Sida 1/10
Installation instructions
Heat pump dryer
One-family household
1064356-09
26/02/2021
1064356-09
1
Fire hazard! Models 12017—12019 contain the refrigerant R290, an environmentally friendly but flammable refriger-
ant. Keep open fire, ignition and/or heat sources such as burning candles, incense sticks, room heaters and the like
away from the models.
The appliance should be installed by qualified personnel only.
Each step must be carried out and checked in full in the order specified.
Check the appliance for visible damage. Do not use the appliance if it is damaged in any way.
Validity
The installation instructions apply to the models: —12011 12013, 12017—12019
Transport
Transport the appliance in an upright position only! Transporting it in any other position will result in damage to the
appliance! When carried carefully without being shaken, the appliance may be tilted a maximum of 90° to the left
(viewed from the front).
Identification plate
1
▸Open the appliance door.
–The identification plate is located1
bottom right.
Supplied installation accessories
The necessary installation accessories are located in the washing drum and in the appliance packaging.
Designation Article no. Number See installation step
Installation plate (incl. double-sided adhesive tape) W40653 1 2. Positioning the installation plate
Tower panel W55687 1 2. Positioning the installation plate
Condensate drain set (incl. screw material) W56298 1 6. Connecting condensate drain
Installation instructions
Heat pump dryer
One-family household
1064356-09
26/02/2021
1064356-09
2
Room size, room climate and ventilation
Keep all ventilation slits on the appliance clear and unobstructed. Otherwise an adequate supply of air is not guaran-
teed.
▸Ventilate the room well. Ensure that the temperature of the room is between 5–35°C.
▸The room temperature must be kept between the range of 15–25°C to ensure the economic running of the appliance.
Room size <10m² (<20m³) Room size 10m² (≥20m³)≥
▸Room must be ventilated: There must be air inlet and outlet
openings to the adjacent room or to the outside, e.g. open win-
dow/door, ventilation grille or slits in the door or ventilation sys-
tem.
▸Condensation may form on thermal bridges! The room must
therefore be aired after running several consecutive drying pro-
grammes, e.g. by opening a window or door to the room.
1. Dimensions
The stated dimensions do not include distances from walls. To prevent disturbing noise and vibration the appliances
must not come into contact with the surrounding walls of their installation location.
1160
1200*
180°
180°
1200*
1160
595
70
15
600
500 50 57.5
3
6
1
5
(126)444280
850
2
4
550 458 71
Left-hand opening Right-hand opening
1Cooling air inlet
2Cooling air outlet
3Installation plate
4Tower panel
5Outlet mains connection cable,
length: 1.8m, with plug
6Condensate drain
Drain connection: ø10.5 mm
Pumping height of drain pump from floor:
≤1200 mm
Condensate water drain hose,
length: 2.5 m
*Clearance space across the whole width
of the front
Installation instructions
Heat pump dryer
One-family household
1064356-09
26/02/2021
1064356-09
3
2. Positioning the installation plate
General tips
Use the installation plate supplied to install the appliance. It fixes the appliance in position, and is for use with both
free-standing appliances and appliances positioned in a niche.
In case of underfloor heating, do not drill holes in the floor! Adhere installation plate into place!
1
E
D
45
▸Fold out spacers in order to keep dis-D
tance to the back wall.
3×
1
2
2
ø5
Variant 1: Without underfloor heating:
▸Fasten installation plate to the floor with
3screws.
▸Dampen mounting slots with water toE
make the appliance easier to push in.
Variant 2: With underfloor heating:
▸Holes must not be drilled in the floor if
the room has . Theunderfloor heating
installation plate must be adhered to the
floor.
▸Dampen mounting slots with water toE
make the appliance easier to push in.
When installing the washer-dryer tower, do not drill any holes in the washing machine! Adhere installation plate into
place!
▸If a has to be installed tumble dryer on
top of a washing machine, no holes
must be drilled in the washing machine.
The installation plate must be adhered to
the floor.
