Sida 1/48

CONTENTS

SAFETY INSTRUCTIONS 2

Important Safety Instructions

Grounding Instructions

BEFORE INSTALLING 4

Electric Shock Hazard

PREPARING THE DISHWASHER ENCLOSURE 5

Product Dimensions

Enclosure Dimensions

INSTALLING THE DISHWASHER 6

Step 1: Check the Parts and Tools

Step 2: Select the Best Location for the Dishwasher

Step 3: Check Water Supply Requirements and Cautions

Step 4: Check the Electrical Requirements and Cautions

Step 5: Unpacking and Inspecting the Dishwasher

Step 6: Preparing the Dishwasher

Step 7: Placing the Dishwasher and Connecting the Hot Water Supply Line

Step 8: Leveling the Dishwasher

Step 9: Securing the Dishwasher

Step 10: Connecting the Drain Hose

Step 11: Wiring Connections

Step 12: Completing the Installation

SPECIFICATIONS 24

Installation Guide

CONTENTS

Users Manual

SAFETY INSTRUCTIONS 26

Proper Installation

Basic Precaution Before Use

FEATURES OF YOUR NEW DISHWASHER 28

Speciﬁcation

Filter System

Smart Wash System

OPERATING INSTRUCTIONS 32

Control Panel

Cycle Chart

PREPARING AND LOADING DISHES 36

Loading the Lower Basket

Loading the Upper Basket

Loading the Silverware Basket

Adding a Dish

Filling the Detergent Dispenser

Filling the Rinse Aid Reservoir

USER MAINTENANCE 40

Cleaning the Exterior

Cleaning the Interior

Cleaning the Nozzles

TROUBLESHOOTING 41

Installation Guide

Step 4: Check the Electrical Requirements and Cautions

The electrical requirements for the dishwasher are as follows:

In the United States, install in accordance with the National Electric Code/State and

Municipal codes and/or local codes.

For cable direct connections.

Use ﬂexible, armored or non-metallic sheathed, copper wire with a

grounding wire that meets the wiring requirements for your local codes and

ordinances.

Use the strain relief method provided with the wiring junction box or install

a U.L.-listed/CSA-certiﬁed clamp connector to the wiring junction box. If

using conduit, use a U.L.-listed/CSA-certiﬁed conduit connector.

installing the dishwasher

Step 7: Placing the Dishwasher and Connecting the Hot Water

Supply Line

1. Adjust the three leveling legs at the bottom of the dishwasher after measuring the

height of the cabinet opening from under the countertop to the ﬂoor. (See Step 8,

Leveling the Dishwasher.)

2. Locate the hot water supply line and the power cable.

3. Place the dishwasher so that the power cable is in the right channel of the base of

the dishwasher. Use standard duct tape or cable ties to secure the electrical cable to

their adjacent channels in the base. This can prevent the electrical cable from being

squeezed when you push the dishwasher into place.

4. Pull the drain hose through the hole in the sink cabinet side wall. Keep it free of

kinks and twists.

5. Make sure the hot water supply line is not twisted, and then connect the hot water

supply line to the elbow joint.

6. Slide the dishwasher carefully into the installation space. If possible, gently pull any

excess lengths of water supply line, drain hose, or power cable back as you move the

dishwasher. Get a second or third person to help you do this if necessary.

installing the dishwasher

Do not place the dishwasher on the water supply line, drain

hose, or power cable. Also, make sure they are not folded or

twisted.

WARNING

Figure 7

Figure 6

Step 9: Securing the Dishwasher Continued

The screws or tub spacer cap may fall into the dishwasher while you are working with

the door open.

Cover the interior of the dishwasher with a towel to prevent any screws from falling

into the dishwasher. If any foreign items such as a screw get into the dishwasher, it

may cause noise, an abnormal operation, damage,

or a malfunction.

Use a magnetic screwdriver to help prevent screws from falling into the dishwasher.

If a foreign item, such as a screw, gets into the dishwasher and you are unable to

remove it, the dishwasher needs to be disassembled. Contact a qualiﬁed service

technician for this.

installing the dishwasher

Figure 8

Figure 9

Users Manual
