ISSUED: DEC. 2014

(

)

RATE

ATE

ATED

70kg

(154lbs)

RATED

Video Wall Mount

INSTALLATION MANUAL

CAUT IO N: DO NOT EXCEED

RATED LISTED WEIGHT. SERIOUS

INJURY OR PROPERTY DAMAGE

MAY OCCUR!

200x200

400x200/400x400

600x400

/300x300

AS0364T

70"

MAX

Maintenan ce

• Check that the bracket is secure a nd safe to use at regular intervals(at least every three mo nths).

• Please cont act your distributor if you have any que stions.

9. Lock the Pop-out Module with the Plastic Locking Pieces

Component Checklist

IMPORTANT: Ensure that you have received all parts according to t he component checklist prior to installation.

If any parts are missing o r faulty, telephone your lo cal distributor for a replac emen t.

Package M

Package W

ST6.3x55 (x6)

W-A

concrete anchor

W-B

(x6) D6 washer (x6)

W-C

NOTE: Read the entire instruction manual before you start installation and assembly.

WARNING

M5x14

M-A

(x4) M6x14

M-B

(x4)

washer

M-F

(x4)

M8x20

M-C

(x4)

big

M-H

spacer (x4)

M6x30

M-D

(x4)

M8x30

M-E

(x4) small spacer (x8)

M-G

• Do not begin the installation until you have read and understood all the instructions

and warnings contained in this installation sheet. If you have any questions

regarding any of the instructions or warnings, please contact your local distributor.

• This mounting bracket was designed to be installed and utilised ONLY as

specified in this manual. Improper installation of this product may cause damage

or serious injury.

• This product should only be installed by someone with good mechanical ability

who has basic building experience and fully understands this manual.

• Make sure that the supporting surface will safely support the combined weight of

the equipment and all attached hardware and components.

• Always use an assistant or mechanical lifting equipment to safely lift and position

the equipment.

• Tighten screws firmly, but do not over tighten. Over tightening can cause damage

to the items, This greatly reduces their holding power.

• This product is intended for indoor use only. Using this product outdoors could

lead to product failure and personal injury.

antiskid block (x2)

plastic locking piece (x2)

wall plate

(x1) pop-out module

(x1)

M8x12 (x8)

M8 nut (x8)

adapter bracket (x2)

VESA adapter (x2)

VESA adapter

(x2)

1. For Solid Brick and Concrete Wall Mounting

Drill pilot holes

X X

√

Screw the wall

plate onto

the wall

60mm

60mm60mm

(

((2

22.

..4

44"

"")

)

))

60mm

(2.4")

ø 10mm

(ø 3/8")

Mark the

exact location of

mounting holes

Installers must verify that the supporting surface will safely support the combined weight of

the equipment and all attached hardware and components.

WARNING

2. For Video Wall Installation (Mounting space as shown below)

X=Length of display Y=Height of display

3. Installing the Pop-out Module

Please take off the caps before installation.

W-C

W-A

W-

W-B

BW-B

Y+5mm
