www.tunturi.com 4 in 1 Strength Station Owner’s Manual
Record Serial Number Here
Platinum by Tunturi
www.Tunturi.com
Date of Purchase
Owner’s Manual
September 2010
Revision 0
Upper Body Unit
PG6241說明書101025 拚版用-16.indd 1-2 2010/11/3 20:16:40
Platinum by Tunturi 2 4 in 1 Strength Station Owner's Manual
__________ Page
Instructions 2
Parts Listing 3-4
Hardware Comparison 5-8
Main Frame Assembly 9-13
Cable Routing 14-17
Upholstery 18
Functional Arm Option 19
Congratulations on the purchase of your new 4 in 1 Strength Station. This gym will provide you with a lifetime of enjoyment
to meet your strength training needs. Platinum by Tunturi strives to build the best quality multi-station gyms and to package these
gyms in such a way to avoid any damage during shipping.
In order to get started with your assembly you should first familiarize yourself with this manual. It is recommended that you
read through each step thoroughly before you begin. Begin by opening your boxes and separating all of your parts. Verify that all
parts are accounted for and have no damage. When all parts are accounted for, you may begin your assembly. Some items may
have been pre-assembled for your convenience. Please note that and hardware quantities shown reflect total quantities for your gym
may not reflect actual quantities in each bag. Assemble your gym on a solid level surface. This will ensure the best possible perform-
ance, function, and safety for the gym and your workout.
Assemble your gym according to the step by step instructions found in this manual. Failure to do so will void your warranty
and may result in personal injury. After assembly, you should check each station to ensure correct operation. If a problem arises,
recheck your assembly with these instructions to verify correct assembly. If you are unable to correct a problem or have questions
with your assembly please contact your authorized Tunturi dealer.
Platinum by Tunturi has built this gym to give you a safe, effective and enjoyable workout. However, there
is a risk assumed by individuals who use this type of equipment. It is very important that all warnings and
instructions are read and followed before beginning any exercise program.
It is also very important to read and follow the preventative maintenance schedule described in this
manual. If any of the warning labels or stickers are worn, faded, torn, scratched or missing they should be replaced
immediately.
WARNING: There is a risk assumed by individuals who use this type of equipment. To minimize risk
always follow these rules.
1) It is essential that you consult with your physician before beginning any exercise program.
2) Inspect equipment before each use for loose, worn, or frayed parts (including cables, nuts and bolts). Replace
parts at first signs of wear (use only genuine TUNT Use of equipment that is URI replacement parts).
damaged, worn, frayed or not completely assembled on a solid, level surface may result in injury.
3) Make sure all adjustment pins are fully engaged before using equipment.
4) Keep all parts of the body and clothing outside the path of any moving parts of the gym. Be alert to the
possibility of injury. Do not be careless.
5) Minors and children should not be allowed to play on or around this gym.
6) If you have any questions on proper use or maintenance of this gym, do not hesitate to call your local
PLATINUM BY TUNTURI distributor or PLATINUM BY TUNTURI at www.Tunturi.com
__________ Page
Functional Arm Cable Routing 20-21
Weight Stack Decals and Serial Number 22
Cable Tension, Adjustments, and Comparison 23-25
Final Assembly and Troubleshooting 26
Maintenance 27
Floor plan Layout 28
Contact 29
Table of Contents
Instructions
Warning
PG6241說明書101025 拚版用-16.indd 3-4 2010/11/3 20:16:40
www.tunturi.com 3 4 in 1 Strength Station Owner’s Manual
ITEM NO. DESCRIPTION QTY
1 1 Right Vertical Support
2 1 Rear Base
3 1 Middle Frame Assembly
4 1 Front Base Support
5 2 Top Swivel Pulley Holder
6 1 Left Vertical Support
7 1 Top Weight Plate
8 Shroud 2
9 1 Guide Rod Holder
10 2 Guide Rod
11 19
Weight Stack Plate
12 2 Rubber Donut
13 Right Swing Arm Assembly 1
14 Left Swing Arm Assembly 1
15 Right Press Arm Assembly 1
16 1 Left Press Arm Assembly
17 1 1” Arm Shaft
18 Spacer 1
19 1 Seat Frame Assembly
20 Back Chrome Adjustment 1
21 1 8” Telespar
22 1 10” Chrome Adjustment
23 Axle 1
24 Press Arm Cable Lockout 1
25 1 Criss-Cross Free Floater
26 2 Free Floater
27 2 4-1/2” Pulley Cover
28 6 1-1/4” Pulley Spacer
29 8 3-1/2” Pulley Cover
30 Middle Frame Connector Plate 2
Accessories
Upholstery
ITEM NO. DESCRIPTION QTY
31 Weight Stack Pull Pin 1
32 Press Arm Lock 1
33 Strap Handle 2
ITEM NO. DESCRIPTION QTY
34 Bottom Pad 1
35 Head Pad 1
36 Back Pad With Lumbar 1
37 7” Upholstery Roller 2
Hardware
ITEM NO. DESCRIPTION QTY
41 2 Beveled Leveler
42 4 Wavy Washer
43 4 1” Snap Ring
44 2 3/8” Jam Nut
45 HCS 3/8”-16 x 2-1/2” 2
46 4 HCS 3/8”-16 x 5”
47 HCS 3/8”-16 x 5-1/4” 6
48 74 3/8” Flat Washer
49 14 3/8” Lock Washer
50 37 3/8” Nylock
51 HCS 3/8”-16 x 3/4” 2
52 HCS 3/8”-16 x 1/2” 4
53 FHSCS 3/8”-16 x 3/4” 2
54 2 Shaft Collar
55 Shoulder Bolt 1/2”-13 x 4-1/4” 1
56 Shoulder Bolt 1/2”-13 x 3-1/2” 1
57 2 HCS 3/8”-16 x 3”
58 2 1/2” Flat Washer
ITEM NO. DESCRIPTION QTY
60 HCS 3/8”-16 x 1-1/4” 4
61 16 3-1/2” Pulley
62 6
4 1/2” Pulley
63 1-1/4” Shoulder Bolt 3
64 1 5/16” Nylock
65 HCS 3/8”-16 x 2-1/4” 8
66 3/8” Curved Washer 4
67 1/2” Curved Pulley Spacer 8
68 4 HCS 3/8”-16 x 2”
69 HCS 3/8”-16 x 2-3/4” 8
70 HCS 3/8”-16 x 4-3/4” 6
71 2 Roller End Cap
72 BHSCS 3/8”-16 x 3/4” 2
73 1 HCS 3/8”-16 x 7”
74 1 HCS 1/2”-13 x 1”
87 Weight Stack Decals 1
88 1 Silicon Gel Pack
Cables
ITEM NO. DESCRIPTION QTY
38 Weight Stack to Cable Tie Out 1
39 Floating Pulley Cable 1
40 Lat Pull to Cable Lockout 2
86 Lat Pull to Functional Arm 2
Frame Components
PG6241說明書101025 拚版用-16.indd 5-6 2010/11/3 20:16:40
