Läs nedan 📖 manual på svenska för Waring Commercial DMC201DCA (2 sidor) i kategorin Matberedare. Denna guide var användbar för 5 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/2
3. Referring to wiring diagram, disconnect both motor leads of mixing
head to be removed. Black lead is connected to the NC (normally
closed) terminal of the associated on/off switch via a quick-connect
terminal.
4. Support mixer head from front of unit, and remove the 3 (three)
machine screws securing mixer head to front panel
5. Guide wires through hole in front panel while lifting mixer head free
of unit.
6. Replace rear panel.
TO REPLACE MIXER HEAD: Reverse above procedure.
Waring Commercial
314 Ella T. Grasso Ave.
Torrington, CT 06790
www.waringproducts.com 027866 RV02 0902
Multiple-Spindle
Mixer
IMPORTANT SAFEGUARDS FOR
WARING COMMERCIAL MIXERS
1. READ ALL INSTRUCTIONS.
2. To protect against electrical shock, do not put the Waring
Commercial Mixer in water or other liquid.
3. Unplug from outlet when not in use, before putting on or
taking off parts, and before cleaning.
4. Avoid contacting moving parts.
5. Do not operate the Waring Commercial Mixer or any other
electrical equipment with a damaged cord or plug, or after
the unit malfunctions, is dropped or damaged in any
manner. Return it to the nearest authorized service facility
for examination, repair, or adjustment.
6. Do not use outdoors.
7. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
8. Do not operate the mixer unless the U-shaped stabilizing
leg on the bottom of the unit is unfolded and fully seated in
position, projecting from the rear of the base.
Exception: If mixer is operated against a supporting wall,
stabilizing leg may be left folded under unit.
SAVE THESE INSTRUCTIONS
White/Blue
Black
Black
Black
Green/Yellow
White
White
White
Brown/Blue
Brown/Blue
Brown/Blue
Black/Brown
Motor 1 Motor 2 Motor 3
Switch 1
NC
NO
C
Switch 2
NC
NO
C
Switch 3
NC
NO
C
GROUNDING INSTRUCTIONS
• For your protection, Waring Commercial Mixers are equipped with
3-conductor cordsets.
• 120 Volt units are supplied with a molded 3-prong grounding-type
plug, and should be used in combination with a properly connected
grounding-type outlet as shown in Figure A.
If a grounding-type outlet is not available, an adapter, shown in Figure
B, may be obtained to enable a 2-slot wall outlet to be used with a
3-prong plug.
Referring to Figure C, the adapter must be grounded by attaching its
grounding lug under the screw of the outlet cover plate.
Before using an adapter, it must be determined that theCAUTION:
outlet cover plate screw is properly grounded. If in doubt, consult a
licensed electrician.
Never use an adapter unless you are sure it is properly grounded.
Use of an adapter is not permitted in Canada.NOTE:
GREEN/YELLOW: EARTH GROUND WHITE/BLUE: NEUTRAL BLACK/BROWN: LIVE
HOW TO USE YOUR WARING COMMERCIAL MIXER
Each mixing head of your Waring Commercial Mixer has an automatic on/off
switch that starts the motor. The motor is started when the container contacts
the on/off switch actuator and it is moved in an upward direction. The motor
will continue to run until the container is removed from the unit. A HIGH/LOW
speed selector switch is incorporated into each head. Mixer is designed to
operate with a rolled lip milk-shake container.
CLEANING/SANITIZING INSTRUCTIONS
1. Rinse containers thoroughly under running water. Add 8 ounces of clean
rinse water to containers. Place container in normal operating position on
mixer and run on high speed for two (2) minutes. Empty containers.
2. UNPLUG POWER CORD FROM ELECTRICAL OUTLET.
3. Loosen and remove thumbscrews and container rests. With both hands
reach around the mixer shaft. Place your fore fingers on each side of the
actuator knob in the indentation of the knob; placing your thumbs on the
top of the knob so as you pull the knob off of the switch stud you will not
hit the shaft.
4. Wash, rinse, and sanitize thumbscrews, on/off switch actuator knobs,
and containers. Sanitize these parts by immersing in sanitizing
solution for two (2) minutes. Shake off excess moisture and allow
parts to air dry.
5. Working from the top down, wash, rinse, and sanitize the portion of the
mixer housing situated directly over the containers and the portion of the
spindles above the agitators, using absorbent wiping cloths moistened with
cleaning solution, rinse water and sanitizing solution.
6. Reassemble on/off switch actuator knobs by placing actuator knob over
switch stud. With your other hand holding the back of the unit, to prevent
the unit from toppling over. Push actuator knob until you hear it snap in
place
7. Wash, rinse, and sanitize the agitators and the spindle bottoms as follows.
Plug power cord into electrical outlet.
Add 8 ounces of washing solution to containers and place in normal
operating position on mixer.
Run on high speed for a minimum of two (2) minutes.
Empty containers, and repeat two-minute run with 8 ounces of rinse
water.
Empty containers. Run motors for a few seconds with empty containers
in normal operating position to spin off any excess moisture. Empty
containers. Do not rinse containers, spindles or agitators after sanitizing
is completed.
Allow parts to air dry.
Wash, rinse, and sanitize as outlined above prior to initial use, and when-ever
mixer will not be used again within a period of one hour.
Surfaces of the mixer housing which are outside of the food-contact areas may
be cleaned as required, using wiping cloths moistened with cleaning solution, rinse
water, and sanitizing solution. UNPLUG POWER CORD FROM ELECTRICAL
OUTLET BEFORE CLEANING HOUSING. Prevent liquid from running into
housing by wringing all excess moisture from wiping cloths before using them.
Washing solutions based on non-sudsing detergents and chlorine-based
sanitizing solutions having a minimum chlorine concentration of 100 PPM are
recommended.
The following washing, rinsing, and sanitizing solutions, or their equivalents,
may be used.
REMOVAL AND REPLACEMENT OF MIXER HEADS
Each of the three mixing heads is individually removable for replacement or
repair.
TO REMOVE MIXER HEAD
1. Unplug unit from electrical outlet.
2. Remove rear cover panel from unit by removing the 7 (seven) screws.
A. B. C.
Circuit Grounding Conductor
Connected Properly
Grounding Prong
Grounding Lug
Adapter
Cover
Mounting
Screw
Cover of Ground Outlet Box
SOLUTION PRODUCT DILUTION IN WATER TEMPERATURE
WASHING: CALGON® CALGOLAC 1 TABLESPOONS/GALLON HOT (115˚ F)
RINSING: PLAIN WATER WARM (95˚F)
SANITIZING: CLOROX® INSTITUTIONAL 1 TABLESPOON/GALLON COLD (50˚ F
BLEACH 70˚ F)
