限用物质及其化学符 (Restricted substance and its chemical symbols)
部件名称
Unit
电路板
Circuit Board
电子元器件
Electronic Components
外壳
Case
线材
Cables
风扇
Fan
散热片
Heat Sink
其他辅料
Other Accessories
Pb
Hg
Cd
六价铬
Cr (Vl)
多溴联苯
PBB
多溴 二苯醚
PBDE
超出 及超出 系指限用物质之百分比含量超出百分比含量基准值。 0.1wt% 0.01wt%
Exceeding 0.1wt% and Exceeding 0.01wt% indicate that the percentage content of the restricted substance
exceeds the reference percentage value of presence condition.
: 系指该项限用物质之百分比含量未超出百分比含量基准值。
Indicates that the percentage content of the restricted substance does not exceed the percentage of
reference value of presence.
: 系指该项限用物质為排除項目
Indicates that the restricted substance corresponds to the exemption.
YEAR
LIMIT ED
WARRANT Y
LIMIT ED
WARRANT Y
1010
CYBERCORE PLATINUM SERIES
QUICK
START
GUIDE
QSG Product
Website
English
Deutsch
Español
Français
Россию
Português
Türkçe
日本の
한국어
简体中文
繁體中文
3
11
19
27
35
43
51
59
67
75
83
91
ﻲﺑرﻋ
G A M E
TO T H E
X T R EM E
CYBERCORE 1300 PLATINUM
CYBERCORE 1000 PLATINUM
Installation
Safety and Agency Approvals
5
7
9
10
EN
Product Specifications
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW
XPG CYBERCORE PLATINUM SERIES POWER SUPPLIES
XPG CYBERCORE PLATINUM Series power supplies are created for silence with extreme
power performance, designed with a 120mm XPG VENTO PRO 120 PWM cooling fan
featuring extremely low RPM fan control circuit design allows the fan to operate efficiently
and silently. 80 PLUS PLATINUM rated efficiency ensures low-cost operation, and its fully
modular cable set provides user convenience and easy to build.
XPG CYBERCORE PLATINUM uses high quality 10C Japanese capacitors throughout and
is a great choice for a high performance PC.
SAFETY AND PROTECTION
The main outputs will be latched off when each protection is triggered. The main
output can be reset by cycling the DC remote on/off or AC power. +5Vsb output is auto
recovery when fault condition is removed.
INTEGRATED PROTECTION CIRCUITS
Over Current Protection :
XPG has followed Intel Power Supply Design Guide with 110%-140% of total current on all+12V &
+5V & +3.3V rails. Therefore OCP of XPG CYBERCORE PLATINUM is more effective.
Over Voltage Protection :
OVP on +12V, +5V, +3.3V DC outputs rails are required to comply with the latest Intel ATX Power
Supply Design Guide. OVP shuts down the PSU in the event that the DC outputs exceed a set level,
determined by the PSU manufacturer. The minimum voltage levels required for compliance is +12V
rail@ 15.6V max , +5V rail at 7.0V max, +3.3V rail at 4.5V max.
Over Power Protection :
XPG has followed Intel ATX Power Supply Design Guide with 110-150% of PSU Total
Wattage.
Over Temperature Protection :
OTP ensures that the PSU will shut down when the PSU internal temperature reaches a set
point. This is usually as a result of internal current over loading or a defect fan.
No Load Operation :
XPG has followed Intel ATX Power Supply Design Guide with 0A minimum loading to
support Intel Haswell C6/C7 sleep mode function.
Short Circuit Protection :
SCP is defined as any output impedance of less than 0.1ohms. Amongst other things, SCP
ensures that the PSU shuts down should the +12V, +5V & +3.3V rails short to any ground,
or any other rail. It also ensures that no damage should occur to your PC components if
there is any short circuit inside the system.
XPG Power Supplies have full protection circuits on board to keep your expensive components safe under all
circumstances.
