Sida 1/10
39
VT8237 SATA RAID User Manual
Enter BIOS Configuration Utility
When the system powers on, the following information will appear on
screen. Press the ‘Tab’ key to enter BIOS configuration
utility.
VIA Technologies,Inc.VIA Serial ATA RAID BIOS Setting Utility v1.00
Copyright (C) VIA Technologies,Inc.All Right reserved.
Scan Devices,Please wait . . .
Press < Tab > Key into User Window!
Channel 0 Master: IC35L040AVVA07-0
Channel 1 Master: IC35L040AVVA07-0
The main interface of BIOS conguration utility is as below:
VIA Tech. RAID BIOS Ver 1.00
8Create Array Create a RAID array with
8Delete Array the hard disks attached to
8Create/Delete Spare VIA IDE controller
8Select Boot Array
8Serial Number View F1 : View Array/disk Status
éê : Move to next item
Enter : Conrm the selection
ESC : Exit
Channel Drive Name Array Name Mode Size(GB) Status
Channel0 Master IC35L040AVVA07-0 ATA 100 38.34 Hdd
Channel1 Master IC35L040AVVA07-0 ATA 100 38.34 Hdd
VT8237 SATA RAID User Manual
40
Technical Reference Booklet
Create Disk Array
1. Use the arrow keys to navigate the main menu. Use the up and down arrow keys to
select the Create Array command and press <Enter> to call out the list of creation
steps.
VIA Tech. RAID BIOS Ver 1.00
8Auto Setup For Data Security Create a RAID array with
8Array Mode RAID 1 (Mirroring) the hard disks attached to
8Select Disk Drives VIA IDE controller
8Start Create Process
F1 : View Array/disk Status
éê : Move to next item
Enter : Conrm the selection
ESC : Exit
Channel Drive Name Array Name Mode Size(GB) Status
Channel0 Master IC35L040AVVA07-0 ATA 100 38.34 Hdd
Channel1 Master IC35L040AVVA07-0 ATA 100 38.34 Hdd
2. Highlight the Array Mode and press <Enter>, then a list of array modes will appear.
Just highlight the target array mode that you want to create, and press <Enter> to
VIA Tech. RAID BIOS Ver 1.00
8RAID 0 for performance Create a RAID array with
8RAID 1 for data protection the hard disks attached to
VIA IDE controller
8RAID SPAN for capacity
F1 : View Array/disk Status
éê : Move to next item
Enter : Conrm the selection
ESC : Exit
Channel Drive Name Array Name Mode Size(GB) Status
Channel0 Master IC35L040AVVA07-0 ATA 100 38.34 Hdd
Channel1 Master IC35L040AVVA07-0 ATA 100 38.34 Hdd
41
3. After selected array mode, there are two methods to create a disk array. One method
is “Auto Setup Auto Setup” another is “Select Disk Drives”. let BIOS select the
disk drives and create array automatically. Select Disk Drives let user select the array
drives by required. When using Select Disk Drives method, the channel column will be
activated. Just highlight the target drives that you want to use and press <Enter> to
select them respectively. After all drives have been selected, press <Esc> to go back
to the creation steps menu.
VIA Tech. RAID BIOS Ver 1.00
8Auto Setup For Performance Create a RAID array with
8Array Mode RAID 0 (Striping) the hard disks attached to
8Select Disk Drives VIA IDE controller
8Block Size 64K
8Start Create Process F1 : View Array/disk Status
éê : Move to next item
Enter : Conrm the selection
ESC : Exit
Channel Drive Name Array Name Mode Size(GB) Status
[ * ]Channel0 Master IC35L040AVVA07-0 ATA 100 38.34 Stripe0
[ ]Channel1 Master IC35L040AVVA07-0 ATA 100 38.34 Hdd
4. If user selected a RAID 0 array in step 2, user also can select a block size for the
array. Use the arrow key to highlight the Block Size and press <Enter>, then select a
block size from will popup. The block size can be selected from 4K to 64K Bytes.
VIA Tech. RAID BIOS Ver 1.00
8Auto Setup For 4K Create a RAID array with
8Array Mode RAID 8K the hard disks attached to
8Select Disk Dri 16K VIA IDE controller
8Block Size 64K 32K
8Start Create Pr 64K F1 : View Array/disk Status
éê : Move to next item
Enter : Conrm the selection
ESC : Exit
Channel Drive Name Array Name Mode Size(GB) Status
[ * ]Channel0 Master IC35L040AVVA07-0 ATA 100 38.34 Stripe0
[ * ]Channel1 Master IC35L040AVVA07-0 ATA 100 38.34 Stripe1
Create Disk Array
