HIGH OUTPUT LED TAPE
Installation Guide
V2 .0
Caution: Please read this guide carefully before installing Lyyt LED tape
Damage caused by incorrect application is not covered by the warranty
Installation
Lyyt high output LED tape is supplied on 5m reels and operates from a 24Vdc power supply.
Installation should be carried out by competent electrical installers, observing the relevant electrical safety procedures.
The tape has a self-adhesive backing to allow it to be easily attached to a clean, non-porous surface.
Where less than 5m of tape is needed, there are solder points as shown below, where the tape may be cut to size. These
cut points will be at 5cm intervals. In order to re-connect to another length of tape after cutting, strip away the epoxy
coating at the solder points and solder a wire from “+” to “+” and a wire from “ ” to “ ” as shown below. - -
Some accessories are supplied with the tape reel for this purpose or alternatively, connection clips may also be used Lyyt
to join lengths of tape (156.135UK 156.140UK). In order to retain weather-proofing, it is advised to seal the cuts and –
joints with silicone glue.
Each 5m reel of single colour LED tape is fitted with a 2.1mm DC jack socket for power input for easy connection to a
power supply. This connector may be removed and stripped for bare wire connection if a 2.1mm jack is not fitted to the
power supply.
If the power supply has enough capacity to power more than one reel, another reel can be connected to the end of the
first reel via the 2.1mm DC jack plug.
For Lyyt high output LED tape, it is recommended to link no more than 15m of tape in sequence .
Using a separate wire to loop “+” and “ ” back to the power supply will help to avoid dimming at the far end through -
voltage drop.
To connect beyond these lengths, a parallel wire must be run from the power supply to the further reels of tape.
High Output LED Tape Installation Guide
Power requirements
It is imperative that the power supply should have higher than the rated capacity in Amps (A) for the current required to
power the length(s) of LED tape installed. Please see the table below for reference.
Tape length
5m
10m
15m
20m
25m
30m
Current
2A
4A
6A
8A
10A
12A
Suggested PSU
153.759UK
153.760UK
153.761UK
153.762UK
153.763UK
153.764UK
Lyyt high output LED strips can also be operated with Lyyt single colour 12/24V controllers, amplifiers or dimmers.
Specifications
Stock ref.
156.776UK
156.777 UK
156.778UK
Colour
Warm white (3000K)
Natural white (6000K)
Cool white (6000K)
Number of LEDs
120/m
Beam angle
140°
Cut intervals
5cm
Reel length
5m
LED type
Epistar™ SMD3528
LED spacing
8.3 mm
IP rating
IP65
Power consumption / metre
9.6W
Luminous flux (Lumens per metre)
720lm/m
Light intensity per LED
2400mcd
Cross-section
10.5 x 2.55mm
Weight
210g
Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as Electrical or
Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life .
The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
Copyright © 2019. AVSL Group Ltd.
