Rechargeable table lamp
poldina micro
1. Tips for use:
This product is exclusively for lighting purposes and:
A) It must not be exposed to heavy mechanical loads or contamination; It can be installed and used only after checking the state of the pro-B)
duct; check that is not dirty and has not been damaged during storage; Installation and maintenance must be carried out when the appliance C)
is switched off; Any alterations to the product, any tampering and any failure to comply with the instructions provided may make the appliance D)
hazardous; When fully assembled, the lamp (head+structure, without the recharging base), reaches an IP65 rating, making it idealE)
for outdoor use. The light fixture (top) alone and the assembled lamp placed on the recharging base has an IP20 rating, making it unsuitable for
outdoor use; All metal and plastic surfaces should be cleaned with a soft dry cloth; The company Zafferano shall not be held liable for any F) G)
damage caused due to its products being assembled in any manner that does not comply with the instructions provided.
2. Technical data of the lamp:
- Power: 1,8 W
- Volt: DC 5 V
- Color temperature: 2200 - 2700 - 3000 K
- Lumen lamp: 124 - 128 -142 lm
- Lithium battery pack included (see section accessories included); for instructions about how to replace the battery pack, please consult the
website: www.zafferanoitalia.com. Use only original batteries for replacement.
- Charge: 3/4 h
- Battery life: 7/8 h
- Class: III
- Protection rating: IP65
- CRI>80
3. Battery charger technical data:
- Contact charging base: INPUT/OUTPUT 5Vdc - 1A; cavo USB 1.2 Mt.
- USB port power charger NOT INCLUDED: INPUT AC100-240V 50/60Hz; OUTPUT 5Vdc- 1A.
- The lamp works correctly even when connected to the charging base.
- We recommend using an optional charger and the original cherging base provided. Alternatively, use a certified cable and a 1A max charger.
4. Important:
- The support surface for the lamp must not exceed a 15° tilt or it will fall.
- The battery has an overload protection function.
- To preserve the integrity of the battery, we recommend keeping the charge between minimum 20% and maximum 80%; if the lamp is not used for
long periods, it is advisable to regularly charge/discharge the product.
- Please refer to local laws for the proper disposal and recycling of the battery.
DESIGNED BY ZAFFERANO SRL IN ITALY, MADE IN PRC • Zafferano srl, Viale dell’Industria, 26 - 31055 Quinto di Treviso - TV - Italia •
For more information and updates visit our website • www.zafferanoitalia.com
3
INCLUDED NOT INCLUDED
Single-contact
charging station
LD0340RA
Multi-socket USB
charger (8xUSB)
BAT04704004001000
Replacement battery pack
This product contains a class F light source
KIT00005704800200
Replacement LED board
LED DIMMER
1,8W LED • 124-128-142lm • 2200-
2700-3000K • IP65 • 100-240V
50-60Hz • CRI>80 • 5Vdc max 1A
Ø 7 x h 27,5 cm / Ø 2,8 x h 10,8 in
LD0490B3 white
LD0490C3 chrome
LD0490D3 black
LD0490F3 red
LD0490G3 sage green
LD0490K3 Capri blue
LD0490L3 blue lilac
LD0490N3 dark grey
LD0490O3 gold
LD0490P3 pink
LD0490R3 corten
LD0490S3 sand
LD0490V3 yellow green
LD0490Z3 orange
7 x 7 cm
2,8 x 2,8 in
Ø 7 cm
Ø 2,8 in
27,5 cm
10,8 in
LD0490UA
USB port power charger
DESIGNED BY ZAFFERANO SRL IN ITALY, MADE IN PRC • Zafferano srl, Viale dell’Industria, 26 - 31055 Quinto di Treviso - TV - Italia •
For more information and updates visit our website • www.zafferanoitalia.com
INSTRUCTIONS FOR USE
SWITCHING ON / SWITCHING OFF / DIMMING
Quick taps to:
- turn on
- turn off the lamp
When the lamp is switched on, lightly press the touch sensor to
obtain the desired brightness. Every time you turn it on, the light
intensity returns to 100%
4
<1 sec <1 sec
4 sec 4 sec
When the lamp is switched off, press
lightly for 4 seconds until a steady blue
LED lights up
Quick tap on the touch sensor
to change the color temperature
of the lamp
Light pressure for 4 seconds to set
the new color temperature and switch off
the lamp
COLOR TEMPERATURE CONFIGURATION
<1 sec <1 sec <1 sec
2200K 2700K 3000K
Charge the battery before initial use.
To correctly charge the lamp, we recommend that you:
1) Connect the USB cable to the adaptor;
2) Put the plug into the electrical socket
3) Place the lamp on the charging base;
4) When fully charged, disconnect the plug from the electrical socket
INDICATOR LEDS
FLASHING RED LED
the battery charge is lower than 20%,
charging is recommended.
When the charge is depleted (1%), the lamp
does not switch on but emits three white flashes
as an alert to charge
PERMANENT GREEN LED
the battery is 100% charged,
disconnection from the power charger
is recommended
PERMANENT RED LED
charging in progress
