Installation and User Guide
Camera and Electronic Products for Integrators
© 2005 Vaddio 341-252 Rev. A
Vaddio™ IR Remote Commander
Enhanced IR Remote Controller
The Vaddio IR Remote Commander was designed to work with the Vaddio camera packages based on
the Vaddio HD-18, Sony® EVI-D70, EVI-D100 and BRC-300 Pan/Tilt/Zoom Cameras. The IR Remote is
compatible with the following list of Vaddio camera systems:
Vaddio ClearVIEW HD-18 Systems (Camera, WallVIEW and CCU Versions)
WallVIEW™ 70 PTZ, WallVIEW 100 PTZ, WallVIEW 300 PTZ
CeilingVIEW™ 70 PTZ and CeilingVIEW 70 PTZ HideAway
Vaddio EZCamera™ series Model 100 PTZ and Model 70 PTZ systems
Vaddio 100 PTZ and 70 PTZ Integrator’s camera kits
The Vaddio IR Remote Commander is also a 100% compatible replacement IR remote for the Sony PTZ Cameras
The information contained in this manual will help you install and operate you IR Remote
Commander. If these instructions are lost or misplaced, Vaddio keeps copies of Specifications,
SAVE THESE
INSTRUCTIONS
Figure 1:
Vaddio IR Remote Commander
Enhanced, ergonomically designed
and user-friendly handheld remote
control (Actual size)
Power On/off
(Green button)
Back Light
Compensation
On/off
Data Screen for BRC
Type Camera OSD Camera Select
Three IR Frequencies
Standard Pan
Direction Reverse Pan
Direction
Pan/Tilt controls
(burgundy buttons)
Pan/Tilt Reset Auto Focus
On/off
Zoom Speed
SLOW
(Lt. Gray button)
Zoom Speed
FAST
(Lt. Gray button)
Manual Focus Control
(Near- & Far+)
Preset Set
Press and hold,
touch Preset 1
thru 6 to set
p
reset
Preset Erase
6-Presets
Stored in the
Camera for
Recall
Camera Home Position
2005 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and
pricing subject to change. CeilingVIEW, WallVIEW, EZCamera are registered trademarks of Vaddio, Inc. All other trademarks are
property of their respective owners. Form Number 341-252 Rev. A.
Installation and User Guides and most pertinent product drawings for the Vaddio product line on the
Vaddio website. All manuals for the cameras mentioned in this manual can be found and can be
downloaded from www.vaddio.com free of charge.
Do not attempt to take the products in this system apart. There are no user-serviceable parts inside.
Do not spill liquids on the products and keep these devices away from food and liquid
For smears or smudges, wipe with a clean, soft cloth. Do not use any abrasive chemicals.
Do not store or operate the IR Remote under the following conditions for any circumstance:
Temperatures above 40°C (104°F) or temperatures below 0°C (32°F)
High humidity, dusty, condensing or wet environments
In inclement weather or under severe vibration
Hardware* Warranty - One year limited warranty on all parts. Vaddio warrants this product against
defects in materials and workmanship for a period of one year from the day of purchase if Vaddio
receives notice of such defects during the warranty. They will, at its option, repair or replace products
that prove to be defective. See Warranty and RMA Policy documentation.
Exclusions - The above warranty shall not apply to defects resulting from: improper or inadequate
maintenance by the customer, customers applied software or interfacing, unauthorized modifications
or misuse, operation outside the normal environmental specifications for the product, use of the
incorrect power supply, or improper site operation and maintenance.
Vaddio Customer service Vaddio will test, repair, or replace the product or products without
charge if the unit is under warranty. If the product is out of warranty, Vaddio will test then repair the
product or products. The cost of parts and labor charge will be estimated by a technician and
confirmed by the customer prior to repair. All components must be returned for testing as a complete
unit. Vaddio will not accept responsibility for shipment after it has left the premises.
Vaddio Technical support - Vaddio technicians will determine and discuss with the customer the
criteria for repair costs and/or replacement. Vaddio Technical Support can be contacted through one
of the following resources: e-mail support at support@vaddio.com or online at www.vaddio.com.
Return Material Authorization (RMA) number - Before returning a product for repair or
replacement request an RMA from Vaddio’s technical support. Provide a technician with a return
phone number, e-mail address, shipping address, and product serial numbers. Describe the reason
for repairs or returns as well as the date of purchase. Include your assigned RMA number in all
correspondence with Vaddio. Write your assigned RMA number on the outside of the box when
returning the product.
Voided warranty The warranty does not apply if the original serial number has been removed or if
the product has been disassembled or damaged through misuse, accident, modifications, or
unauthorized repair.
Shipping and handling - Vaddio will not pay for inbound shipping transportation or insurance
charges or accept any responsibility for laws and ordinances from inbound transit. Vaddio will pay for
outbound shipping, transportation, and insurance charges all items under warranty but will not
assume responsibility for loss and/or damage by the outbound freight carrier.
If the return shipment appears damaged, retain the original boxes and packing material for
inspection by the carrier.
o Contact your carrier immediately.
Products not under warranty - Payment arrangements are required before outbound shipment for
all out of warranty products.
*Vaddio manufactures its hardware products from parts and components that are new or equivalent to new in
accordance with industry standard practices.
The IR Remote Commander was designed, built and tested for use indoors only. Please use two
(2) Size/Format AAA, 1.5V batteries only. Use alkaline batteries for best results.
WARRANTY
INFORMATION
OPERATING
AND STORAGE
CONDITIONS
CARE AND
CLEANING
