Sida 1/18
Vinten
Camera Control Solutions
Operators Guide
Vision 250
Pan & Tilt Head
Vision 250
Pan and Tilt Head
Publication Part No. 3525-8 Issue 3
Copyright © Vinten Broadcast Limited 2004
All rights reserved throughout the world. No part of this document may be stored in a retrieval system, transmitted, copied
or reproduced in any way including, but not limited to, photocopy, photograph, magnetic or other record without the prior
agreement and permission in writing of
Vinten Broadcast Limited.
Vinten, QuickFit and Vision are registered trademarks of Vinten Broadcast Limited.
3
Safety - read this first
Warning Symbols in this Operators Guide
Where there is a risk of personal injury, injury to others, or damage to the pan
and tilt head or associated equipment, comments appear, highlighted by the
word WARNING! and supported by the warning triangle symbol.
Technical data
Weight
Flat base (complete with pan bar) 6.05 kg (13.3 lb)
Ball base (complete with pan bar and bowl clamp) 6.39 kg (14 lb)
Height to mounting face
Flat base 184 mm (7.24 in.)
Ball base 171 mm (6.73 in.)
Length 159 mm (6.23 in.)
Width 244 mm (9.6 in.)
Typical payload 25 kg (55 lb) - See balance graph)
Tilt range ±90°
Pan range 360°
Pedestal/tripod fixing 100/150 mm ball
Four-hole flat base
Further information
For further information or advice regarding this pan and tilt head, please contact Vinten Broadcast
Limited, your local Vinten distributor or visit our website.
For full details on maintenance and spare parts, please refer to the Vision 250 Pan and Tilt Head
Maintenance Manual and Illustrated Parts List (Publication Part No. 3465-9), obtainable from Vint-
en Broadcast Limited or your local Vinten distributor. For information on-line, visit our website at
www.vinten.com.
Produktspecifikationer
| Varumärke: | Vinten |
| Kategori: | Stativ |
| Modell: | Vision 250E |
