Owner’s Manual

Este manual esta disponible en español en la página de Tripp Lite:

www.tripplite.com/support

Ce manuel est disponible en français sur le site Web de Tripp Lite :

www.tripplite.com/support

HDMI Over Cat5

Matrix Switch

Models: B126-2X2, B126-4X4

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

17-06-500-9333F8-EN.indd 1 7/10/2017 1:20:45 PM

Package Contents

Product Features

• B126-2X2 or B126-4X4 Local Transmitter Unit

• External Power Supply

(Input: 100-240V, 50/60 Hz, 0.5A Output B126-2X2: 5V 2A;

Output B126-4X4: 5V 3A)

• 3.5 mm to DB9 Adapter Cable

• Mounting Hardware

• Remote Control

• 5 ft. IR Extension Cable (B126-4X4 Only)

• Owner’s Manual

• Share multiple HDMI sources between multiple monitors

• Route any input to any output, or route the same input to multiple outlets

• Transmit a signal over one Cat5e/6 cable to a remote monitor up to

175 ft. away

• A B126-Series remote receiver is needed at each monitor

• For longer distances: Use a B126-1A0 or B126-1A0-WP-1 active

remote receiver to extend a 1080p @ 60 Hz signal up to 125 ft. from

the transmitter (or a 1080i @ 60 Hz signal up to 175 ft. from the

transmitter)

• For shorter distances: Use a B126-1P0 or B126-1P0-WP-1 passive

remote receiver to extend a 1080p @ 60 Hz signal up to 50 ft. from the

transmitter (or a 1080i @ 60 Hz signal up to 75 ft. from the transmitter)

• Use 24 AWG, Solid Wire Cat5e/6 cable, such as Tripp Lite’s

N202-Series, to achieve maximum distance and resolution

• Further expand the range and number of monitors by adding

B126-110 remote repeater units

17-06-500-9333F8-EN.indd 2 7/10/2017 1:20:45 PM

Product Features

• Add up to three repeaters on each channel of the matrix switch, for a

total of four displays per channel (an active remote receiver should be the

last unit in a channel)

• A 1080p @ 60 Hz signal can be extended up to 125 ft. for each repeater

added into a channel (or up to 175 ft. for a 1080i @ 60 Hz signal)

• Switch between inputs via pushbuttons, remote control, or RS-232 serial

• For model B126-4X4 only: Extend the remote control range, allow

discreet placement of the transmitter unit and maintain device switching

functionality with the included ﬁve-foot IR extension cable

• HDCP-compatible

• Mounting hardware included

• Plug-and-play; no software or drivers required

• Compatible with all operating systems

• Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule

purchases

Optional Accessories:

• B126-1A0 or B126-1A0-WP-1 – Active Remote Receiver Units

• B126-1P0 or B126-1P0-WP-1 – Passive Remote Receiver Units

• B126-110 HDMI Over Cat5 Extender – Remote Repeater Unit

• N202-Series Cat6 24 AWG, Solid Wire Patch Cables

• P568-Series High-Speed HDMI Cables

• P520-006 RS-232 Serial Extension Cable
