UT673PV User Manual
1/ 7
UT673PV
User Manual
UT673PV User Manual
2/ 7
Preface
Thank you for purchasing this brand new product. In order to use this product safely and correctly, please
read the User Manual thoroughly, especially the “Safety Information” section. It is recommended to keep
this manual at an easily accessible place, preferably close to the device, for future reference
Ⅰ. Overview
UT673PV Solar MPPT Meter can measure the maximum power of solar module rapidly. It has the ability to
measure maximum power (Pmax) of solar module, open-circuit voltage (Voc), and short-circuit current
(Isc) at the same time and display all parameters on the screen. MPPT is the most important indicator for
judging if a solar panel generates power in low eciency, and is commonly used for measuring solar panel
or troubleshooting faulty module.
Application elds: Manufacturers of solar panel, users of solar panel, etc.
Ⅱ. Features
1 Small external dimensions; easy to carry ）
2 Designed with large LCD to display all parameters ）
3 Without needing battery, the Meter powers on with it connected to solar panel. ）
4 Manual/Auto mode ）
5 Protection against overtemperature, overvoltage, and overcurrent ）
6 Protection against reverse connecti ）on
7 Overload protection ）
Please carefully read the contents associated with “Safety” and “Warning” included in this User Manual,
and observe all precautions strictly.
Warning: Please read the “Safety Information” carefully before use.
Ⅲ. Accessories
Relevant safety information and warnings are included in this User Manual. Please read the related contents
thoroughly and follow all warning and precautions. Please contact your supplier if any accessory listed below
is missing or damaged.
1. User Manual 1 pc
2. MC4 cables (UT-L101) 1 pair
3. Special solar tool 1 set
4. Magnetic hanger (UT-B23) 1 set (optional)
Ⅳ. Safety Information
Please pay attention to “Warning labels and sentences”. A Warning identifies conditions and procedures
that are dangerous to the user, and that cause damage to the Meter or the equipment under test.
The Meter is designed in accordance with Double Insulation and no measurement category, for solar panel
only, the maximum working voltage is 60VDC. The Meter is for indoor use. The protection supplied by the
UT673PV User Manual
3/ 7
Meter may be compromised or lost without following the operating instructions.
1) Please check the Meter and test leads before use to avoid any damage or problem. Please stop use if
exposed test lead, damaged case, abnormal display and other problems occur.
2) It is forbidden to use without the cover closed in place. Otherwise it may present a risk of electric
shock.
3) If the test lead is damaged, please replace it with the one of same model or specication.
4) Do not touch the exposed wire, connector, unused input terminal or circuit during measurement.
5) Use caution when working with voltage over 30V DC. Please hold the test lead behind the tactile
barrier to prevent electric shock.
6) Do not exert voltage over the specied value between terminals or between any terminal and earth
ground
7) Use only test leads (MC4 cables) with rated voltage and current same as that of the Meter or test
leads (MC4 cables) approved by certication body.
8) Do not keep or use the Meter in environments with high temperature, high humidity, strong
electromagnetic eld, or inammable and explosive substances.
9) Do not alter the internal wiring without authorization to avoid damaging the Meter or causing safety
hazard.
10) Please measure a known intrinsic voltage or current before use to ensure the Meter works normally.
Ⅴ
Ⅴ
Ⅴ
ⅤⅤ. Electrical Symbols
Ⅵ
Ⅵ
Ⅵ
ⅥⅥ. General Characteristics
1. Maximum voltage between signal input terminal and COM terminal: 60VDC
2. Range: Auto/Manual
3. Polarity display: Protection against reverse connection
4. Overrange indication: “OL”
5. Drop proof: 1m
6. Operating temperature: 0 (32 104 ) ℃～40℃ ℉～ ℉
7. Storage temperature: -10℃～50℃ ℉～(14 122 ) ℉
8. Relative humidity: ≤75% (0 below); ≤50% (30℃～ ℃ 30 ℃～40℃)
9. Operating altitude: ≤2000m
10. External dimensions: About 142mm x 76mm x 22mm
11. Weight: About 154g
12. Measurement category: no measurement category, for solar panel only, the maximum working
voltage is 60VDC
13. Pollution degree: 2
14. Application eld: Solar panel
Symbol
Description
Danger! High voltage!
Warning
DC (Direct Current)
