Features and Functions
The illustration below and chart on the next page describe the
features and functions of the One For All® Easy 3 Device
universal remote control.
Feature Function
POWERSETUP
TV VCR
CBL
CH-
REC PAUSE
PLAY
REW FF
STOP
VOL
2
4
1
VOL
CH+
3
M
Stop Key
Play Key
Red Light
(LED)
Setup
Key
TV Key
Power
Key
CBL Key
VCR Key
Volume
and
Channel
Glow Keys
Record
Key
Rewind
Key Fast
Forward
Key
Pause Key
Mute
Glow Key
The LED flashes red to show that the
remote is working.
The TV, VCR and CBL keys are used to
select the home
entertainment device you want to control.
The POWER key operates the same as on
your original remote.
The SETUP key is used to set up your
devices.
The Glow Keys: VOL (Volume), CH
(Channel), and M (Mute) operate the same
as on your
original remote. To activate the "Glow"
Feature, you must expose the Glow Keys
to bright light. The length of time the
Glow Keys remain illuminated will be
determined by the length of time the
remote is exposed to bright light. These
keys are also used to enter set-up codes for
your devices.
The REW (Rewind), FF (Fast Forward),
STOP, PLAY, PAUSE and REC (Record)
keys control the same functions as those
found on your VCR remote.
RED Light (LED)
POWER
SETUP
CH-
VOL
2
4
1
VOL
CH+
3
M
TV VCR CBL
REW FF STOP
PLAY PAUSE REC
Overview:
Thank you for purchasing the One For All® Easy 3 Device
universal remote. Before you can use your new
remote, you will need to program it. To do this, you need to tell
the remote what equipment you wish to operate. This is done by
following these three easy steps.
Step 1: Install two (2) new AAA alkaline batteries.
Step 2: Look up the code for your TV, VCR or Cable Box.
Step 3: Enter the code.
User Manual
Previous Model Name:
So Easy
URC 3030
Easy 3
3031 / 3032 / 3033 / 3034
Step 1:
Installing the Batteries
Step 3:
Setting Up Your Devices
1
1
2Match the batteries to the + and - marks inside
the battery case, then insert the batteries.
3Press the battery cover back into place.
1st TV code
2nd TV code
3rd TV code
1st VCR code
2nd VCR code
3rd VCR code
1st Cable code
2nd Cable code
3rd Cable Code
Step 2:
Looking Up Your Electronic Device Code
You will need one of these codes to program your One For All®
Easy 3 Device remote.
Look at your Electronic Device to find out the brand name and
write it in the space below:
TV ________________________
VCR _______________________
Cable _______________________
1
2
Your One For All® Easy 3 Device needs two (2) new AAA
alkaline batteries. To install the batteries:
On the back of the One For All® Easy 3
Device, push down on the tab and lift the
cover off.
Set-Up Codes
RCA 1213
Sony 1111
Turn on your TV, VCR or Cable Box, depending on the
device you are programming.
2Press TV* and release. Press and hold SETUP
until the One For All® Easy 3 Device's red
light blinks twice. Release SETUP.
* Note: When setting up your VCR and/or Cable Box,
substitute the appropriate device key (VCR or CBL).
3Using the example
shown on the
right, enter the
first four-digit
code you wrote
down for the
device you are
setting up. (See
"Looking Up Your
Electronic Device
Code".) If you put
in the code
correctly, the red
light will blink
twice.
TV
4Test the unit by pressing POWER. The red
light (LED) should blink once.
POWER
Note: Removing the batteries for more than 30 minutes will require you to
reprogram the remote control.
SETUP
+
Find your Device brand in the listing on the re-
verse side of these instructions. The most
popular codes are listed first. Write your codes
here:
How to Enter Codes
If your TV
Press
code is:
1
VOL
1
2
VOL
2
CH+
3
3
CH-4
4
TV Set Up
Aim the One For All® Easy3 Device at your TV
and press POWER. Your TV should turn off. If it
doesn't, repeat Steps 2-4, trying each code listed for
your brand until you find the one that operates your
TV.
VCR Set Up
Aim the One For All® Easy3 Device at your
VCR and press POWER. Your VCR should turn
off. If it doesn't, repeat Steps 2-4, trying each code
listed for your brand until you find the one that
operates your VCR. If your original VCR remote
did not have a POWER key, put a tape in your
VCR and press PLAY on the One For All® Easy3
Device.
Cable Set Up
Aim the One For All® So Easy 3 Device at your
Cable Box and press POWER. Your Cable Box
should turn off. If it doesn't, repeat Steps 2-4, trying
each code listed for your brand until you find the
one that operates your Cable Box. If your original
Cable Box remote did not have a "ON" key, Use
CH + on the One For All® Easy 3 Device to
turn your Cable Box on.
4
POWER
POWER
or
POWER
CH+
3
or
PLAY
Troubleshooting
If you cannot get the One For All® Easy 3 Device to operate
your equipment or perform commands properly:
■Try all of the codes listed for your TV, VCR or
Cable Box in the Set-Up Codes section to the right.
