/// www.tscprinters.com
DA210/DA220 SERIES – Desktop Direct Thermal Bar Code Printer
COMPACT DESIGN
AFFORDABLE TOTAL COST OF OWNERSHIP
KEY FEATURES
High quality double-walled clamshell
design
6 inches per second print speed
64 MB SDRAM and 128 MB Flash
memory (DA220/DA320)
Easy media loading
USB 2.0 (High speed mode)
TSPL-EZ firmware emulates Eltron®
and Zebra® languages out of the box
Bluetooth 4.0
802.11 a/b/g/n (DA220/DA320)
ENERGY STAR® qualified
APPLICATIONS
Small Parcel Shipping
Mail Room Address and
Routing Labels
Shipping & Receiving
Entertainment and
Transportation Ticketing
Retail Point-of-Sale
File-Folder Labeling
/// www.tscprinters.com
TSC® is a trademark of TSC Auto ID Technology Co., Ltd.
TSC Auto ID Technology Co., Ltd. is an ISO 9001/14001 registered company.
© 2017 TSC Auto ID Technology Co., Ltd.
Product models and Specifications are subject to change without notice.
Contact your TSC sales representative for specific information.
DA210/DA220 SERIES – Desktop Direct Thermal Bar Code Printer
PRINTER MODEL DA210 DA310 DA220 DA320
Resolution 8 dots/mm (203 DPI) 12 dots/mm (300 DPI) 8 dots/mm (203 DPI) 12 dots/mm (300 DPI)
Printing method Direct Thermal
Max. print speed 152.4 mm (6”)/second 102 mm (4”)/second 152.4 mm (6”)/second 102 mm (4”)/second
Max. print width 108 mm (4.25”) 105.7 mm (4.16“) 108 mm (4.25”) 105.7 mm (4.16“)
Max. print length 2,286 mm (90“)
Enclosure Double-walled plastic
Physical dimension 172 mm (W) x 165 mm (H) x 195 mm (D)
6.77“ (W) x 6.50“ (H) x 7.68“ (D)
Weight 1.5 kg (3.31 lbs)
Label roll capacity 127 mm (5“) OD
Processor 32-bit RISC CPU
Memory • 8 MB Flash memory
• 16 MB SDRAM
• 128 MB Flash memory
• 64 MB SDRAM
Interface
• USB 2.0 (High speed mode)
• Internal Bluetooth (factory option)
• USB 2.0 (High speed mode)
• RS-232 (factory option)
• Internal Ethernet, 10/100 Mbps (factory option)
• USB host, for scanner or PC keyboard (factory option)
• Internal 802.11 a/b/g/n wireless (factory option)
• Internal Bluetooth (factory option)
• External Bluetooth (user option)
Power
External universal switching power supply
• Input: AC 100-240V, 50-60Hz
• Output: DC 24V, 2.5A, 60W
Operation switch, button,
LED 1 power switch, 1 feed button & 1 LED (3 colors: green, amber & red)
Sensors
• Transmissive gap sensor
• Black mark reflective sensor
• Head open sensor
Internal fonts • 8 alpha-numeric bitmap fonts
• Monotype Image® true type font engine with one CG Triumvirate Bold Condensed scalable font
Bar code
• 1D bar code
Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked,
GS1 DataBar, Code 11, China Post
• 2D bar code
PDF-417, Maxicode, DataMatrix, QR code, Aztec, MicroPDF417
Font and barcode rotation 0, 90, 180, 270 degree
Printer language TSPL-EZ (Compatible to EPL, ZPL, ZPL II)
Media type Continuous, black mark, fan-fold, notched (outside wound)
Media width 19 ~ 114 mm (0.7“ ~ 4.5“)
Media thickness 0.055 ~ 0.19 mm (2.16 ~ 7.48 mil)
Media core diameter 25.4 ~ 38 mm (1” ~ 1.5”)
Label length 10 ~ 2,286 mm (0.39“ ~ 90“)
Environment condition Operation: 5 ~ 40°C, 25 ~ 85% non-condensing
Storage: -40 ~ 60°C, 10 ~ 90% non-condensing
Safety regulation FCC Class A, CE Class A, RCM, CB, CCC, ENERGY STAR
®, KC, BIS, UL
Environmental concern Comply with RoHS, WEEE
Accessories
• Windows labeling software CD disk
• Quick start guide
• USB cable
• Power cord
• External universal switching power supply
Limited warranty
• Printer: 2 years
• Print head: 25 km (1 million inches) or 12 months which comes first
• Platen: 50 km (2 million inches) or 12 months which comes first
Factory options
• Internal Bluetooth • USB host, for scanner or PC keyboard
• Real Time Clock
• Internal Ethernet, 10/100 Mbps
• Internal 802.11 a/b/g/n wireless
• Internal Bluetooth
• RS-232 serial interface
Dealer options N/A • Peel-off module
• Guillotine cutter (full cut or partial cut)
User options
• External roll mount, media OD. 214 mm (8.4”) with
76.2 mm (3”) core
• External roll mount, media OD. 214 mm (8.4”) with
76.2 mm (3”) core
• External Bluetooth module (serial interface)
• KP-200 Plus keyboard display unit
• KU-007 Plus programmable smart keyboard
CORPORATE HEADQUARTERS
TSC Auto ID Technology Co., Ltd.
Tel: +886 2 2218 6789
E-mail: apac_sales@tscprinters.com
LI ZE PLANT
TSC Auto ID Technology Co., Ltd.
Tel: +886 3 990 6677
E-mail: apac_sales@tscprinters.com
AMERICAS
TSC Auto ID Technology America Inc.
Tel: +1 657 258 0808
E-mail: americas_sales@tscprinters.com
MEXICO
TSC Mexico Representative Office
Tel: +52 (33) 3165 7379
E-mail: americas_sales@tscprinters.com
BRAZIL
TSC Brazil Representative Office
Tel: +55 (11) 99597 8098
E-mail: americas_sales@tscprinters.com
EMEA
TSC Auto ID Technology EMEA GmbH
Tel: +49 (0) 8106 37979 00
E-mail: emea_sales@tscprinters.com
RUSSIA
TSC Auto ID Technology EMEA GmbH
Tel: +7 495249 9017
E-mail: emea_sales@tscprinters.com
MIDDLE EAST
TSC Auto ID Technology ME Ltd, FZE
Tel: +971 4 2533 069
E-mail: emea_sales@tscprinters.com
ASIA PACIFIC
TSC Auto ID Technology Co., Ltd.
Tel: +886 2 2218 6789
E-mail: apac_sales@tscprinters.com
INDIA
TSC India Representative Office
Tel: +91 2267 082 465
E-mail: apac_sales@tscprinters.com
KOREA
TSC Korea Representative Office
Tel: +82 2 852 3322
E-mail: apac_sales@tscprinters.com
CHINA
Tianjin TSC Auto ID Technology Co., Ltd.
Tel: +86 22 5981 6661
E-mail: apac_sales@tscprinters.com
