Sida 1/8

- 1 -

アフターサービス

修理および商品のお取り扱いについてのご質問、ご相談は、お客様

相談窓口へお問い合わせください。

お客様相談窓口

0570

666

569

PHS等一部の電話ではご利用できません。固定電話または携帯

電話からおかけください。

受付時間月曜～金曜 10:00 ～ 17:00 （祝祭日、窓口休業日を除く）

● サービス・センター :〒168-0073 東京都杉並区下高井戸1-18-16 2F

輸入販売元: KORG Import Division

〒206-0812 東京都稲城市矢野口4015-2

http://www.korg.com/jp/kid/

本保証書は、上記の保証規定により無償修理をお約束するものです。

保証書

お買上げ日年月日

販売店名

VOX AC30 Radio

保証規定（必ずお読みください）

本保証書は、保証期間中に本製品を保証するもので、付属品類（ヘッドホンなど）は保

証の対象になりません。保証期間内に本製品が故障した場合は、保証規定によって無

償修理いたします。

1. 本保証書の有効期間はお買い上げ日より1か年です。

2. 次の修理等は保証期間内であっても有償となります。

・消耗部品（電池、スピーカー、真空管、フェーダーなど）の交換。

・お取扱い方法が不適当のために生じた故障。

・天災（火災、浸水等）によって生じた故障。

・故障の原因が本製品以外の他の機器にある場合。

・不当な改造、調整、部品交換などにより生じた故障または損傷。

・保証書にお買い上げ日、販売店名が未記入の場合、または字句が書き替えられて

いる場合。

・本保証書の提示がない場合。

尚、当社が修理した部分が再度故障した場合は、保証期間外であっても、修理した

日より3か月以内に限り無償修理いたします。

3. 本保証書は日本国内においてのみ有効です。

This warranty is valid only in Japan.

4. お客様が保証期間中に移転された場合でも、保証は引き続きお使いいただけます。

詳しくは、お客様相談窓口までお問い合わせください。

5. 修理、運送費用が製品の価格より高くなることがありますので、あらかじめお客様

相談窓口へご相談ください。発送にかかる費用は、お客様の負担とさせていただき

ます。

6. 修理中の代替品、商品の貸し出し等は、いかなる場合においても一切行っておりま

せん。

本製品の故障、または使用上生じたお客様の直接、間接の損害につきましては、弊社は

一切の責任を負いかねますのでご了承ください。

本保証書は、保証規定により無償修理をお約束するためのもので、これよりお客

様の法律上の権利を制限するものではありません。

■お願い

1. 保証書に販売年月日等の記入がない場合は無効となります。記入できないときは、

お買い上げ年月日を証明できる領収書等と一緒に保管してください。

2. 保証書は再発行致しませんので、紛失しないように大切に保管してください。

 2017 VOX AMPLIFICATION LTD.

1 Harrison Close, Knowlhill, Milton Keynes, MK5 8PA. UK www.voxamps.com

Vox Ampliﬁcation Ltd.

Thank you for purchasing the VOX AC30 Radio. To ensure trouble-free enjoyment,

please carefully read this manual and use the product correctly. In addition, be

sure to store this manual in a safe place for future reference.

Merci d’avoir choisi la VOX AC30 Radio. Pour une sûreté et un plaisir d’utilisation

maximum, lisez aentivement ce manuel et suivez toutes ses consignes d’utilisa-

tion. Veillez en outre à conserver ce manuel en lieu sûr an de pouvoir le consulter

ultérieurement.

Vielen Dank, dass Sie sich für einen VOX AC30 Radio entschieden haben.

Um möglichst lange Spaß an Ihrem neuen Gerät zu haben, lesen Sie diese Anleitung

aufmerksam und verwenden Sie das Gerät entsprechend. Bewahren Sie diese An-

leitung an einem sicheren Ort auf, um auch später darin nachschlagen zu können.

Gracias por comprar la Radio VOX AC30. Para poder disfrutar de ella sin problemas,

lea este manual atentamente y utilice el producto correctamente. Además, es impor-

tante que guarde este manual en un lugar seguro para futuras consultas.

