Xvive LV1 is a miniature professional lavalier microphone for use with the Xvive U5
Wireless Audio for Video System, or other broadcast/recording devices. This small
omni-directional clip-on microphone includes a locking 3.5mm connector, and
easily attaches to any clothing. It’s designed for speech and vocal applications and
features high-level speech intelligibility.
FEATURES
• Superior audio clarity
• Natural response across the frequency range
• Low distortion
• Includes both a foam windscreen and a fur windshield for
attenuating breath noise and wind noise
• Matte black, sleek, low-prole design
• Microphone capsule with omni-directional pickup pattern
• The plug locks and is compatible with standard TRS interface
Microphone Connector
Mono 3.5mm TRS output. Ensure the
connected device provides a regulated +
2.5V to 10V voltage to the “+” conductor.
LV1 LAVALIER MICROPHONE
Microphone
Dimensions
Weight
Directivity
Sensitivity
Frequency response
Impedance
Signal-to-noise ratio
Current consumption
Operating voltage
Maximum input Sound Pressure Level
Electret condenser microphone
ϕ 8 × 19 mm (cable: 1.6 m / 5.25 ft)
13 g /0.46 oz
Omni-directional
-32 dB ± 3 dB
30 Hz – 20 kHz
2.5 kΩ ± 30%
75 dB
400μA Max
3.3V (2.5V to 10V)
120 dB SPL
P R O F E S S I O N A L W E A R A B L E M I R O P H O N E
LAVALIER MICROPHONE
TRS Wiring Diagram
“+” Audio output
and bias voltage
Ground
LAVALIER MICROPHONE SETUP
a) Install windscreen and mic clip on the lavalier
microphone (see “INSTALL CLIP” diagrams);
b) Use the mic clip to attach the microphone to
clothing, as desired;
c) Run the mic cable to the transmitter in a way that
avoids friction noise, and so that the cable and
the wireless transmitter antenna do not cross;
d) The Xvive LV1 Lavalier Microphone has an
omni-directional pickup pattern. Keep at least
10 inches away from your mouth or audio source.
Plug the 3.5mm TRS lavalier microphone plug into
your recording device or wireless audio transmitter.
QUICK STARTINSTALL CLIP
SHENZHEN FZONE TECHNOLOGY CO., LTD.
2nd floor, Building 12, Xicheng Industrial Area, Xixiang
Town, Baoan District, Shenzhen Guangdong, China.
www.xviveaudio.com
Made in China
>10 inches
1A
B
2
3
4
