Sida 1/6
M M321
1U Rack M ine Mixer with Bluetoothic/L ®, USB & FM Tuner
Item ref: 8 953.02 UK
User Manual
Version 4.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
953. 8 User Manual 02 UK
Introduction
Thank you for choosing an Adastra MM321 mic/line mixer with built-in media player as part of your sound reinforcement system.
This unit is designed to offer high quality, dependable service for audio mixing and distribution .
Please read this manual to gain the best results from your product and avoid damage through misuse.
SAFETY SYMBOL AND MESSAGE CONVENTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC ELECTRIQUE NE PAS
OUVRIR
This symbol indicates that dangerous voltage constituting a risk of electric shock is
present within this unit
This symbol indicates that there are important operating and maintenance instructions in
the literature accompanying this unit.
SAFETY NOTICE
1. Prior to use, read through this manual
2. Keep the manual in good condition
3. Pay attention to safety warnings
4. Observe all operating requirements
5. Do not use the device near water or wet areas
6. For cleaning, only use a lint-free, dry cloth
7. Install according to the specificatio ns
8. Place ay from heat sources or heating appliances aw
9. Use mains lead provided and avoid damage to cable or connectors
10. Unplug power from mains during stormy weather or if unused for long periods
11. In case of malfunction, water ingress or other damage, consult qualified service personnel
12. Do not place in damp areas or near liquids or moisture. Do not spill liquids on the housing
13. Please pay attention to warning symbols during transit and placement
14. Terminals marked with the symbol are HAZARDOUS LIVE and should only be connected by qualified personnel
15. Ensure that the apparatus is connected to a mains socket with a protective EARTH connection
16. Ensure correct operation of the mains switch
Warning
To prevent the risk of fire or electric shock, do not expose any components to rain or moisture.
If liquids are spilled on the casing, stop using immediately, allow unit to dry out and have checked by qualified personnel before
further use. Avoid impact, extreme pressure or heavy vibration to the case
No user serviceable parts insi Do not open the case refer all servicing to qualified service personnel. de – –
Safety
• Check for correct mains voltage and condition of IEC lead before connecting to power outlet
Placement
• This unit can be used free- rack standing or fixed into a 19”
• Ensure adequate support and access to controls and connectors when rack-mounting
Cleaning
• Use a soft cloth with a neutral detergent to clean the housing as required
• Do not use strong solvents for cleaning the unit
953. 8 User Manual 02 UK
Front panel
Rear panel
Connection
Ensure the Power (15) is switched off until all input and output connections are in place.
Turn all rotary level controls ( - and Master level (13) fully down (anti-clockwise) to avoid loud noises 5 10)
when switching on.
Set the BASS and TREB Tone controls (11, 12 to the vertical position (zero) LE )
Channels 1, 2 and 3 can accept microphones or mono line level inputs, such as CD, TV or electronic keyboard.
Connect the main microphone or line level signal to Mic/Line 1 input on the rear panel via balanced XLR (28)
or 6.3mm jack .
If a condenser mic is being used connect via XLR, select Mic level and 20V Phantom power on via the channel ,
1 DIP switches (27)
Further mic or line level signals can be connected to inputs 2 and (24, 26) in the same way as for channel 1 3
Set the DIP switches for channels 2 and 3 (23, 25) to suit the input source.
Connect stereo line level sources to AUX and AUX 2 RCA inputs (21, 22). 1
Outputs are available on L+R balanced XLR (18) for stereo operation and a single 6.3mm unbalanced jack
(19) summed to mono. Record outputs on L+R RCA (20) are unaffected by the Master level control.
1.
3.5mm AUX input to media player
9.
Aux line input 1 level control
2.
USB port
10.
Aux line input 2 level control
3.
Media player control panel
11.
Bass EQ boost/cut control
4.
Media player LCD display
12.
Treble EQ boost/cut control
5.
Media player level control
13.
Master output level control
6.
Mic/Line input 1 level control
14.
Output level LED indicators
7.
Mic/Line input 2 level control
15.
Power switch and indicator
8.
Mic/Line input 3 level control
16.
IEC mains inlet and fuse holder
2 4.
Input 3 balanced XLR/jack
17.
24V emergency alarm contacts
25.
Mic/Line and phantom switches Input 2
18.
L+R XLR balanced outputs
26.
Input 2 balanced XLR/jack
19.
6.3mm jack mono unbalanced output
27.
Mic/Line and phantom switches Input 1
2 0.
Recor utput L+R RCA d o
28.
Input 1 balanced XLR/jack
21.
Aux 2 line input L+R RCA
29.
Ch.1 override level
22.
Aux 1 line input L+R RCA
30.
BT antenna connector
23.
Mic/Line and phantom switches Input 3
31.
FM tuner antenna F connector
