E6 OWNER'S MANUAL P. 2-8

BETRIEBSANLEITUNG S. 9-16

MODE D'EMPLOI P. 17-24

MANUALE D'USO P. 25-31

MANUAL DEL USUARIO P. 32-38

HANDLEIDING P. 39-45

BRUKSANVISNING S. 46-52

KÄYTTÖOHJE S. 53-62

www.tunturi.com

• SERIAL NUMBER • SERIENNUMMER

• NUMERO DE SERIE • NÚMERO DE SERIE

• NUMERO DI SERIE • SERIENUMMER

• SERIENNUMMER • SARJANUMERO

O W N E R ' S M A N U A L • E 6

IMPORTANT S A FET Y

INST RU C T IONS

Read this guide through carefully before assembling,

using or servicing your ﬁ tness equipment. Please

keep the guide somewhere safe; it will provide you

now and in the future with the information you need

to use and maintain your equipment. Always follow

these instructions with care. The equipment has

been designed for home use. The Tunturi warranty

applies only to faults and malfunctions in home use

(24 months). Please note that the warranty does not

cover damage due to shipping or negligence of

adjustment or maintenance instructions described in

this manual.

NOT E ABOU T

YOUR HEALT H

• Before you start any training, consult a physician

to check your state of health.

• If you experience nausea, dizziness or other

abnormal symptoms while exercising, stop your

workout at once and consult a physician.

• To avoid muscular pain and strain, begin each

workout by warming up and end it by cooling down

(slow pedaling at low resistance). Don’t forget to

stretch at the end of the workout.

NOT E ABOU T T HE

EXER C I S ING

ENVIRONMENT

• The equipment is not to be used outdoors.

• Place the equipment on a ﬁ rm, level surface. Place

the equipment on a protective base to avoid any

damages to the ﬂ oor beneath the equipment.

• Make sure that the exercising environment has

adequate ventilation. To avoid catching cold, do not

exercise in a draughty place.

• In training, the equipment tolerates an environment

measuring +10°C to +35°C. The equipment can

be stored in temperatures ranging between -15°C

and +40°C. Air humidity in the training or storage

environment must never exceed 90 %.

NOT E A BOUT U S ING

T HE EQUIPM ENT

• If children are allowed to use the equipment, they

should be supervised and taught to use the equip-

ment properly, keeping in mind the child’s physical

and mental development and their personality.

• Before you start using the equipment, make sure

that it functions correctly in every way. Do not use a

faulty equipment.

• Press the keys with the tip of the ﬁ nger; your nails

may damage the key membrane.

• Never lean on the interface.

• Never remove the side covers. Do not step on the

frame casing.

• Only one person may use the equipment at a

time.

• Hold the handlebar for support when getting on or

off the equipment.

• Wear appropriate clothing and shoes when

exercising.

• Protect the meter from sunlight and always dry the

surface of the meter if there are any drops of sweat

on it.

• The equipment must not be used by persons

weighing over 135 kg.

• Make sure the equipment is unplugged before car-

rying out any assembly or maintenance procedures.

• Do not attempt any servicing or adjustments other

than those described in this guide. Everything else

must be left to someone familiar with the mainte-

nance of electromechanical equipments and author-

ised under the laws of the country in question to

carry out maintenance and repair work.

• This product must be grounded. If it should mal-

function or breakdown, grounding provides a path

of least resistance for electric current to reduce the

risk of electric shock. This product is equipped with

a cord having an equipment-grounding conductor

and a grounding plug. The plug must be plugged

into an appropriate outlet that is properly installed

and grounded in accordance with all local codes

and ordinances.

DANGER:

Improper connection of the equipment-grounding

conductor can result in a risk of electric shock.

Check with a qualiﬁ ed electrician or serviceman if

you are in doubt as to whether the product is prop-

erly grounded. Do not modify the plug provided with

the product - if it will not ﬁ t the outlet, have a proper

outlet installed by a qualiﬁ ed electrician.

SAVE T H I S I N S T R U CT I O N M A N UAL

G B

O W N E R ' S M A N U A L

•

E 6

W E L C O M E T O T H E W O R L D

O F T U N T U R I E X E R C I S I N G !

Your choice shows that you really want to invest

in your well being and condition; it also shows

you really value high quality and style. With

Tunturi Fitness Equipment, you’ve chosen a high

quality, safe and motivating product as your

training partner. Whatever your goal in training,

we are certain this is the training equipment

to get you there. You’ll ﬁ nd information about

using your exercise equipment and what makes

for efﬁ cient training at Tunturi’s website at

W W W.T U N T U R I . C O M .

A S S E M B L Y

Start by unpacking the equipment and check that

you have the following parts:

1. Frame

2 . Rear support

3 . Plastic covers for front support (2)

4 . Handlebar / meter

5 . Heart rate transmitter belt

6 . Transformer

7. Assembly kit (contents marked with in the spare

part list): keep the assembly tools, as you may need

them e.g. for adjusting the equipment.

If necessary, please contact your dealer with the

model, equipment serial no. and spare part no.

of the missing part. You’ll ﬁ nd a spare part list at

the back of this guide. The packaging includes a

silicate bag for absorbing moisture during storage

and transportation. Please dispose of the bag once

you have unpacked the equipment. The directions

left, right, front and back are deﬁ ned as seen from

the exercising position.

S U P P O R T S

Place the rear support under the frame and fasten

it with two hex screws and washers. Tilt the cycle

back so that it rests on the rear support and seat.

Push the plastic covers into place at the ends of

the front support. Turn the cycle back to upright

position.

H A ND L E BA R

Expose the wire coming from the frame tube

by unwrapping the tape that covers it, and then

connect it to the counterpart in the handlebar

support tube. Ensure that the joint is securely

locked by gently pulling the wire. Thread the wire

carefully inside the frame tube and push the

handlebar support tube into place inside the frame

tube, so that the fastening screws are on the front

of the tube.

N O T E ! Use the enclosed Allen key to tighten both

fastening screws through the holes in the tube.

Tighten the fastening screws by turning them

counter-clockwise.

T R ANS F O RM E R

Before connecting the equipment to a power

source, make sure that local voltage matches that

indicated on the type plate: the equipment operates

at either 230 V or 115 V (North American

version). Plug the socket end of the transformer

cord into the connector, just above the rear support

in the center of the frame, and the other end into

the wall socket.
