LED LightYN60 RGB II
Thanks for using YN60 RGB II, Please read the instructions and pay attention to the warnings.
Product Structure
Warnings
1. Please keep it d, do not touch the product with wet
hands, or do not immerse the product in water or expose
it to rain.
2. Please do not use this product in a high temperature
environment or in a closed space under direct sunlight.
3. This product has built-in lithium batte, do not
disassemble, impact, squeeze, or put into the re. Please
follow the corresponding operating regulations, otherwise
it may cause explosion or re.
1. Unplug the power cord after charging is completed.
2. If the product has not been used for a long time,
please charge the product rst.
3. This product has built-in lithium batte, the batte
life will be shoened after a period of use, which is a
normal phenomenon.
4. Do not irradiate LED to the human eye at close range,
otherwise it may temporarily aect the vision.
Precautions
* When the body temperature reaches 70°, YN60 RGB II
will automatically enter the overheating protection
state to ensure the safety, and after its body getting
cool, YN60 RGB II will automatically turn on.
Instruction for Use
1. Turn on and set the working mode
Long press 【 】button to turn on, the OLED screen
lights, and the display will show the current batte level,
then sho press【 】 button to set the working mode,
switch successively among CCT color temperature mode
/ HSI mode / SCENE mode, and long press the button
again to turn o.
2. CCT color temperature mode
Press【 】 button, switch to set the brightness or color
temperature, press button or button to 【 】 【 】
adjust the value of the brightness or color temperature,
the brightness adjustment range is 1% -100%, and the
color temperature adjustment range is 2500K-9900K.
3. HSI hue mode
Press【 】button to switch H: hue / : brightness/S
saturation, and then press【 】button or【 】button
to set each parameter. The brightness adjustment range
is 1% -100%, and the hue setting range is 0°-360°.
(Color can refer to hue bar)
4. Scene modes (SCENE)
Suppo 25 kinds of scene modes, press【 】button to
cycle switch between the brightness and scene modes,
press【 】 【 】button or button to set the scene modes
or brightness.
5. Batte icon
Each grid represents about 1/5 of the batte percentage.
When the battepower is going to run out, please charge
in time.
6. Charging
The charging po is Type-c, suppos up to 5V*2.1A.
(the charging head needs to be purchased separately)
7. 1/4 inch screw po
The bottom of the lamp is equipped with a 1/4-inch screw
po for easy use of other accessories.
8. Set up the automatic save function
The current working mode will be automatically saved
when the product is shut down.
Specication
Model YN60 RGB II CRI Ra: ≥95
CCT Color
Temperature 2500~9900K(±100K)
Lamp
Beads
68pcs
24pcs warm-white
lamp beads
RGB Hue﹙HSI） 0°~360°
Fixed Inteace 1/4 nut inteace hole×1
Brightness
Adjustment 1%~100%
Maximum Power Approx.6W
Display Screen 0.96inch OLED
display screen
Batte Life 1.1~11h
Scene Modes suppo﹙25 kinds）
Built-in
Lithium Batte 2000mAh
Charging Po Type-c
Charging Power 5V2.1A
Material PC,ABS,PMMA
Dimension 66*66*19.6mm
Weight
1Simulated lightning
2Film screen reection
3Candlelight
4Sunset
5Fireworks
6
Rainbow seven-color cycle
7
RGB color gamut cycle
8 Police car
9Ambulance
10 Fire truck
11 Flash
12 Heabeat
13 SOS
14 Alpine emergency signal
15 Pay （fast pace）
16 Festival atmosphere
17 Fire scene
18 Red light ash
19 Green light ash
20 Blue light ash
21 Yellow light ash
22 Purple light ash
23 Cyan light ash
24
Color temperature cycle
25
Photographic light
Warranty Card
Dear customer, the warranty card is an impoant
proof of warranty seice. Please keep this warranty
card properly.
Please conrm the following items:
1. The product warranty period is one year.
(Since the date of purchase)
2. During the warranty period, the user can get free repair
for the occurred product failure due to the use
according to the instructions.
3. During the warranty period, when you need warranty
seice, please take this card and the product to our
maintenance seice center for warranty seice.
(You can also mail this card and product to our seice
center for warranty seice.)
4. Products under one of the following circumstances are
not within the scope of free repair.
1) Out of warranty, the user himself dismantled the product,
the mechanical structure is man-made damaged.
2) Improper use by users, such as not following the
instructions or use non-compliant power supply.
3) No warranty card, the warranty card is purposely
altered or not lled in, or inconsistent with the product
sent for repair.
4) Fault and damage caused by non-product quality
reasons such as drop, vibration or transpoation
collision after purchase.
Do not disassemble or repair this product by yourself. We
will not provide warranty seice if you disassemble the
machine without authorization. If there is any fault, please
contact our company or local dealer. This product is
guaranteed for one year from the date of sale.
The specications and parameters of this product are tested
according to the laborato samples of the company. The
nished product may have slightly dierent and will not
aect the normal use, and the design and specications are
subject to change without notice.
【 】Power switch (long press)
Scene mode switch button (sho press)
【 】
Button
【 】Button
Switch hue/brightness/saturation
1OLED display screen
2
3
4
5
6
TYPE-C charging po
7
1/4 nut inteace hole
Shell
8
LED lamp bead
9
current color temperature and batte percentage
Curent saturation
（about 1 hour to
fully charge）
Product List
YN60 RGB II ×1
Cold-shoe seat with screw ×1
Charging cable ×1
Manual×1
Manufacturer:
Shenzhen YONGNUO Electronic Equipment Co., Ltd.
Address: Room 209 Block A, A1 Building and 2/F-5/F, A2
Building,No.14 Jinxiu East Road, Xiuxin Community,
Kengzi Street, Pingshan District, Shenzhen
Telephone: (86)0755-33001023
Website: www.hkyongnuo.com
Executive standard: Q/YNDQ 001
Illuminance
Distance 0.3m (Lux) 0.5m (Lux) 1m (Lux)
Cold light
Warm light
Red
Green
Blue
1205 498.5 135
984 401 108
162 54.3 18.6
446 178 49.6
105 42.4 12.1
* The specications and parameters of this product are tested according to the laborato samples
of the company. The nished product may have slightly dierent and will not aect the normal
use, and the design and specications are subject to change without notice.
100%
Power
IIIuminance
YN60 RGB II
M
5432
7
1
66mm
66mm 19.6mm
10
8
9
【 】
M
Hue bar for reference
10
YN60 RGB II
M
6
M
M
2500K
1%
CCT
current
batte
percentage
HSI
H:77°
S:100
26%
10
SCENE
S-MODE
Flash
1%
current CCT mode
current brightness
current color temperature
current batte
percentage current HSI mode
current brightness
current batte
percentage current SCENE mode
current brightness
24pcs cold-white
lamp beads
20pcs RGB lamp beads
ÉTUI ET BARQUETTE
À SÉPARER ET À DÉPOSER
DANS LE BAC DE TRI
Approx.88g
Current hue
current mode
