VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
| | |T: +886- 2-82455282 F: +886-2-82455532 E: sales@vivot ek.com
VIVOTEK USA, INC.
2050 Ringwood Avenue, San Jose, CA 95131
| | |T: 408-773-8686 F: 408-773-8298 E: salesusa@vivotek.com
VIVOTEK Netherlands B.V.
Busplein 36, 1315KV, Almere, The Netherlands
| | |T: +31 (0)36 5389 149 F: +31 (0)36 5389 111 E: saleseurope@vivot ek.com
Non-PoE Switch
Data INP+D OUT
100~240V AC
PoE
PWR
1. Use CAT5 or 5e UTP/STP cables.
2. AC input (100~240V/AC, 50~60Hz), for a max. consumption of 30W.
AP-GIC-010A(B)-030 PoE Injector
Quick Installation Guide
Model Description
AP-GIC-010A-030 GE Standard 802.3at 30W output
AP-GIC-010B-030 GE Passive 30W output.
(The PoE output should only be connected to an IP camera. It should not be
connected to non-PoE devices, such as a PC's LAN port)
IMPORTANT:
INTRODUCTION
CONNECTION
* 1x PoE injector * 1x AC power cord
* 1x Quick Installation Guide
PACKAGE CONTENTS
All specications are subject to change without noice.
Copyright © 2014 VIVOTEK INC. All rights reserved.
Installation Steps:
1. Connect the included AC power cord to the injector. The Power LED (Green) should be lit.
2. Connect the Data IN port to a LAN switch using an Ethernet cable.
3. Connect the Power+Data OUT port to a powered device, i.e., IP camera, using another Ethernet cable. Make sure the
PoE LED (Yellow) is lit.
4. Check if the powered device (IP camera) is working properly. An IP camera may take up to 1 or 2 minutes to power up.
P/N: 625028600G
The AP-GIC-010B-030 GE does not support the following models:
FD8381-EV, IB8381-E, FE8181(V), FE8391
These models come with PoE detection. They will consider the "Passive" injector as an ordinary 802.3af power source,
and hence will only draw 15 watts of power from it. 15 watts is insufcient for driving the onboard heater and IR lights.
IMPORTANT:
