Video Wall Mount
INSTALLATION MANUAL
CAUTI ON: DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
200x200
400x200 /400x40 0
600x400
/300x30 0
AS0346T
70"
MAX
9. Lock the Pop-out Module with the Plastic Locking Pieces
Maintenance
• Check that the brack et is secur e and safe to u se at regular intervals(at least every three months).
• Please contact your distrib utor if you have any questions.
8. Fixing the Brackets Position with the Antiskid Blocks
Install the both antiskid blocks as close to the adapter brackets as possible.
Tighten screws on the antis kid blocks using a proper screwdriver to prevent display from moving.
D
2
Component Checklist
IMPORTANT: Ensure that you ha ve received all parts ac cording to the compon ent checklist prior to insta llation.
If any parts are missing o r faul ty, telephone your local distri butor for a replac ement.
Package M
Package W
ST6.3x55 (x6)
W-A
concrete anchor
W-B
(x6) D6 washer (x6)
W-C
1
NOTE: Read the entire instruction manual before you start installation and assembly.
WARNING
M5x14
M-A
(x4) M6x14
M-B
(x4)
washer
M-F
(x4)
M8x20
M-C
(x4)
big
M-H
spacer (x4)
M6x30
M-D
(x4)
M8x30
M-E
(x4) small spacer (x8)
M-G
• Do not begin the installation until you have read and understood all the instructions
and warnings contained in this installation sheet. If you have any questions
regarding any of the instructions or warnings, please contact your local distributor.
• This mounting bracket was designed to be installed and utilised ONLY as
specified in this manual. Improper installation of this product may cause damage
or serious injury.
• This product should only be installed by someone with good mechanical ability
who has basic building experience and fully understands this manual.
• Make sure that the supporting surface will safely support the combined weight of
the equipment and all attached hardware and components.
• Always use an assistant or mechanical lifting equipment to safely lift and position
the equipment.
• Tighten screws firmly, but do not over tighten. Over tightening can cause damage
to the items, This greatly reduces their holding power.
• This product is intended for indoor use only. Using this product outdoors could
lead to product failure and personal injury.
wall plate
A
(x1) pop-out module
B
(x1)
adapter bracket (x2)
C
antiskid block (x2)
D
plastic locking piece (x2)
E
4
3
1. For Solid Brick and Concrete Wall Mounting
Drill pilot holes
2
X X
√
Screw the wall
plate onto
the wall
60mm
60mm
60mm
60mm60mm
(
(
(
((2
2
2
22.
.
.
..4
4
4
44"
"
"
"")
)
)
))
60mm
(2.4")
ø 10mm
(ø 3/8")
Mark the
exact location of
mounting holes
1
Installers must verify that the supporting surface will safely support the combined weight of
the equipment and all attached hardware and components.
WARNING
W-C
W-A
W-
W-
W-
W-B
B
B
BW-B
2. For Video Wall Installation (Mounting space as shown below)
3. Installing the Pop-out Module
XX
Y+5mm
Y+5mm
X=Length of display Y=Height of display
Hang the pop-out module onto the
wall plate. Secure it by tightening
both screws.
Please take off the caps before installation.
