TABLE OF CONTENTS
TITLE PAGE
HIGHLIGHTS
NOTES FOR SAFE USAGE
FIGURATION AND ACCESSORIES
ELECTRIC SYMBOL
GENERAL INFORMATION
SPECIFICATIONS
1.DC Voltage (DCV)
2.AC Voltage (ACV)
3.DC Current (DCA)
4.AC Current (ACA)
5.Resistance
6.Capacitance
7. Inductance
8.Auto range frequency test
9.Transistor hFE measurement
10.Diode
11.Continuity Buzzer
12.TTL LOGIC Test
13.Temperature Test
OPERATION INSTRUCTION
1. Introduction of functional buttons
2. DC Voltage Measurement (DCV)
3.AC Voltage Measurement (ACV)
4. Current Measurement (DCA)
5.AC Current Measurement (ACA)
6. Resistance Measurement
7. Inductance Measurement (L)
8. Capacitance Measurement (C)
9. Frequency Measurement (10MHz)
10. Temperature Measurement (
0C or 0F)
Model UT70A: OPERATING MANUAL
3
3
5
7
8
9
9
9
10
10
10
11
11
11
11
12
12
12
12
14
15
15
17
18
19
20
21
22
23
24
1
TABLE OF CONTENTS
TITLE PAGE
11. Transistor Parameter
Measurement (hFE)
12. Diode (or PN node of transistor)
Measurement( )
13. Continuity Buzzer Test
14. TTL LOGIC Test
MAINTENANCE
FUSE AND BATTERY replacement
Accessories
Model UT70A: OPERATING MANUAL
24
25
25
26
27
28
28
2
Operating Manual of UT70A Multimeter
HIGHLIGHTS
UT70A Multimeter is a hand-held digital multimeter with
advanced design, multiple functions, novel figuration,
large display screen and reliable performance. This meter
is fully capable to measure voltage and current both AC
and DC, resistance, capacitance, inductance, temperature,
frequency, forward voltage drop of diode, transistor hFE
and continuity test, TTL LOGIC level measurement. It
has some extraordinary functions such as holding the
measured data and maximum value, providing backlight
display in a dim condition, displaying polarity, over-range,
low battery, and units icons, and full overloading protection
and automatic power off.
NOTES FOR SAFE USAGE
1) CE Version: The Meter complies with the standards
IEC61010-1:in pollution degree 2, overvoltage category
CAT III 1000V, CAT IV 600V and double insulation .
UL Version: The Meter complies with the standards
UL61010B-1, in pollution degree 2, overvoltage
category CAT II 1000V and double insulation.
CATII: Local level, appliance, PORTABLE EQUIPMENT
etc., with smaller transient overvoltages than Installation
CategoryIII.
CATIII: Distribution level, fixed installation,with smaller
transient overvoltages than CAT IV.
CAT IV: Primary supply level, overhead lines,
cablesystems etc.
2) Make sure the insulation of the meter in good condition,
no damage and break before use.
3) Don’t use at all unless the back case is in place or
there is danger of electric shock.
4) Battery should be replaced to ensure an accurate
measurement when " " appears on LCD.
Model UT70A: OPERATING MANUAL
3