Many set-up codes may allow partial functionality,
however, only one code will operate your device
correctly.
■Make sure you are within 15 feet of your
equipment when using your remote control.
■If the red light on the remote control does not blink
when you press a key, replace the batteries with
two (2) new AAA alkaline batteries. Be sure you
match the batteries to the plus (+) and minus (-)
marks inside the battery case.
■No volume when in the Cable mode or when
operating a second TV or TV/VCR combination?
Press and hold SETUP until the red light blinks
twice, then release SETUP. Press CH- + CH- +
VOL- then press VOL+.
■As a safety feature on the One For All® Easy 3
Device, you must press the REC key twice.
■World Wide Web: http://www.oneforall.com
Multitech 1413, 1431
NAD 1341, 1331, 1411
NEC 1142, 1231, 1123
Nikko 1243, 1411
NTC 1243
Okron 1123
Onwa 1413
Optimus 1341, 1324, 1433
Optonica 1244, 1334
Orion 1432, 2112
Oritron 1413, 1112
Panasonic 1433, 1214, 1224, 1223
PCE 1331, 1232
Penney 1213, 1232, 1214, 1142, 1123,
1122, 1412, 1131, 1133, 1312,
1331, 1321, 1112, 1211, 1143,
1433, 2114
Performance 1111
Philco 1223, 1311, 1142, 1123
Philips 1223, 1311
Pilot 1142, 1123, 1211
Pioneer 1341, 1144
Portland 1243, 1123, 1211
Priceclub 1232
Prism 1214
Proscan 1213
Proton 1221, 1411, 1112
Pulsar 1121
Pulser 1123
Quasar 1433, 1214, 1224
RadioShack 1334, 1413, 1123, 1211, 1143
RCA 1213, 1122, 1123, 1141, 1312,
1434, 1343, 1242
Realistic 1324, 1334, 1231, 1142, 1123,
1413, 1411, 1211, 1143
Rhapsody 1422, 1421
Runco 1142, 1121
Sampo 1221, 1211, 1143
Samsung 1232, 1231, 1142, 1123, 1411,
1143
Samsux 1211
Sanky 1142, 1232, 1211
Sansui 1142, 1232, 1334
Sanyo 1324, 1333, 1314
Scimitsu 1123
Scotch 1411
Scott 1432, 1123, 1413, 1411
Sears 1213, 1324, 1342, 1223, 1231,
1331, 1333, 1411, 1412, 1321,
1314
Sharp 1244, 1334, 1211
Shogun 1123
Signature 2000 1114, 1244
Signature 1114, 1244
Simpson 1423, 1424
Sony 1111, 1113, 1241
Soundesign 1413, 1423, 1411, 1412
Spectricon 1112
Squareview 1342
SSS 1123, 1413
Starlite 1413
Supre-Macy 1212
Supreme 1111
Sylvania 1223, 1311, 1142
Symphonic 1342
Tandy 1244, 1334
Tatung 1224, 1112
Technics 1433, 1214
Technol Ace 1412
Techwood 1214, 1231, 1112
Teknika 1243, 1223, 1322, 1123, 1114,
1232, 1413, 1231, 1423, 1412,
1211
Thomas 1231, 1411
TMK 1231, 1344, 1411
Toshiba 1331, 1232, 1321
Tosonic 1422
Totevision 1211
Truetone 1433, 1214, 1224
Universal 1131, 1133
Vector Research 1142
Victor 1222
Vidikron 1223
Vidtech 1123, 1411
Viking 1212
Wards 1223, 1334, 1311, 1114, 1231,
1142, 1123, 1141, 1411, 1131,
1133, 1124, 1412, 1134, 1343,
1241
Wellton 1411, 1123
XR1000 1432, 1413, 1342
Yamaha 1142, 1123
York 1142
Zenith 1121, 1243, 1114
Zonda 1112
TV
VCR
to SETUP* + CH - + CH - +VOL+ + VCR +
TV + TV + SETUP* + VCR code.
SETUP* + CH - + CH - +VOL+ + CBL +
TV + TV + SETUP* + Cable Box code.
SETUP* + CH - + CH - +VOL+ + TV +
VCR + VCR + SETUP* + TV code.
SETUP* + CH - + CH - +VOL+ + CBL +
VCR + VCR + SETUP* + Cable Box code.
SETUP* + CH - + CH - +VOL+ + TV +
CBL + CBL + SETUP* + TV code.
SETUP* + CH - + CH -- +VOL+ + VCR +
CBL + CBL + SETUP* + VCR code.
To Change Press
TV
CBL
to
TV
VCR
to
to
VCR
CBL
TV
CBL
to
CBL
VCR
to
Re-Assigning Device Keys
You can use the One For All® Easy 3 Device to operate a
second TV or a second VCR. To do so, you must re-assign
one of the device keys (TV, VCR, or CBL) to operate your
second TV or VCR. The chart below shows you how to re-
assign the device keys. * Please note: Here you must press and
hold SETUP until the One For All ® So
Easy 3 Device's red light blinks twice.
