Tisira MTM65-P701PQ Bruksanvisning

Tisira tvättmaskin MTM65-P701PQ

Läs nedan 📖 manual på svenska för Tisira MTM65-P701PQ (12 sidor) i kategorin tvättmaskin. Denna guide var användbar för 5 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/12
MODEL:MTD65-P7501PO
Before using your washing machine, please read this
manual carefully and keep it for future reference.
Read This Manual
Inside you will find many helpful hints on how to
use and maintain your washing machine properly.
Just a little preventative care on your part can
save you a great deal of time and money over the
life of your washing machine. You'll find many
answers to common problems in the chart of
troubleshooting tips. If you review the chart of
troubleshooting tips first, you may not need to call
for service.
OWNER’S MANUAL
Twin Tub Washing Machine
●
Be sure to use plug that is properly grounded.
The maximum gradient of the supporting surface for the washing machine should not exceed 2 .º
Do not tear down electrical wires and components in the machine by yourself.
There are holes on the base for ventilation. These holes should not be blocked by foreign
objects (carpets, etc.).
Never connect the grounding wire with the live wire, or it may lead to an electric shock.
If the power cord is damaged, it must be replaced by a qualified person to avoid a hazard.
●Do not connect to the hot water supply.
●
●
●
●
●
●
After using, be sure to unplug the power plug.
If the following symptoms occur, please disconnect the power plug and perform
the following checks:
Check that the power supply is in good condition.
Check that the power plug is inserted properly.
●
●
● Check that the wash timer knob or the spin timer knob is not
in the "0" position.
Check that the drain hose is not laid too high.
Check that the drain hose is not froz en.
Check that the drain hose is not bloc ked by foreign matter.
●
●
●
Check that there are no coins or any other foreign objec ts
dropped into the wash tub.
●
Check that the washing machine is placed on flat, stable floor.
Check that clothes are evenly distributed in the spin tub.
Check that there are no washing materials or foaming debris
dropped into the outside of the spin tub.
●
●
●
The washing
machine does
not work.
The drain hose
does not work.
There is abnormal
noise during washing.
There is abnormal
noise and violent
vibration during
spinning.
Symptom Reason
MAINTENANCE
Main Technical Parameters
Capacity (dry Clothes)
Power Supply
Input Power
Maximum Time
Water volume
Maximum water pressure
Overall dimension
Net weight
Pump Input Power
Wash
6.5 kg
340W
15 min.
H: 59L M: 51L L: 39L
Spin
4.6kg
135W
5 min.
/
0.6Mpa
761x448x885(mm)
19.5kg
30W
240V/50Hz
Upper Drain System
Safety Precaution
Be sure to comply with the following to prevent damage to body and property of you and others:
The sign stands for “pay attention” , and the picture of specific items needs attention
shows in .
The sign stands for “forbid”, and the picture of specific items forbidden shows in .
The sign stands for “must do”, and the picture of specific items must be done
shows in .
-1-
SAFETY PRECAUTIONTABLE OF CONTENTS
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
！
Do not install the machine in
damp or rainy environment to
avoid electric shock, fire,
machine failure,or deformation.
Avoid dampness
Do not dismantle the machine
by yourself.
Forbid dismantling
Do not place inflammable
materials like burning candle,
mosquito incense, cigaret etc.
or heating source like electric
stove, calorifier etc. on the
machine.
Forbid
！
Warning
Attention To Installation
Lay upper drain hose
Installation site
Preparation Instructions
Reference of laundry quantity
corresponding to different capacities
Laundry volume and detergent
dosage reference
Name Of Pa rts
Accessories
Introduction Of Control Panel
Quick Start
Washing Method
Rinsing Method
Spinning Method
Efficiency Program
Special Features
Notes
Attention To Maintenance
Cabinet maintenance
Cleaning the lint filter
Anti-freezing protection
Operation when objects are
droppe d into outside of the spin tub
Main Technical Parameters
Safety Precaution
1
3
3
3
4
4
4
5
5
5
6
6
6
7
7
8
8
9
9
9
9
9
9
knowledge, unless they have been given supervision or experience and
instruction concerning u se of the appliance by a person responsible for
their safety.
This appliance is for indoor use only.
Children should be supervised to ensure that they do not play with the
appliance.
When choosing the water inflowing to wash tub or spin tub , please do not
move the water inlet valve during the process of water inflowing.
The new hose-sets supplied with the appliance are to be used and that
old hose-sets should not be reused.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
The openings must not be obstructed by a carpet.
If strong vibration occurs in time of spinning, open the spin cover
immediately. Make sure that the washing machine is placed on a flat and
stable floor ,and then adjust washing materials, distribute them evenly.
To do spinning and draining together, please spin for 1 minute before draining.
Do not wash or spin waterproof clothes or clothes that float easily to avoid
abnormal vibration or damage to the clothes.
back cover

Produktspecifikationer

Varumärke: Tisira
Kategori: tvättmaskin
Modell: MTM65-P701PQ
