Sida 1/1
Gift box, carrying bag, English manual
Power adaptor, power cord, test leads, test probes,
alligator clips, current clamp (10A/100A/1000A),
USB interface cable, PC software CD, SD card (8GB)
4pcs
665mm x 350mm x 305mm
GENERAL CHARACTERISTICS
Power
Display
Product net weight
Product color
Product size
Standard accessories
Standard individual packing
Standard quantity per carton
Standard carton measurement
Standard carton gross weight
Red and grey
Li-ion battery: 7.4V 3600mAh
70mm x 52mm; 3.5 inches 64K color TFT LCD (320
x
240)
808.4g
24.2kg
199mm x 118mm x 49mm
UT283A Single Phase Power Quality Analyzer
UT283A is a handheld multi-functional
device designed to measure and
analyze single-phase power systems.
This portable S class device can
measure amplitude, phase, harmonics,
current, voltage, then record results in
SD card for further analysis and export.
This product is suitable for
professionals working in electrical
power, medical, transportation,
telecommunication, and other
industrial areas.
● Trend/event capture
● Harmonics/inrush current measurement
● File management through USB interface
● Flick measure (PST/PLT values)
● User friendly interface
● Multimeter functions
● Scope functions including
waveform display
● 3.5 inches 64K color TFT LCD display
● THD (Total Harmonic Distortion) function
● Long-term monitoring
10V~1000V AC/DC
10A/100A/1000A
40~70Hz
>15%S
0~1
0~9999MWh
(1~51th, step 1th)
±6000V Peak, Fsample=2MHz
0~1000V AC
10A/100A/1000A
600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ
60nF/600nF/6μF/60μF/600μF
Up to 51th
10 minutes, PST and PLT values
8GB
1 to 10
Um≥3%Unom (1~51th, step 0.5th)
Um＜3%Unom (1~51th, step 0.5th)
Im≥10%Inom (1~51th, step 0.5th)
Im＜10%Inom (1~51th, step 0.5th)
±0.5%Udin
±0.5%f.s.
±50mHz
±1%S
±0.02
±1.5%rdg
±5%
±5%Urms
±0.15%Unom
±5%Irms
±0.5%Inom
±5%rdg.±5%f.s
Udin±1 %
±1%f.s
±(1%+3)
±(4%+20)
Calculated based on voltage
and current amplitude and
phase accuracy
Range UT283A
SPECIFICATIONS
Voltage (V)
AC current (A)
Frequency (Hz)
Power (W)
Power factor
Energy (Wh)
Crest factor
Power harmonics
Transients
Dip/swell/interrupt
AC inrush current (A)
Resistance (Ω)
Capacitance (F)
True RMS
Harmonic analysis
Flick measure
Voltage ratio
Current ratio
Event capture
Trend capture
Data logging
USB interface
Backlight adjustment
Low battery indication
Input protection
Voltage harmonics
or inter-harmonics
Current harmonics
or inter-harmonics
Features
91
