The AV-1900 is a highly capable mixer-amplier packed with useful features to make it as easy as possible to operate. It
is designed for use in demanding applications like meeting spaces, small auditoriums, lecture theatres, school halls, and
small churches. It has professional audio features normally only found in much more expensive mixer amps.
2 x 50w Mixer Amplier
AV-1900 EU SAP: 5557274
AV-1900+CS-1900 EU SAP: 5734019
AV-1900+SP-1800 EU SAP: 5734020
vav.link/av-1900
2 x 50w RMS (at 8 ohms) low impedance digital power amplier
Input 1: Line-level Stereo (2-Phono/RCA) or Mic (XLR)
Input 2: Line-level Stereo (2-Phono/RCA) or Mic (Phoenix)
Input 3: Bluetooth or Mic (Phoenix)
Input 4: Line-level Stereo (Minijack) or Mic (Phoenix)
1 x Line-level Pre-Output
Balanced Mic inputs with Phantom Power
RS-232 control
Bluetooth
For ease of connectivity it has a Bluetooth input. The device name and pin are xed and
cannot be changed. It can only pair with one device at a time. A device can be manually
unpaired by pressing the INPUT 3 dial. If you do not want Bluetooth active just set input 3 to
mic input with the switch on the rear.
Mixer Amp
This amp has four inputs, each of which can either be used for a microphone
or
a line-level
input. It is a true mixer amp, so it can bring together multiple sources and play them at the
same time.
Mic Pre-Amp Trim
The input gain for each mic input can be "trimmed" - adjusted on the rear panel. This allows the
installer to "turn up" less sensitive mics, and "turn down" hot inputs.
Four Microphone Inputs
All mic inputs are “balanced” to eliminate electro-magnetic noise induced on long cables. Input
1 uses a professional XLR connector - more convenient for rental and portable use, and the
other inputs use phoenix connectors - more suited to permanent installations.
Switchable Phantom Power
Each mic input has Phantom power which is a voltage required to make professional
condenser mics work. Phantom can be turned off on each input discretely.
RS-232
Designed for integration with a bigger system, it can be controlled by a control system such as
Techconnect Control via RS-232.
D-Class
An ecient Digital-class amplier chip dramatically reduces power consumption especially at
rest, and makes this amp super-small.
3 x Stereo Inputs
Three line-level stereo inputs accept input from a variety of sources such as computers (via
the headphone jack), tablets or phones. Inputs 1 and 2 use 2-phono (RCA) connectors. Input 4
is via a Minijack connector, and is duplicated on the front panel for adhoc access.
Line Output
A line-level pre-output on the rear bypasses the internal amplier. It would connect to a larger
amplier or powered loudspeakers. It is post-mix; volume adjustments made on the front
panel affects the output level.
Auto-Standby
If the amplier senses no input it will automatically go into standby mode. When it senses
input it will reactivate. Auto-standby can be disabled via RS-232.
Mounting Options
Rack ears are included so it can be integrated into an AV rack.
39043/en/2020-10-12 14:27:49/2020-10-13 00:08:49
MANUAL
Manual
EN PDF 1.19 MB
les.visionaudiovisual.com/products/AV-1900/manuals/AV-1900_manual.pdf
Product Images
ZIP 7.52 MB
les.visionaudiovisual.com/products/AV-1900/images/AV-1900.zip
SPECIFICATIONS
AMPLIFIER DIMENSIONS
283 x 135 x 45 mm / 11.1″ x 5.3″ x 1.8″ (wide x deep x tall) not including dials and connectors
CARTON DIMENSIONS
333 x 200 x 155 mm / 13.11″ x 7.87″ x 6.10″ (length x width x height)
AMPLIFIER WEIGHT
1.2 kg / 2.65 lbs
PACKAGED WEIGHT
about 3 kg / 6.61 lbs
COLOUR
Black
INPUTS
Input 1: Line-level Stereo (2-phono / RCA) or Balanced Mic (XLR) Input 2: Line-level Stereo (2-
phono RCA) or Balanced Mic (Phoenix) Input 3: Bluetooth or Balanced Mic (Phoenix) Input 4: Line-
level Stereo (Minijack) or Balanced Mic (Phoenix) Note: Input 4 is duplicated on front panel.
Plugging into front panel disconnects the source plugged in at rear.
OUTPUTS
1 x Line-level Stereo (2-phono RCA) Post mix
POWER OUTPUT
2 x 50 Watts RMS @ 8 OHMS
TOTAL HARMONIC DISTORTION
<10%
FREQUENCY RESPONSE (LINE IN)
50Hz~18KHz
SIGNAL TO NOISE RATIO (LINE IN)
70dB
RATING INPUT LEVEL/IMPEDANCE
700mV/47Kohms
OPERATING TEMPERATURE RANGE
0 to +40°C (32 to +104 °F)
POWER CONSUMPTION (RATING CONDITION)
100W
PHANTOM POWER
48V
BLUETOOTH VERSION
5.0
ACCESSORIES INCLUDED
2 x Speaker Cable 5m / 16.4ft long 1 x UK C7 gure-8 power cable 1.8 m long 1 x EU C7 gure-8
power cable 1.8 m long 1 x AU C7 gure-8 power cable 1.8 m long 1 x US C7 gure-8 power cable
5.9ft long 1 x Rack ears
POWER SUPPLY
100~240V Internal Power Supply
WARRANTY
Lifetime return-to-base
COMPLIANCES
RoHS, WEEE, CE/EMC, CE/LVD, RCM_SDOC, FCC_BT3.0, FCC_BT4.0,CE-RED
ORDER PART CODE:
AV-1900 [EU SAP: 5557274 / US SAP: ] or AV-1900+CS-1900 bundle [EU SAP: 5734019 / US SAP: ]
or AV-1900+SP-1800 bundle [EU SAP:5734020 / US SAP: ]