Set-Up Codes for TVs
A-Mark 1112
Abex 1143
Accuscan 1213
Admiral 1244, 1334
Adventura 1212
Aiko 1243
Akai 1142, 1231
Alleron 1412, 1421
Ambassador 1344
Americana 1232, 1322
Anam 1233, 1413
Anam National 1224
AOC 1112, 1123, 1142, 1422, 1221
Archer 1112
Audiovox 1413, 1112
Bay Crest 1123, 1334
Belcor 1123
Beaumark 1121
Bell & Howell 1324, 1114, 1244
Bench Mark 1232, 1123, 1413, 1114
Bradford 1413
Brockwood 1123
Broksonic 1112 , 1432, 2112
Candle 1142, 1231, 1423, 1212
Capehart 1221
Carver 1223
CCE 1431
Celebrity 1111
Citizen 1243, 1232, 1231, 1142, 1441,
1423, 1211, 1212
Clairtone 1422
Colortyme 1223, 1232, 1411
Concerto 1231
Conic 1143
Contec 1413, 1422, 1332
Craig 1413
Crosley 1223
Crown 1413, 1211
Curtis Mathes 1342, 1232, 1142, 1444, 1211
CXC 1413
Daewoo 1243, 2111, 1123, 1211
Daytron 1123, 1231
Dumont 1123, 1121
Electroband 1111, 1422
Electrohome 1443, 1322
Emerson 1432, 2112, 1413, 1412, 1344,
1411, 1441, 1442, 1123, 1211,
1422, 1414, 1144, 1332, 1324
Encor 1143
Envision 1142
Fisher 1324, 1333
Fujitsu 1412
Funai 1342, 1412, 1413
Futuretech 1413
GE 1213, 1214, 1224, 2111, 1131,
1133, 1442, 1312, 1411, 1141,
1343
Gibralter 1142, 1123, 1121
Goldstar 1231, 1142, 1123, 1411, 1143,
2113, 2114
Granada 1313, 1323
Grundy 1412, 1413
Grunpy 1412, 1413
Hallmark 1411
Harley Davidson 1411, 1111, 1413, 1223
Harman/Kardon 1234
Harvard 1413, 1233
Heathkit 1114, 1121, 1243
Hitachi 1313, 1323, 1231, 1144, 1143
Ima 1413
Infinity 1223
Janeil 1212
JBL 1223
JCB 1111
JVC 1222, 1414, 2121, 2122
Kamp 1332
Kawasho 1332
Kaypani 1221
Kenwood 1142, 1123
KLH 1233, 1413
Kloss Novabeam 1234, 1132
Kloss 1234, 1132, 1212
KMC 1143
KTV 1142, 1413, 1422, 1441, 1211,
1421, 1431
Lloyds 1432, 1413, 1412
Logik 1114
Luxman 1231
LXI 1324, 1223, 1213, 1411, 1331
Magnasonic 1412, 1142
Magnavox 1223, 1311, 1423, 1424, 1142
Majestic 1114
Marantz 1223, 1142
Matsui 1431
Megatron 1411, 1112, 1313
MEI 1422
Memorex 1322, 1324, 1231, 1114, 1411,
1433
MGA 1322, 1142, 1411
Midland 1213, 1121, 1214, 1312, 1211,
1143
Minutz 1131, 1133
Mitsubishi 1322, 1123, 1411, 1244, 2123
Motorola 1244, 1224
MTC 1422, 1232, 1231, 1142, 1123
Set-Up Codes for VCRs
Adventura 1111
Aiko 1413
Aiwa 1111
Akai 1141, 1214, 1313, 1224
American High 1124
Asha 1411
Astra 1124, 1411, 1111
Audiovox 1131
Avis 1241, 1111
Beaumark 1411
Bell & Howell 1311
Broksonic 1311, 1413, 1341, 1314, 1422,
1424
Produktspecifikationer
| Varumärke: | Vermeiren |
| Kategori: | Rollator |
| Modell: | Goliat Artro |
Behöver du hjälp?
Om du behöver hjälp med Vermeiren Goliat Artro ställ en fråga nedan och andra användare kommer att svara dig
Rollator Vermeiren Manualer
13 September 2024
11 September 2024
3 September 2024
2 September 2024
27 Augusti 2024
22 Augusti 2024
20 Augusti 2024
Rollator Manualer
- Rollator Gemino
- Rollator Volaris
- Rollator Topro
- Rollator Scala
- Rollator Human Care
- Rollator Excelcare
- Rollator Dietz
- Rollator Thuasne
- Rollator Bischoff Bischoff
- Rollator Provo
- Rollator Ridder
- Rollator Saljol
- Rollator Trionic
- Rollator Wheelzahead
- Rollator Weinberger
- Rollator Rehasense
- Rollator MultiMotion
- Rollator Travixx
Nyaste Rollator Manualer
17 Februari 2025
23 September 2024
23 September 2024
22 September 2024
22 September 2024
19 September 2024
18 September 2024
15 September 2024
15 September 2024
15 September 2024
