Sida 1/4
*KTA-2727-3*
(
(
(
)
)
m
R
m
(
8
Pull handle, slide seat, release
handle.
Do not sit nearer than 25 cm from
steering wheel, to permit safe
airbag deployment.
Pull lever, adjust inclination and
release lever. Allow the backrest to
engage audibly.
Do not angle the backrest too far
back. We recommend a maximum
rake of approx. 25 o.
Lever pumping motion.
up = seat higher
down = seat lower
Sit with buttocks are as far back
against backrest as possible.
Adjust distance between seat and
pedals so that your legs are slightly
angled when depressing pedals.
Slide the front passenger seat as
far back as possible.
Press button, adjust height and
engage in position. The upper edge
of the head restraint should be at
upper head level.
To adjust horizontally, pull the
head restraint forwards. It engages
in several positions.
Withdraw seat belt from retractor,
guide it untwisted across the body
and insert latch plate in belt buckle.
To release belt, press red button on
belt buckle.
Fasten seat belt before each trip.
Unlock lever, adjust steering wheel,
then engage lever and ensure it is
fully locked.
Do not adjust steering wheel unless
vehicle is stationary and steering
wheel lock has been released.
Select the relevant exterior mirror
by moving the selector switch to the
left or right .
Then press the control pad to
adjust the respective mirror.
In the centre position of the selector
switch, no mirror is selected.
To reduce dazzle, adjust lever on
the underside of the mirror housing.
Dazzle from following vehicles at
night is automatically reduced if
the vehicle is equipped with
automatic anti-dazzle interior
mirror.
Front switches operate the front
windows and rear switches operate
the rear windows.
Push switch = Open window
Pull switch = Close window
Push or pull switch gently to the first
detent position: window moves up
or down as long as the switch is
operated.
Push or pull switch to the second
detent position and then release:
Window opens or closes
automatically with safety function
enabled. To stop window
movement, operate switch once
more in the same direction.
Turn light switch:
= Automatic light control:
Exterior lighting is
switched on and off
automatically, depending
on external lighting
conditions
m= Activation or deactivation
of Automatic light control.
Switch returns to .
8= Sidelights
9= Low beam
When the function is switched on
and the ignition is on, the system
switches between daytime running
lights and low beam, depending on
external lighting conditions.
Increases visibility of the vehicle
during daylight.
During poor lighting conditions, the
low beam is switched on.
Do not cover the light sensor
otherwise the mode will not
operate properly.
The low beam and reversing lights
illuminate briefly by doing the
following:
1. Switch off ignition
2. Open the driver’s door
3. Pull turn signal lever briefly
then release
Some interior lights come on when
the ignition is switched off. The
exterior and interior lights remain
on for a brief period after the door
is closed and will switch off
automatically after a short delay.
Press button ( on remote control:
Low beam, reversing lights and
interior lights are switched on
briefly.
Lights switch off immediately when
the power button m is pressed.
Headlight flash = Pull lever
towards
steering wheel
High beam = Push lever
forwards
Low beam = Push lever
forwards
again or pull
towards
steering wheel
Turn the fog light band on the lever
to position r and release it, to turn
the rear fog light on or off. The
band will return to its original
position when released.
Headlights and sidelights must be
on for the rear fog light to work.
The rear fog light is automatically
set to off each time the vehicle is
started.
Adapt headlight range to suit the
vehicle load to prevent dazzling of
other road users.
Turn thumb wheel ? to required
position.
Front seats occupied = 0
All seats occupied = 1
All seats occupied and
load compartment laden = 2
Driver’s seat occupied and
load compartment laden = 3
Lever up = Right turn signal
Lever down = Left turn signal
If lever is moved past the resistance
point, the turn signal is switched on
constantly. When the steering
wheel is moved back the turn signal
is automatically deactivated.
For three flashes, e.g. when
changing lanes, press the lever until
resistance is felt and then release.
Move lever to resistance point and
hold for longer indication.
Switch the turn signal off manually
by moving the lever to its original
position.
Operated with the ¨ button.
In the event of an accident where
the airbags are deployed, the
hazard warning flashers are
activated automatically.
= Fast
= Slow
= Adjustable timed
interval wipe
= Off
For a single wipe when the wiper is
off, press the lever down.
Lever in position : Turn adjuster
wheel up or down to make wiping
interval shorter or longer.
Do not use wiper if windscreen is
frozen. Switch off in car washes.
Pull lever towards steering wheel.
Washer fluid is sprayed onto the
windscreen and the wiper swipes
for a few strokes.
Use this feature to alert people who
may not hear your vehicle
approaching.
Briefly press button 4 on the end
of the lever and a soft-note alert
will momentarily sound.
The pedestrian safety alert is only
available when the vehicle is not in
Park position .
The pedestrian safety alert is not
suitable as a horn.
Ü
The heating is operated by
pressing the Ü button.
Heating switches off automatically
after approx. 5 minutes.
Press button V.
Set temperature to warmest
level.
Switch heated rear window Ü
on.
The system monitors high humidity
inside the vehicle and adjusts to
outside air supply and turns on the
air conditioning or the heater if
necessary. Fan speed may increase
slightly, to help prevent fogging.
When high humidity is no longer
detected, the system will return to
its prior operation.
To apply, pull switch J with vehicle
stationary: the electrical parking
brake is applied automatically and
control indicator J flashes then
illuminates in the instrument cluster
when fully applied. For maximum
force, e.g. parking on inclines, pull
switch J twice.
The electrical parking brake can
always be applied, even if the
ignition is off.
To release, switch on ignition. Keep
brake pedal depressed and then
push switch J.
To prevent the 12-volt battery from
draining, avoid repeated use of the
electrical parking brake switch
when the ignition is off.
Press button ( on remote control
- or - press lock/unlock button on
door handle (once or twice,
depending on configuration) to
unlock the tailgate.
Press the button under the tailgate
handle to unlatch, and lift up to
open the tailgate.
Use interior handle to close.
Do not press the button under the
tailgate handle whilst closing or it
will unlatch again.
Always close the tailgate before
driving.
Press button ) on remote control
- or - press lock/unlock button on
door handle to lock the vehicle.
Switch ignition off before opening
the bonnet, otherwise the engine
will be started automatically.
Pull bonnet release lever located
below instrument panel and return
it to its original position.
Push safety catch in engine
compartment to the left and open
the bonnet fully.
Release bonnet prop rod from its
retainer above the radiator support
and place it securely into the
slotted retainer in the bonnet.
Before closing, press the bonnet
prop rod into its retainer. Lower
bonnet and allow it to drop into the
catch. Check bonnet is engaged.
The fuel system on this vehicle
requires a refuelling process to
control evaporative emissions.
Before refuelling, switch off engine
and any external heaters with
combustion chambers.
Switch off any mobile phones.
To refuel:
1. Press the fuel door release
button in the driver’s door for
one second.
A message is displayed in the
Driver Information Centre (DIC)
asking you to wait.
2. When a message is displayed in
the DIC confirming the system is
ready to be refuelled, the fuel
door on the right rear side will
unlock.
Push the rear edge of the fuel
door inwards and release to
open the fuel door.
3. Turn fuel cap anti-clockwise to
remove. When refuelling, hang
the fuel cap tether from the hook
on the inside of the fuel door.
Complete refuelling within
30 minutes of pressing fuel door
release button in the driver’s
door. Press button again if
necessary, to continue refuelling.
4. After refuelling, reinstall the fuel
cap by turning it clockwise until it
clicks. Close the fuel door.
Do not top off or overfill the fuel
tank and wait a few seconds before
removing the nozzle.
Wipe off any overflowing fuel.
Petrol engine - only use unleaded
fuel that complies with EN 228 or
E DIN 51626-1 or equivalent.
Use of fuel that does not comply
with EN 228 or E DIN 51626-1 or
equivalent can lead to deposits or
engine damage and may affect
your warranty.
Fuel tank capacity (all models) -
35 litres.
