Sida 1/36
1
Table of Contents
Title Page
Overview
Unpacking Inspection
Safety Information
Rules For Safe Operation
International Electrical Symbols
The Meter Structure
Rotary Switch
Functional Buttons
Display Symbols
Measurement Operation
A. DC and AC Voltage Measurement
B. DC and AC Current Measurement
C. Measuring Resistance
D. Measuring Diodes
E. Testing for continuity
F. Capacitance measurement
G. Temperature Measurement
(UT58B/UT58C only)
H. Measuring Transistor
I. Frequency Measurement (UT58C only)
Sleep Mode
Operation of Hold Mode
General Specifications
Accuracy Specifications
A. DC Voltage
B. AC Voltage
C. DC Current
D. AC Current
E. Resistance Test
F. Diodes Test
G. Continuity Test
H. Capacitance
I. Temperature (UT58B/UT58C only)
J. Transistor Test
3
10
4
11
12
14
14
15
17
18
20
21
22
23
24
24
25
26
27
27
27
28
28
29
29
29
30
30
31
5
6
8
9
Model UT58A/B/C: OPERATING MANUAL
Title Page
K. Frequency (UT58C only)
Maintenance
A. General Services
B. Replacing the Fuses
C. Replacing the Battery
31
32
32
32
33
Model UT58A/B/C: OPERATING MANUAL
2
Overview
Warning
To avoid electric shock or personal injury, read the
“Safety Information” and “Rules for Safety Operation”
carefully before using the Meter.
Digital Multimeters Model UT58A, UT58B and UT58C
(hereafter referred to as “the Meter”) are 3 1/2 digits with
ex-large LCD, steady operations, fashionable structure
and highly reliable hand-held measuring instrument. The
Meter uses large scale of integrated circuit and has full
range overload protection. The Meter not only can
measure AC/DC Voltage, AC/DC Current, Resistance,
Capacitance, Temperature, Frequency, Transistor, Diode
and Continuity, but also have Data Hold, Full Icon Display,
Overload Protection and Sleep Mode features.
Model UT58A/B/C: OPERATING MANUAL
3