このたびは、VOX AC30 Radioをお買い上げいただきまして、誠にありが

とうございます。本機を末永くご愛用いただくためにも、取扱説明書をよ

くお読みになって正しい方法でご使用ください。また、取扱説明書は大切

に保存してください。

Owner Manua’s

Manuel d’utilisation

Bedienungsanleitung

Manual de usuario

取扱説明書

EFGSJ 1

Published 3/2017 Printed in China

Area Settings/Paramètres de zone/Bereichseinstellungen/

Conguración del área/

エリア設定

No. Main eriaFM (MHz) AM (KHz)

1 76.0 - 108.0: 0.1 MHz step 522 - 1629: 9 KHz step Japan

2 87.5 - 108.0: 0.05 MHz step 522 - 1629: 9 KHz step Europe

3 87.5 - 108.0: 0.1 MHz step 520 - 1620: 10 KHz step USA

4 87.5 - 108.0: 0.1 MHz step 522 - 1611: 9 KHz step Asia

5 65.0 - 108.0: 0.05 MHz step 522 - 1620: 9 KHz step OIRT

When using this device for the rst time, make sure to set the area

seings for the radio. Refer to “Area Seings” on page 1, “Inserting

baeries” on page 2.

La première fois que vous utilisez cet appareil, veillez à régler les paramètres

de zone de la radio. Voyez “Paramètres de zone” à la page 1, “Installer des piles”

à la page 5.

Bevor Sie das Gerät erstmals benuen, sollten Sie die Bereichseinstellungen

für das Radio vornehmen. Siehe „Bereichseinstellungen“ auf Seite 1, „Einlegen

von Baerien“ auf Seite 6.

Cuando utilice esta unidad por primera vez, asegúrese de hacer los ajustes de

conguración de área geográca para la radio. Consulte “Conguración del área”

en la página 1, Consulte “Insertar las pilas” en la página 7.

初めてご使用になる前に、必ずラジオのエリア設定を行ってください。詳しく

は、1ページの「エリア設定」、8ページ「電池の入れ方」をご覧ください。

- 2 -

Part Names and Functions

13 4

1. AM/FM switch: Switches between AM and FM.

2. Display: Displays the radio station frequency and clock.

Clock Radio

Radio

3. and buons: Use these buons to select a radio station or set the time on

the clock.

4. VOLUME knob: Controls the volume levels for the speakers and PHONES

jack.

5. Antenna: Extend when FM signal reception is poor.

6. PHONES jack: Connect the headphones (stereo mini-plug) here. If you connect

the headphones to this jack, the internal speaker will be muted.

7. AUX IN jack: Used to connect this device to the analog output of audio devices

using a stereo mini-phone plug. Adjust the volume using the connected device.

8. DC 9V jack: Connect a separately-sold AC adapter here.

9. Radio power switch, LED: When the switch is moved to the ON position,

the radio turns on, and the LED lights up. When the switch is moved to the

STANDBY position, the radio turns OFF, and the LED turns o.

Inserting batteries

When using this device for the rst time, make sure to set the area seings

for the radio.

Onceyouhavemadetheseseings,theywillremaininmemoryuntilyousetthe

radioareaoncemore,evenifyoureplacethebaeries.

1. Insert the baeries

while holding down both the buons. and

2. Look at the chart in “Area Seing” on the cover (page 1), and use the

and

buons to select the numbers on the display, according to the region

where the radio will be used.

3. Press both the

and

buons once more. The display blinks as shown

in “Seing the Clock and Alarm”.

Remove the baery cover located on the rear side of the unit. Insert six AA bat-

teries in the correct orientation as shown in the gure.

After baeries are inserted, the display blinks as

in section “Seing the Clock and Alarm”.

Replacing the batteries

If the display becomes dim, replace the baeries with new ones.

Thesoundmaybecomenoisyifthebaerypowerislow.

Removeexhaustedbaeriesimmediately.Otherwise,amalfunctionmayoccur,orthe

baeriesmayleakliquid.Also,removethebaeriesifyouplannottousetheamplier

foralongperiodoftime.

Using the AC adapter (optional)

Connect the AC adapter to the DC 9V jack on the right side. If no baeries are

installed when the AC adapter is connected, the display blinks as in section

“Seing the Clock and Alarm”.

Werecommendinstallingbaeriessotheradiostationfrequencyaswellastimesfor

theclockandalarmaresavedwhentheACadapterisunplugged.

Setting the Clock and Alarm

The clock and alarm display the time only in the 24-hour format.

The alarm is a function that automatically turns on the radio at the specied

time. When the alarm is set, alarm mark “ ” appears in the display

1. With the radio power switch in the STANDBY position and the

clock shown in the display, simultaneously hold down the

and

buons.

