Sida 1/21
P/N:110401109411X
Preface
Thank you for purchasing the new clamp meter. In order to use this product
safely and correctly, please read this manual thoroughly, especially the Safety
Instructions part.
After reading this manual, it is recommended to keep the manual at an easily
accessible place, preferably close to the device, for future reference.
Limited Warranty and Liability
Uni-Trend guarantees that the product is free from any defect in material and
workmanship within one year from the purchase date. This warranty does not
apply to damages caused by accident, negligence, misuse, modification,
contamination or . The dealer shall not be entitled to give any mishandling other
warranty on behalf of Uni-Trend. If you need warranty service within the warranty
period, please contact your seller directly.
Uni-Trend will not be responsible for any special, indirect, incidental or subsequent
damage or loss caused by using this device.
UT205E/UT206B/UT207B/UT208B User Manual
3 4
I. Overview ------------------------------------------------------------------- 4
II. Accessories 4
III. Safety Instructions 5
IV. Electrical Symbols 6
V. External Structure 7
VI. LCD Display 8
VII. 11
VIII. Specifications 13
IX. Operating Instructions 22
X. Maintenance 38
---------------------------------------------------------------
-----------------------------------------------------
-----------------------------------------------------
------------------------------------------------------
------------------------------------------------------------
Function SwitchDial and Function Buttons --------------------
--------------------------------------------------------
-----------------------------------------------
------------------------------------------------------------
Table of Contents
I. Overview
Warning:
Before using the meter, please read the Safety Instructions carefully.
II. Accessories
Open the package box and take out the meter. Please double check whether
the following items are missing or damaged.
a) User manual ------------------------------------------------------------ 1 pc
b) Test leads 1 pair ----------------------------------------------------------------
c) K-type thermocouple (UT206B/UT208B) 1 pc -----------------------
d) Cloth bag 1 pc -----------------------------------------------------------------
e) 1.5V AAA batteries 3 pcs ----------------------------------------------------
f) Flexible current probe (UT206B/UT208B) optional ----------------------
If any of the above is missing or damaged, please contact your supplier
immediately.
UT205E/UT206B/UT207B/UT208B User Manual UT205E/UT206B/UT207B/UT208B User Manual
The UT205E/UT206B/UT207B/UT208B is a 6000-count handheld true RMS
clamp meter with auto range. This full scale overload protection meter contains
the following features:
AC/DC voltage, AC current, resistance, diode, continuity, capacitance, frequency,
duty ratio, data hold, MAX/MIN, relative
DC current (UT207B/UT208B)
Temperature (UT206B/UT208B)
LPF (low pass filter) and LoZ (low impedance) voltage (UT206B/UT207B/UT208B)
Inrush current measurement (UT206B/UT207B/UT208B)
Analog bar display (UT206B/UT207B/UT208B),
Flashlight, NCV, low battery indication, and auto power off
The UT206B/UT208B can also be equipped with a flexible current probe to
extend the AC current measurement range to 3000A (optional accessory).
