with small,
at-head screw)
9. Ceiling bracket
10. Hanger
11. Hook
12. Cable
13. Small, thin
screw for
propeller
14. Small screws
for model (4)
15. Large screws
for ceiling (3) YOU WILL ALSO NEED
2 AAA batteries (1.5-volt, type LR03), small
Phillips-head screwdriver, large Phillips-head
screwdriver (preferably powered), scissors
Experiment Manual
TIP! Handle the motor circuit
assembly very gently. The soldered
connection points can break under
too much stress. Do not push or pull
on the wires. They might break o.
Do you have any questions?
Our tech support team will
be glad to help you!
9
1
13
14
15
4
5
2
11
10
7
6 3 8 12
14 x4

1. Determine a suitable place for installation. Make sure the
ceiling bracket is positioned far enough away from any
walls or other obstacles so that the pterosaur does not
crash into anything when it ies around in its circular path.
Your Quetzalcoatlus is ready to
y! Turn on the motor with the
switch, making sure to keep your
hands and other body parts away from
the propeller. Pull the pterosaur a little to
the side and then “throw” it in a clockwise
direction to start it along its circular path. The
pterosaur will propel itself around and around on a
circular path. It ies only clockwise. Make sure
nothing gets in its ight path at any time.
Pterosaurs were the rst ying vertebrates. Some were hardly bigger than a sparrow,
while others had a wingspan of up to 20 meters (66 feet). Their wings had no
embrane similar to that of a modern-day bat.
their head, the function of which is still
mably for steering. Their bones were hollow
but strengthened by bridges and
sponge-like structures — thus being
both light and strong.
All of the pterosaurs known today
were meat eaters. The smaller, tailed
types were presumably skilled yers,
able to catch lake and ocean sh in
ight with their sharp beaks. Others
stood in shallow water pecking on
crustaceans and mollusks.
2. Tie one end of the cable to the
hanger with at least three very
tight knots. 3. Guide the free end of the cable
through the hole in the ceiling bracket
and insert the hanger into the hole in
the center of the bracket.
5. Place the ceiling bracket in the
desired position on the ceiling
and with a large screwdriver
(preferably powered) screw in
the three large screws (part
15) to hold the bracket in
place. Make sure the bracket is
securely in place by tugging on
the cable.
4. Tie the other end of the cable to the
hook with at least three very tight knots.
Trim the loose ends with scissors.
6. Use the hook to connect the
cable to the loop on the back
of the pterosaur.
INSTALLATION INSTRUCTIONS TAKE TO THE SKIES!
HOW DOES IT WORK?
PTEROSAURS — FLYING PREHISTORIC CREATURES
HOW ARE PTEROSAURS LIKE BIRDS?
1
4
3
5
6
animals and plants that no longer exist
today. The dinosaurs became extinct
millions of years ago. But some traces of
their bodies, such as bones, skin
impressions, and footprints, have been
preserved in stone. These are called
fossils. Researchers dig up these
discoveries, study them, and compare
them to others. In this way, scientists
gured out about 200 years ago that
some of these fossil remains came from
enormous animals. Before then, people had thought they were the remains of
human-like giants!
IMPORTANT! An adult must fasten the ceiling bracket to the ceiling
to install the ying pterosaur before it can be used. Scan this QR
code for an installation and ying video.
2
The spinning propeller pushes the model
forward. Since the cable keeps the model
tethered to a central point, the model
cannot y o course; it stays ying in a
continuous circular motion.
To understand how propellers work, let’s
rst examine another common feature of
ying things: the wing. Wings generate a
liing force in air. Air is a mixture of gases.
The molecules in air are always moving
around and they are always being pulled
toward Earth by gravity. Air pressure is the
result of all these moving particles pushing
on each other and all the things under and
around them.
Air behaves like a uid and obeys the
physical laws of uids. To understand how
wings work, the most important principle
of uids to know is that the faster uids
move, the lower their pressure. This is
called Bernoulli’s principle aer the
scientist who came up with it. Airplane
wings are designed to take advantage of
Bernoulli’s principle to li a plane upward.
The cross section of a wing has a top
surface that is curved and therefore longer
than its bottom surface. Air owing over
the top has to travel farther, so it moves
faster. As Bernoulli’s principle states,
faster moving air has a lower pressure and
slower moving air has a higher pressure.
The high air pressure under the wing