The two digits on the left side of the display blink slowly.

2. Use the

buon to select the hour.

Hold down the buon to change the seing continuously.

3. Simultaneously press the

and

buons.

The two digits on the left side light up, and the two digits on the right side

blink slowly.

4. Use the

buon to select the minutes.

Hold down the buon to change the seing continuously.

5. Continue with the next step to set the alarm. If the alarm will not be set,

continue to step 10.

6. Simultaneously press the

and

buons.

The two digits on the right side light up, and the two digits on the left side

blink quickly.

Alarm

mark

7. Use the

buon to select the hour for the alarm.

Select “OFF”, which appears after “24”, to turn o the alarm.

8. Simultaneously press the

and

buons.

The two digits on the left side light up, and the two digits on the right side

blink quickly.

9. Use the

buon to select the minutes for the alarm.

Select “OFF”, which appears after “59”, to turn o the alarm.

Ifeitherthehourorminutesissetto“OFF”,theotherseingwillautomatically

changeto“OFF”.

Simultaneously hold down the buons to apply the seings. and

The display lights up, and the clock with the specied time is displayed.

IfnooperationisperformedusingtheAC30Radiobuons,switchesorknobsfor

about10secondswhilethedisplayisblinking,theclockisdisplayed.

Listening to a Radio Broadcast

When the radio power switch is moved to the ON position, the LED lights up,

the radio frequency appears in the display, and you can listen to the radio.

Whenusingthealarmtolistentotheradio,leavetheradiopowerswitchinthe

STANDBYposition.Iftheradioisturnedo,movethepowerswitchtotheONposi-

tion,thentotheSTANDBYposition.

Iftheradiostationfrequencyisshowninthedisplay,simultaneouslyholddownthe

and buonsforaslongasyouwishtodisplaytheclock.

Search tuning

Use the

buon to tune the radio.

Each time you press a buon, the AM frequency will change by 9 kHz (or 10 kHz),

or the FM frequency will change by 0.1 MHz (or 0.05 MHz).

Scan tuning

Hold down the

buon to tune the radio.

The frequency continues to change, then automatically stops at the frequency of

the rst radio station that is received.

Holding down the buon again will continue tuning the radio, stopping at the

frequency of the next radio station that is received.

Strongnoisemaycausethetuningtostop;however,holdingdownthebuonagain

willcontinuescanning.

Tostopscanning,pressthe or buon.

It may not be possible to receive a radio broadcast from rooms in the center of an

apartment or building. In that case, place the radio near an opening (window or

door) facing outside as much as possible. In addition, reception may be improved

by extending the antenna and adjusting its angle for FM stations or facing the

radio toward the AM radio station.

FM stations are normally received in stereo; however, if the radio waves are weak,

the station may automatically be switched to monaural, which has less noise.

Specications

Radio frequency ranges: According to the area seing

Clock/alarm: 24-hour format

I/O Jacks: AUX IN jack (stereo 1/8” mini-phone jack) x 1,

PHONES jack (stereo 1/8” mini-phone jack) x 1

Output Power: Approx. 1 W RMS x 2 @ 8 ohms

Speakers: 3-inch, 8 ohms x 2

Power Source: AA baeries x 6 (alkaline baeries or zinc-carbon baeries);

or, optional AC adapter

Baery Life: Approximately 8 hours (with FM reception at a continu-

ous volume of 0.1 W while using alkaline baeries)

Approximately 3 years (when displaying only the clock

while using alkaline baeries)

Dimensions (W x D x H): 170 x 80 x 128 mm / 6.69 x 3.15x 5.04 inches

Weight: 640 g / 1.41 lbs. (without baeries)

Accessories: AA baeries x 6

Optional Item: AC adapter (500 mA or greater, DC 9V )

* Appearance and specications of this product are subject to change without notice.

- 3 -

Precautions

Location

Using the unit in the following locations can result in a malfunction:

• In direct sunlight

• Locations of extreme temperature or humidity

• Excessively dusty or dirty locations

• Locations of excessive vibration

• Close to magnetic elds

Power supply

Please connect the designated AC adapter to an AC outlet of the correct voltage. Do not

connect it to an AC outlet of voltage other than that for which your unit is intended.

Interference with other electrical devices

Radios and televisions placed nearby may experience reception interference. Operate

this unit at a suitable distance from radios and televisions.

Handling

To avoid breakage, do not apply excessive force to the switches or controls.

