Z44R
Multi-purpose Rack Mixer
Item ref: 953.020 UK
User Manual
• 2 balanced microphone inputs
• Lo-cut rumble filters
• 3-band EQ per Mic channel
• Switchable 48V phantom power
• 2 x A/B selectable stereo line inputs
• 2-band EQ per Line channel
• Foot-switchable DSP Reverb or ext. FX
• 4 stereo zones with selectable line outs
• Emergency mute contacts
• Suitable for live vocalist PA
• Suitable for 4-zone installation
• Ideal karaoke add-on for DJ
Version 1.1
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
953.020UK User Manual
Introduction
Thank you for choosing the Adastra Z44R multi-purpose rack mixer. This product has been designed to offer a versatile and wide
range of functions to meet many different applications. In order to achieve the best results from this equipment and avoid damage
through misuse, please read and follow these instructions and retain for future reference.
Warning
To prevent the risk of fire or electric shock, do not expose any part of the unit to rain or moisture
If liquids are spilled on the surface, stop using immediately, allow unit to dry out and have checked by qualified personnel
Avoid impact, extreme pressure or heavy vibration to the unit
There are no user serviceable parts inside the mixer refer all servicing to qualified service personnel –
Safety
• Check that the supplied mains lead is in good condition and the supply voltage is correct.
• Ensure signal leads are of good condition without shorted connections (especially when using phantom power)
• Do not allow any foreign particles to enter the console through connectors or control apertures
Placement
• Keep out of direct sunlight away from heat sources and damp or dusty environments ,
• When rack-mounting, avoid placing heavy units above the Z44R and ensure all connectors are accessible
Cleaning
• Use a soft cloth with a neutral detergent to clean the casing as required
• Use a soft brush to clear debris from the control surface
• Do not use strong solvents for cleaning the unit.
Front Panel
1. 48V phantom power LED indicator
2. MIC/LINE 1 LEVEL control
3. MIC/LINE 1 signal and peak LEDs
4. MIC/LINE 1 GAIN control
5. MIC/LINE 2 LEVEL control
6. MIC/LINE 2 signal and peak LEDs
7. MIC/LINE 2 GAIN control
8. LINE 3 LEVEL control
9. LINE 3 peak LED
10. LINE 4 LEVEL control
11. LINE 4 peak LED
12. REVERB TIME parameter control
13. OUT 1 level control & peak LED
14. OUT 2 level control & peak LED
15. OUT 3 level control & peak LED
16. OUT 4 level control & peak LED
17. MIC/LINE 1 combo input
18. MIC/LINE 1 low-cut rumble filter
19. MIC/LINE 1 FX level control
20. MIC/LINE 1 EQ sliders
21. MIC/LINE 2 low-cut rumble filter
22. MIC/LINE 2 FX level control
23. MIC/LINE 2 EQ sliders
24. LINE 3 source select switch
25. LINE 3 EQ sliders
26. LINE 4 source select switch
27. LINE 4 EQ sliders
28. REVERB DEPTH control
29. OUT 1 line selectors
30. OUT 2 line selectors
31. OUT 3 line selectors
32. OUT 4 line selectors
33. Power ON/OFF switch
953.020UK User Manual
Rear Panel
Application
The Z44R can be configured to serve a variety of applications. Deciding upon the particular setup should be the first step
in order to ensure all signal leads are connected properly. Some suggested combinations are shown below.
1. DJ Add-on Vocal Mixer
For DJs who want the option to host karaoke events, the Z44R offers 2 extra microphone channels with genuine
DSP reverb effect and 2 extra switchable line sources (for laptop, CD+G players, MP3 players etc).
Adding these extra features takes up just 1U of rack space and can be configured as a sub-mixer into the main
DJ console or as the main mixer to offer more stereo outputs…
1. IEC mains inl et
2. OUT 4 jack outputs L+R
3. OUT 3 RCA outputs L+R
4. OUT 2 RCA outputs L+R
5. OUT 1 RCA outputs L+R
6. MUTE CONTACTS for emergency systems
7. FX LOOP RETURNS jacks L+R
8. FX LOOP SEND jack
9. REVERB or FX LOOP FOOT SWITCH jack
10. LINE 4 B input RCAs L+R
11. LINE 4 A input jacks L+R
12. LINE 3 B input RCAs L+R
13. LINE 3 A input jacks L+R
14. MIC/LINE 2 combo input
15. 48V phantom power switch
16. MIC/LINE 1 rear jack input