pushes the wing upward and the low
pressure above sucks it upward. This is
called li. Li is always perpendicular to
the direction of the airow.
A propeller works like a spinning wing.
Imagine taking two (or more) wings,
sticking them on a central axis opposite
one another, and spinning the axis. The
wings would spiral through the air and
create low pressure in front of them and
high pressure behind them, and thus pull
the propeller forward. The wings
of a propeller, called blades, are
angled so they cut into the air more.
Just like they screw through the air,
propellers can also work in another uid:
water!
Wing cross
section
Low pressure
Li
Li
High pressure
Air ow
Propeller Propeller
from side
Axis
Spiral
You can stop it at any time by carefully catching the
cord, keeping your hand away from the propeller,
and turning o the motor with the switch.
Taller than a girae, with a wingspan as wide as a school
bus, the Quetzalcoatlus is the largest known ying creature
of all time. Like other pterosaurs, the Quetzalcoatlus had
wings that stretched from its ankles to its extremely long
fourth ngers. Some scientists believe that these massive
wings, along with hollow bones and a powerful launch
system, helped the Quetzalcoatlus y for thousands of
miles without stopping, while moving as fast as a car on the
highway. The Quetzalcoatlus had a large pointed skull and
big eye sockets, indicating that it was likely intelligent and
had good eyesight. Although its jaws were toothless, the
Quetzalcoatlus’s dominant size allowed it to pick up and eat
small animals while it was walking on land. The massive
ying creature and its descendants might be dominating
Earth’s skies today were it not for a single rock. The
Quetzalcoatlus is believed to have died out around 65
million years ago during the great Cretaceous-Tertiary — or
K-T — extinction, when much of the life on Earth was wiped
out aer a huge asteroid slammed into it.
You may have heard: birds descended from dinosaurs. While
this is true, and while birds and the Quetzalcoatlus share
some similarities, the creatures you see ying around
Earth today are not related to the Quetzalcoatlus. Birds
actually evolved from a group of two-legged dinosaurs
called theropods, which include the Tyrannosaurus
rex and smaller velociraptors. Unlike most birds
today, which are bipeds like theropods, the
Quetzalcoatlus was a quadruped, meaning it
walked on four limbs when on the ground. It is
believed that the Quetzalcoatlus was covered in a downy fur,
not feathers. While both types of creatures ew, the
Quetzalcoatlus likely didn’t do much wing apping, but
rather relied on soaring on wind thermals. But
Quetzalcoatlus did have something in common with birds:
both types of animals are warm-blooded, meaning their
bodies can generate heat internally, independent of the
outside temperature. Another key dierence: birds managed
to survive the K-T extinction of 65 million years ago, while
pterosaurs, including the Quetzalcoatlus, did not.
Clockwise!
556002-02-100222
15 x3
Produktspecifikationer
Varumärke: | Thames & Kosmos |
Kategori: | Modellbygge |
Modell: | Jurassic World: Dominion Flying Pterosaur - Quetzalcoatlus |
Behöver du hjälp?
Om du behöver hjälp med Thames & Kosmos Jurassic World: Dominion Flying Pterosaur - Quetzalcoatlus ställ en fråga nedan och andra användare kommer att svara dig
Modellbygge Thames & Kosmos Manualer
Modellbygge Manualer
- Modellbygge Lego
- Modellbygge Chicco
- Modellbygge Carson
- Modellbygge Voltcraft
- Modellbygge Viessmann
- Modellbygge Revell
- Modellbygge Playmobil
- Modellbygge BRIO
- Modellbygge Graupner
- Modellbygge ISDT
- Modellbygge Heller
- Modellbygge Multiplex
- Modellbygge Wilesco
- Modellbygge FABER CASTELL
- Modellbygge Marklin
- Modellbygge Kibri
- Modellbygge Mega Bloks
- Modellbygge KidKraft
- Modellbygge Geomag
- Modellbygge Baufix
- Modellbygge Reely
- Modellbygge Robbe
- Modellbygge LGB
- Modellbygge Woodland Scenics
- Modellbygge Snap Circuits
- Modellbygge BIG
- Modellbygge Discovery
- Modellbygge Quercetti
- Modellbygge Pocher
- Modellbygge Wiking
- Modellbygge Siku
- Modellbygge MBZ
- Modellbygge FALLER
- Modellbygge Seuthe
- Modellbygge Metal Earth
- Modellbygge E-Blox
- Modellbygge Piko
- Modellbygge Fleischmann
- Modellbygge Tams Elektronik
- Modellbygge Roco
- Modellbygge SAB Heli Division
- Modellbygge Proses
- Modellbygge Brawa
- Modellbygge NOCH
- Modellbygge Massoth
- Modellbygge Trix
- Modellbygge Italeri
Nyaste Modellbygge Manualer

2 April 2025

2 April 2025

2 April 2025

29 Mars 2025

24 Mars 2025

24 Mars 2025

4 Mars 2025

24 Februari 2025

23 Februari 2025

23 Februari 2025