Care

If the exterior becomes dirty, wipe it with a clean, dry cloth. Do not use liquid cleaners

such as benzene or thinner, or cleaning compounds or ammable polishes.

Keep this manual

After reading this manual, please keep it for later reference.

Keeping foreign matter out of your equipment

Never set any container with liquid in it near this equipment. If liquid gets into the

equipment, it could cause a breakdown, re, or electrical shock.

Be careful not to let metal objects get into the equipment. If something does slip into

the equipment, unplug the AC adapter from the wall outlet. Then contact your nearest

VOX dealer or the store where the equipment was purchased.

* All product names and company names are the trademarks or registered trademarks

of their respective owners.

THE FCC REGULATION WARNING (for USA)

NOTE: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or tele-

vision reception, which can be determined by turning the equipment o and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

If items such as cables are included with this equipment, you must use those included items.

Unauthorized changes or modication to this system can void the user’s authority to

operate this equipment.

Notice regarding disposal (EU only)

When this “crossed-out wheeled bin” symbol is displayed on the product, own-

er’s manual, baery, or baery package, it signies that when you wish to dispose

of this product, manual, package or baery you must do so in an approved

manner. Do not discard this product, manual, package or baery along with

ordinary household waste. Disposing in the correct manner will prevent harm

to human health and potential damage to the environment. Since the correct

method of disposal will depend on the applicable laws and regulations in your

locality, please contact your local administrative body for details. If the baery

contains heavy metals in excess of the regulated amount, a chemical symbol is displayed

below the “crossed-out wheeled bin” symbol on the baery or baery package.

IMPORTANT NOTICE TO CONSUMERS

This product has been manufactured according to strict specications and voltage re-

quirements that are applicable in the country in which it is intended that this product

should be used. If you have purchased this product via the internet, through mail order,

and/or via a telephone sale, you must verify that this product is intended to be used in

the country in which you reside.

WARNING: Use of this product in any country other than that for which it is intended

could be dangerous and could invalidate the manufacturer’s or distributor’s warranty.

Please also retain your receipt as proof of purchase otherwise your product may be

disqualied from the manufacturer’s or distributor’s warranty.

Précautions

Emplacement

L’utilisation de cet instrument dans les endroits suivants peut en entraîner le mauvais fonc-

tionnement.

• En plein soleil

• Endroits très chauds ou très humides

• Endroits sales ou fort poussiéreux

• Endroits soumis à de fortes vibrations

• A proximité de champs magnétiques

Vorsichtsmaßnahmen

Aufstellungsort

Vermeiden Sie das Aufstellen des Geräts an Orten, an denen

• es direkter Sonneneinstrahlung ausgeset ist;

• hohe Feuchtigkeit oder Extremtemperaturen auftreten können;

• Staub oder Schmu in großen Mengen vorhanden sind;

• das Gerät Erschüerungen ausgeset sein kann.

• in der Nähe eines Magnetfeldes.

Stromversorgung

Schließen Sie das optionale Neteil nur an eine geeignete Steckdose an. Verbinden Sie es

niemals mit einer Steckdose einer anderen Spannung.

Störeinüsse auf andere Elektrogeräte

Dieser kann bei in der Nähe aufgestellten Rund-funkempfängern oder Fernsehgeräten Emp-

fangsstörungen hervorrufen. Betreiben Sie solche Geräte nur in einem geeigneten Abstand

von diesem Erzeugnis.

Bedienung

Vermeiden Sie bei der Bedienung von Schaltern und Reglern unangemessenen Kraftaufwand.

Reinigung

Bei auftretender Verschmuung können Sie das Gehäuse mit einem trockenen, sauberen Tuch

abwischen. Verwenden Sie keinerlei Flüssigreiniger wie beispielsweise Reinigungsbenzin,

Verdünnungs- oder Spülmiel. Verwenden Sie niemals brennbare Reiniger.

Bedienungsanleitung

Bewahren Sie diese Bedienungsanleitung gut auf, falls Sie sie später noch einmal benötigen.

Flüssigkeiten und Fremdkörper

Stellen Sie niemals Behältnisse mit Flüssigkeiten in der Nähe des Geräts auf. Wenn Flüssigkeit

in das Gerät gelangt, können Beschädigung des Geräts, Feuer oder ein elek-trischer Schlag

die Folge sein.

Beachten Sie, daß keinerlei Fremdkörper in das Gerät gelangen. Sollte ein Fremdkörper in

das Gerät gelangt sein, so trennen Sie es sofort vom Ne. Wenden Sie sich dann an Ihren

VOX-Fachhändler.

