Sida 1/6
Datenblatt
Erstellungs-Datum 15 februari 2017 11:08:45 CET
Katalogstand 10.02.2017 / Technische Änderungen vorbehalten 1
Testing tools
COMBI CHECK
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 1429-0
Fax: +49 5231 14292083
www.weidmueller.com
General ordering data
Type COMBI CHECK
Order No. 9918860000
Version 2-pole voltage tester type 1156, Yes - visual +
acoustic
GTIN (EAN) 4032248405749
Qty. 1 stuk(s)
The main function of the voltage tester is to establish
if voltage is present. A 2-pole voltage tester is the only
approved testing instrument that fulfils the requirements
of work protection regulations.
• with LED-Display
• acc. to VDE standard
• high peak voltage strength
• the right tester for every application
Datenblatt
Testing tools
COMBI CHECK
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 1429-0
Fax: +49 5231 14292083
www.weidmueller.com
Technische Daten
Erstellungs-Datum 15 februari 2017 11:08:45 CET
Katalogstand 10.02.2017 / Technische Änderungen vorbehalten 2
Dimensions and weights
Weight 290 g Net weight 356 g
Measuring and testing devices
AC voltage display 6,12, 24, 50, 120, 230,
400, 690 V
AC voltage measuring range
6-690 V
Battery type 1.5 V type AAA battery Continuity test Yes - visual + acoustic
DC voltage display 6,12, 24, 50, 120, 230,
400, 690 V
Display
LED
Frequency range, max. 100 Hz Frequency range, min. 0 Hz
Insulation test
6 kV
Measuring range category CATIV - 400V/ CAT III -
690V
Operating temperature, max. 45 °C Operating temperature, min. -15 °C
Peak voltage resistance 8 kV Protection degree IP65
Rated voltage, max. 690 V AC/DC Rated voltage, min. 6 V
Classifications
ETIM 3.0 EC000494 ETIM 4.0 EC000494
ETIM 5.0 EC000494 ETIM 6.0 EC000494
UNSPSC 41-11-36-37 eClass 5.1 27-20-03-08
eClass 6.2 27-20-03-08 eClass 7.1 27-20-03-08
eClass 8.1 27-20-03-08 eClass 9.0 27-20-03-08
eClass 9.1 27-20-03-08
Product information
Descriptive text technical data Buzzer included
Approvals
Approvals
ROHS Conform
Downloads
PDF 9918860000_DECLARATION_OF_CONFORMITY.pdf
Datenblatt
Testing tools
COMBI CHECK
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 1429-0
Fax: +49 5231 14292083
www.weidmueller.com
Zeichnungen
Erstellungs-Datum 15 februari 2017 11:08:45 CET
Katalogstand 10.02.2017 / Technische Änderungen vorbehalten 3
Produktspecifikationer
| Varumärke: | Weidmüller |
| Kategori: | Multimeter |
| Modell: | Volt Combi Check 3,1 |