* Alle Produkt- und Firmennamen sind Warenzeichen oder eingetragene Warenzeichen

der betreenden Eigentümer.

Alimentation

Branchez l’adaptateur secteur mentionné à une prise secteur de tension appropriée. Evitez de

brancher l’adaptateur à une prise de courant dont la tension ne correspond pas à celle pour

laquelle l’appareil est conçu.

Interférences avec d’autres appareils électriques

Les postes de radio et de télévision situés à proximité peuvent par conséquent sourir d’interfé-

rences à la réception. Veuillez dès lors faire fonctionner cet appareil à une distance raisonnable

de postes de radio et de télévision.

Maniement

Pour éviter de les endommager, manipulez les commandes et les boutons de cet instrument

avec soin.

Entretien

Lorsque l’instrument se salit, neoyez-le avec un chion propre et sec. Ne vous servez pas

d’agents de neoyage liquides tels que du benzène ou du diluant, voire des produits inammables.

Conservez ce manuel

Après avoir lu ce manuel, veuillez le conserver soigneusement pour toute référence ultérieure.

Evitez toute intrusion d’objets ou de liquide

Ne placez jamais de récipient contenant du liquide près de l’instrument. Si le liquide se ren-

verse ou coule, il risque de provoquer des dommages, un court-circuit ou une électrocution.

Veillez à ne pas laisser tomber des objets métalliques dans le boîtier (trombones, par ex.). Si

cela se produit, débranchez l’alimentation de la prise de courant et contactez votre revendeur

VOX le plus proche ou la surface où vous avez acheté l’instrument.

* Tous les noms de produits et de sociétés sont des marques commerciales ou déposées de

leur détenteur respectif.

Note concernant les dispositions (Seulement EU)

Quand un symbole avec une poubelle barrée d’une croix apparait sur le produit, le mode

d’emploi, les piles ou le pack de piles, cela signie que ce produit, manuel ou piles doit

être déposé chez un représentant compétent, et non pas dans une poubelle ou toute autre

décheerie conventionnelle.

Disposer de cee manière, de prévenir les dommages pour la santé humaine et les dom-

mages potentiels pour l’environnement. La bonne méthode d’élimination dépendra des

lois et règlements applicables dans votre localité, s’il vous plaît, contactez votre organisme

administratif pour plus de détails. Si la pile contient des métaux lourds au-delà du seuil

réglementé, un symbole chimique est aché en dessous du symbole de la poubelle barrée d’une

croix sur la pile ou le pack de piles.

REMARQUE IMPORTANTE POUR LES CLIENTS

Ce produit a été fabriqué suivant des spécications sévères et des besoins en tension applicables

dans le pays où ce produit doit être utilisé. Si vous avez acheté ce produit via l’internet, par vente

par correspondance ou/et vente par téléphone, vous devez vérier que ce produit est bien utilisable

dans le pays où vous résidez.

ATTENTION: L’utilisation de ce produit dans un pays autre que celui pour lequel il a été conçu

peut être dangereuse et annulera la garantie du fabricant ou du distributeur. Conservez bien

votre récépissé qui est la preuve de votre achat, faute de quoi votre produit ne risque de ne plus

être couvert par la garantie du fabricant ou du distributeur.

Produktspecifikationer

Varumärke:	Vox
Kategori:	högtalare
Modell:	AC30

Behöver du hjälp?

Om du behöver hjälp med Vox AC30 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

högtalare Vox Manualer

Vox AC30 Bruksanvisning

19 Augusti 2024

Vox VT20X Bruksanvisning

3 Augusti 2024

högtalare Manualer

Nyaste högtalare Manualer

Streetz CM717 Bruksanvisning

20 Mars 2025

Streetz CM715 Bruksanvisning

20 Mars 2025

Streetz CM716 Bruksanvisning

20 Mars 2025

SOUNDBOKS The Battery Bruksanvisning

20 Mars 2025

ETON HEX 165 Bruksanvisning

19 Mars 2025

ETON PRW 50 Bruksanvisning

19 Mars 2025

ETON PFX 10 Bruksanvisning

19 Mars 2025

ETON PRA 80 Bruksanvisning

19 Mars 2025

ETON PFX 16 Bruksanvisning

19 Mars 2025

Manta SPK12GO Bruksanvisning

19 Mars 2025
